Exitronix 400EX Series Installation Instructions

Table of Contents

Download this manual

400EX Series

Installation Instructions

READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

When using electrical equipment, basic safety precautions should always be followed including the following:

• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.

• Installation and servicing of this equipment should be performed by qualified service personnel only.

• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations, if

applicable.

• Do not mount near gas or electrical heaters.

• Do not use outdoors.

• Do not let power supply cords touch hot surfaces.

• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering

by unauthorized personnel.

• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.

• Any modification or use of non-original components will void the warranty and product liability.

• Do not use this equipment for other than intended use.

• Allow battery to charge for 24 hours before first use.

• Use caution when servicing batteries. Battery acid can cause burns to skin and eyes. If acid is spilled on skin

or eyes, flush acid with fresh water and contact a physician immediately.

• Unpack and check for concealed transit damage.

• Report any transit damage to delivering carrier and file claim.

10070257 REV 1 - 02/22

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS!

Technical Support

■ (623) 580-8943 ■ technicalsupport@barronltg.com

800-533-3948 www.barronltg.com

Table of Contents

Do you have a question about the 400EX Series and is the answer not in the manual?

Page 1 400EX Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only.
Page 2 400EX Series Installation Instructions Ceiling or End Mount 1. Remove faceplate cover by pulling equally at the outer rim of the faceplate on two opposite sides. Remove ground wire from faceplate (Fig. 1). 2. Pop out the plastic mounting hole cover on the top or the side of the sign. Place one of the nuts from threaded stem rod in the slot inside the housing just inside of the unit (Fig.
Page 3 400EX Series Installation Instructions Wall Mount 1. Remove faceplate cover by pulling equally at the outer rim of the faceplate on two opposite sides. Remove ground wire from faceplate (Fig. 1). 2. Remove the center knockout and also required knockouts that will match the J-box.
Page 4 400EX Series Installation Instructions Self-test/Self-diagnostics (G2) Operation The purpose of this option is to provide Self-testing and Self-diagnostic capabilities to the EXIT sign. At predetermined intervals, the EXIT sign will automatically switch into battery mode. Refer to the Self-Test Features section of this page for timing details.
