Summary of Contents for Daewoo DTQ 14V1FCN
- Page 1 14V1FCN 20V1FCN 14V4SCN 20V4SCN P/N:48586001E217-R0...
- Page 2 The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the product s enclosure that may be of suffi- cient magnitude to constitute a risk electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and servicing instructions in the literature accompanying the appliance.
-
Page 3: Table Of Contents
CONTENTS Your TV's Front Panel Your TV's Back Panel Your Remote Controls Installing your remote control batteries Notes Connecting an Antenna Connecting a Cable System Connecting Other Pieces of Equipment Safety Note Turning your TV On Programming Your TV's Channel Memory Changing Channels Changing the Volume Changing The TV's Channel Memory... - Page 4 S A F E T Y PLEASE READ ALL THESE INSTRUCTIONS REGARDING YOUR TELEVISION EQUIPMENT AND RETAIN FOR FUTURE REFERENCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE TV RECEIVER. Read all of these instructions. Save these instructions for later use. Unplug this television equipment from the wall outlet before cleaning.
- Page 5 An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
- Page 6 C H A P T E R Your TV comes with a remote control. The section below summarizes the buttons, controls, and terminals that you will use with your TV. POWER Use this button to turn your TV on or off. Use these buttons to change channels on your TV, or to select items in the menu system.
- Page 7 VIDEO AUDIO Use this terminal to attach an antenna or cable system to your TV. This terminal allows the TV to receive a video signal from another component, such as a VCR. This terminal allows the TV to receive an audio sighal from another component, such as a VCR.
-
Page 8: Overview Of Your Equipment
Use this button to turn your TV on or off. Use to turn the TV s sound on and off. Use these buttons to change channels on your TV, or select items in the menu system. Use these buttons to change your TV' s volume, to activate selections in the menu system, or to change audio and video settings. - Page 9 Open the battery compartment on the back of the remote control. Install two AA-size batteries (not included) as shown. Make sure the + and - terminals are oriented cor- rectly. Replace the cover. Do not mix different types of batteries, or mix an old and a new battery. Remove and replace weak batteries.
-
Page 10: Connecting An Antenna
C H A P T E R Your TV will provide you with the best performance if you connect it to an external antenna or cable system. Follow the directions below make this connection. Please note that you will normally only have to make one of the connections shown below, not all of them. - Page 11 You might have two sets of leads from your antenna system, especially if you have one antenna for VHF signals and one antenna for UHF signals. combiner (available at your local electronics store). Press or screw the coaxial lead onto the combiner; place the twin leads underneath the screws on the combiner and tighten the screws.
- Page 12 incoming cable to the IN terminal on the converter box. Connect another cable between the OUT terminal on the converter box and the antenna terminal on the TV. You will need to keep your TV tuned to channel 3 or 4 and change channels using the converter box.
- Page 13 C H A P T E R Once you have connected your TV to an antenna or cable system, plugged the TV in, and put batteries in the remote, you are ready to use the TV. The first thing you should do is program your TV so it memorizes all of available channels. Your TV's memory determines the channels that are available using the CH buttons.
-
Page 14: Programming Your Tv's Channel Memory
You can change channels in three ways: The CH buttons will take you through all memorized channels, one by one. The CH buttons will not access channels that have not been pro- grammed into the TV's memory. For more information about programming channels into memory, see the section Programming your TV's Channel Memory on the previous page. - Page 15 Your TV's memory determines the channels that are available using the CH buttons. You can add channels to this memory or remove them from memory. If a channel is removed from memory, you can tune to it with the number but- tons, but you cannot tune to it with the CH buttons.
- Page 16 Normally, your TV displays the signal coming through the antenna terminal. However, If you ve connected another component to your TV(such as a VCR) using the Video/Audio input, you will want to be able to view the signal from the component. To do this, you will need to switch from the TV input to the Line Input, as follows.
- Page 17 You may wish to adjust the video settings (e. g. contrast or color) to obtain the most pleasing picture. To do so, follow these directions: With the TV on, press the MENU button. then Video menu will appear. The Settings item will be selected. Use the VOL buttons to turn Settings to Preset or Custom. Use the CH buttons to select the video setting you wish to adjust.
- Page 18 If you would like to return to the original video settings, as they were calibrated at the factory, follow these steps : With the TV on, press the MENU button. then Video menu will appear. Press the VOL buttons to set the Settings to Preset . The TV will remember the Custom settings you had previously chosen.
- Page 19 C H A P T E R Your TV has a built in-clock, and you can set the TV to turn on and off at times that you select. You can also set your TV to turn off after counting down a certain amount of time. With the TV turned on, press the MENU button until Time menu will be displayed.
- Page 20 If you enter a time in the Off time setting, your TV will automatically turn off at that time. Follow these instruc- tions to set the Off time . With the TV turned on, press the MENU button until Time menu will be displayed. Use the CH buttons to select Off time item.
- Page 21 The sleep timer allows you to set an amount of time from 15 minutes to 120 minutes. TV will count down the amount of time you set, then turn itself off. To set the sleep timer: With the TV turned on, press the MENU button until Time menu will be displayed. Use the CH buttons to select Sleep Timer item.
-
Page 22: Captioning
C H A P T E R This section contains descriptions of the more advanced features of your TV. You can choose to display the on-screen menus in English, Spanish, French. To change the on-screen language: With the TV on, press the MENU button twice, then Set-Up menu will appear. The Language item will be selected. -
Page 23: Power Restore
When the sound is muted, user can select the caption display. It will display the caption content instead of sound mute. With the TV turned on, press the MENU button until Special menu will be displayed. Use the CH buttons to select CC on Mute item. Use the VOL buttons to select C1 or C2 . -
Page 24: Parental Control Settings
This item helps parents to set the standard for the programs which their children is going to watch. With the TV on, press the MENU button until Special menu will appear. Use the CH buttons to select Parental Control item. Use the VOL buttons to enter into Parental Control settings. -
Page 25: Description Of Parental Control Settings
Description of Parental Control Settings 1. The TV Guidelines set the standard for TV programs excluding sports and news. Use the buttons to select, settings with 2. The Movie Ratings set the standard for movie, video, and other media excluding TV programs. Use the buttons to select, 3. -
Page 26: Troubleshooting
C H A P T E R Your Daewoo television is designed to give you trouble-free performance for many years. If you have a problem with your TV, try the solutions listed below. If the suggestions listed below do not solve your problem, contact your Daewoo dealer or an authorized Daewoo service center.
