- Page 1 Golden Technologies - 401 Bridge Street - Old Forge, PA 18518 Tel: 800-624-6374 - Fax: 800-628-5165 - www.goldentech.com LIT-GP130-OM, Rev. B...
- Page 3 Literature is current at the time of printing. Golden Technologies reserves the right to make changes to the product or literature at any time.
-
Page 4: Table Of Contents
Contents Contents Intended Use: The intended use of the Carry On power wheelchair is to provide mobility to adults, limited to a sitting position and have the capability to operate a simple hand control. Introduction....4 Safety......5 III. EMI / RFI / FCC....9 Specifications.... -
Page 5: Introduction
We at Golden Technologies, Inc. know that you have chosen a power chair that will give you years of dependable operation and also will enhance the quality of your life by providing you with the mobility to experience an active daily lifestyle. -
Page 6: Safety
Safety Safety II. II. Safety Guidelines The symbols below are used in the owner’s manual and/or on the product to identify warn- ings and to notify you of important safety information. Make sure you read and understand them completely. WARNING! Indicate(s) a hazardous situation which, if not avoided, could result in death or serious injury. - Page 7 Never sit on your Carry On when it is being transported. Do not connect or allow anyone except an authorized Golden Technologies, Inc. provider to connect any electrical or mechanical device to your scooter. Unauthorized accessories will void the warranty and may cause injury.
- Page 8 ENTERING AND EXITING Have your Golden Technologies, Inc. representative determine if it is advisable for you to practice getting on and off your power chair and operating it in the presence of an attendant.
- Page 9 II. II. Safety Safety ENTERING AND EXITING Exiting • Make certain that the power is turned off. • Flip up the armrests. • Flip up the footrest. • Carefully stand and step away from the chair. Never transfer on or off of this power wheelchair using the seat backrest, arms, and footrest for support during transfer.
-
Page 10: Emi / Rfi / Fcc
• Report all incidents of unintended movement or brake failure to your Golden Technolo- gies representative or to Golden Technologies. Turn off your power chair as soon as it is safely possible if unintended or un- controllable motion occurs or if unintended brake release occurs. - Page 11 III. III. EMI / RFI / FCC EMI / RFI / FCC FCC RULES PART 15 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 12: Specifications
Specifications Specifications Model Number GP130 Medicare Code Weight Capacity Drive Wheels Center Maximum Speed 3.85 MPH Operating Range 12.5 Miles Ground Clearance 2” Turning Radius 21.25” Type Batteries Li-Ion, 12.5Ah Colors Red, Blue Freewheel Mode Electro-Mechanical Brake Charger Off-Board, 2A Controller Dimensions: Length... -
Page 13: Main Components
Main Components Main Components Light Switch Joystick USB Port Removable Underseat Basket Headlights Foldable Seatpost Foot Plate Drive Wheels Freewheel Levers Caster Wheels Taillight... -
Page 14: Assembly
Assembly Assembly FUSE A fuse will need to be installed to operate. 1. Remove the battery pack see page 16. 3. The fuse can be 2. Remove found in its holder the controller once you open the cover under cover. Install the fuse the basket. - Page 15 Assembly Assembly ARM INSTALLATION • Line up the two teeth on the arm assembly with the cavity on the seat assembly as shown. • Once the arm is fully inserted, rotate it into its downward position to lock it in. •...
-
Page 16: Operation
Operation Operation VII. VII. Read and follow the owner’s manual before operating your power chair. Your Carry On is simple to operate. However, for your safety and the safety of others, Golden Technologies, Inc. recommends that you carefully read and understand the following oper- ating instructions. - Page 17 VII. VII. Operation Operation FREEWHEEL MODE Your Carry On is equipped with a Freewheel Mode feature which will, when activated, allow this device to be pushed manually. Turn the unit off. You will find two red brake levers in the center of the unit, one attached to each motor.
- Page 18 VII. VII. Operation Operation BATTERY PACK AND CHARGING Battery Charging Your Carry On charging system is designed for your safety and for your convenience. Follow the steps below to recharge the battery pack. 1. Position your unit close to a standard wall electrical outlet. 2.
- Page 19 VII. VII. Operation Operation DRIVING Your Carry On is simple to operate. However, for your safety and the safety of others, Golden Technologies, Inc. recommends that you carefully read and understand the following oper- ating instructions. We also recommend that you practice operating your Carry On in an area free of any obstacles.
- Page 20 VII. VII. Operation Operation HELPFUL DRIVING TIPS AND INSTRUCTIONS Doors • Approach any unfamiliar door slowly. • Notice if the door has a door knob or a push bar. • Determine if the door opens towards you or away from you. •...
-
Page 21: Iix. Care & Maintenance
Care & Care & IIX. IIX. Maintenance Maintenance ROUTINE MAINTENANCE Your power wheelchair requires a minimal amount of care and maintenance. If you do not feel confident in your ability to perform the maintenance listed below, you can schedule an inspection and maintenance with your retailer. -
Page 22: Fault Diagnosis & Troubleshooting
Fault Diagnosis & Fault Diagnosis & Troubleshooting Troubleshooting Fault Codes For your convenience, the Carry On has an automatic fault warning system. If, when powered up, there is a fault with the system, the joystick lights will flash. Each differing fault will pro- duce a different qaunity of flashes. - Page 23 Five-Year Limited Warranty: For the period of five years from the date of purchase, in the event of defective materials or workmanship, Golden Technologies will repair or replace at our option any of the following structural frame components found to be defective by an authorized Golden Technologies representative: •...
- Page 24 Items not mentioned or listed are covered at the discretion of Golden Technologies. Any accessories, standard or optional, supplied by Golden Technologies, are covered for a period of one year from the date of purchase with the particular unit. Warranty Exclusions:...
- Page 26 Fold Here First Place Stamp Here Golden Technologies 401 Bridge St. Old Forge, PA 18518 Fold Here Second...
- Page 28 LIT-GP130-OM, Rev. B...
