LED90 Series
Installation Instructions
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations
if applicable.
• Do not mount in hazardous locations, or near gas or electrical heaters.
• Do not let power cords touch hot surface.
• Do not use outdoors.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering
by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• Allow battery to charge for 24 hours before first use.
10070344 REV1 - 03/24
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS!
Technical Support
■ (623) 580-8943 ■ technicalsupport@barronltg.com
1
800-533-3948 www.barronltg.com
Advertisement
Related Manuals for Exitronix LED90 Series
Summary of Contents for Exitronix LED90 Series
- Page 1 LED90 Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only.
- Page 2 LED90 Series Installation Instructions Wall/Ceiling Mount - Back Power Feed (Fig. 2/Fig. 3) Fig. 1 1. Insert a flat blade screwdriver into the two slots to remove front cover from backplate. (Fig 1). Remove the knockout hole on the center of the backplate. Then remove the knockouts on the backplate that correspond to the junction box holes to be used.
- Page 3 LED90 Series Installation Instructions Wiring Diagram (Fig. 5) Fig. 5 AC INPUT Orange 277VAC Integral LED Head Charge White NEUTRAL PCBA Black 120VAC Remote Heads 3.6V, 1.5W max (-R Option) 6.4V, 2W max (-G2-R Option) Remote Heads Connection - (Option) 1.
- Page 4 LED90 Series Installation Instructions Testing and Reporting Instructions (G2 models) 1. When AC power is supplied to fixture, the unit will automatically initiate a self-test and self-diagnostic test as follows: • Verifies battery disconnection, charger board failure at every 5 seconds.
