Exitronix VEX-WPCR Series Installation Instructions

READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations if applicable.
• Do not mount near gas or electrical heaters.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering by
unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• May be used in outdoor covered environment with temperatures ranging from 10°C to 40°C
(50°F to 104°F)
Wall Mount
1. Use flat head screwdriver to loosen the screws on the lens.
2. Remove lens from sign and set aside for later use.
3. Remove the EXIT stencil from housing and set aside.
4. Drill out the desired mounting knockouts found on the backplate to fit the junction box mounting dimensions.
5. Drill or knock-out the center wire access hole on the backplate for the unit's supply wire leads.
6. Remove the backing from self adhesive junction box gasket and adhere to the backplate.
7. Route the unit's input wires through center wire access hole of the backplate and make wiring connection
(see Electrical Connections section).
8. Secure backplate to junction box using the correct hardware (supplied by others).
9. Remove desired chevron(s) as needed. Note: When removing chevrons it may be helpful to remove the color
diffuser panel to allow easier access to the chevrons. Once chevrons have been successfully removed it is
important to reinstall the diffuser panel.
10. To prevent battery damage: Do not connect the battery untill constant AC power can be supplied to the unit.
11. Secure faceplate(s) to the housing.
12. Secure lens to faceplate.
13. Press "TEST" button to check operation.
10070207 Rev 1 - 11/18

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS!
VEX-WPCR SERIES

INSTALLATION INSTRUCTIONS

1
Use Flexible Conduit Only
