- Page 1 INOZet Pendulum Bridges Original instructions in German! Keep for future use! As of: 13.07.2023 Edition: D HWR Spanntechnik GmbH Rosa-Luxemburg Straße 5 D - 28876 Oyten Phone: +49 (0) 4207 / 68 87 - 0 Fax: +49 (0) 4207 / 68 87 - 15 E-Mail: info@hwr.de...
-
Page 2: Table Of Contents
Warranty and liabaility ................... 1-1 Designated use ....................1-1 Obligations ..................... 1-1 Technical Description .................... 2-1 General information ..................2-1 ® Overview of the INOZet pendulum bridges ..........2-1 2.2.1 Installation ..................2-1 2.2.2 Description of functions ..............2-2 Installation ......................3-1 Clamping system - transport with eyebolt ............ - Page 3 6.7.2 Technical data INOZet pendulum bridges ........6-12 6.7.3 Technical data INOZet gripper jaws ..........6-13 6.7.4 Technical data INOZet soft top jaws ..........6-14 6.7.5 Technical data INOZet T-nuts ............6-14 Spare parts ......................7-1 Page II © Copyright ®...
-
Page 4: Safety
• only allow trained expert staff (specialised in metal) or CNC lathe oper- ® ators to work with the INOZet pendulum bridges. They have to be fa- miliar with the functioning of the pendulum bridges themselves as well as the functioning of the machine tool and its safety- and emergency systems and they need to know how to handle them reliably. -
Page 5: Technical Description
The pendulum bridges can be installed on the base jaws of any current chuck. ® the INOZet -clamping system must only be used with CAUTION clamping jaws of HWR Spanntechnik GmbH (see. chapter „6“ Technical Data). ® INOZ VERVIEW OF THE ENDULUM BRIDGES 2.2.1... - Page 6 Due to the doubling of the clamping points the clamping pressure is intro- duced into the workpiece more evenly and thus reduces the chance of de- formation. ® Adhere to the max. speed of the INOZet pendulum CAUTION bridges and of the chuck of the machine tool.
-
Page 7: Installation
LAMPING SYSTEM TRANSPORT WITH EYEBOLTS ® Depending on the size and weight of the INOZet - clamping system the pendulum bridges have to be installed on the chuck by using appropriate hoisting gear. -
Page 8: Installation On The Chuck
Step 2 Clean the reference area of the chuck of the machine tool and the reference area of the INOZet® pendulum bridges. There may not be any dirt or chippings in these areas. Make sure that all bore holes are clean and deburred. -
Page 9: Operation
Installation Step 4 For finding the ideal clamping position (3, Fig. 3-2) adhere to ®“ the chuck specific „instructions for INOZet (separate sheet in- cluded in the shipment). Usually the clamping position of the pendulum bridges will be found at half the travel of the base jaw. Deviations may be pos- sible due to the serration for example. -
Page 10: Clamping Of A Workpiece
Application PPLICATION CLAMPING OF THE WORKPIECE For clamping and releasing of the workpiece adhere to the correspondent chapter in the associated installationn instructions of HWR Spanntechnik GmbH. Make sure to use the correct clamping jaws: Machining For every chucking a calculation of the required... -
Page 11: Maintenance
Maintenance AINTENANCE ® In order to guarantee failure-free operation the INOZet pendulum bridges and the machine tool have to undergo regular service and maintenance. Switch off the machine tool prior to the service and maintenance operation and secure the machine from restarting (see operating manual of the ma- chine tool). -
Page 12: Technical Data
WT(S)021 - WT(S)038 - WT(S)050 - 3-jaw sets WT(S)031 WT(S)045 WT(S)125 WT(S)025-4 – WT(S)070-4 – 4-jaw sets WT(S)063-4 WT(S)050-4 WT(S)125-4 Fastenig torque [Nm] Table 6-2: Fastenig torque for fixing bolts Page 6-1 © Copyright ® INOZet Edition D HWR Spanntechnik GmbH... -
Page 13: Overview Of The Inozet Pendulum Bridges
Technical data ® INOZ VERVIEW OF PENDULUM BRIDGES ® Fig. 6-1:Overview for the technical data of the INOZet pendulum bridges © Copyright Page 6-2 ® INOZet HWR Spanntechnik GmbH Edition D... - Page 14 3,5 x 60° 1055 524-1000 470-1000 WR25 WP25 GP21 WT(S) 125-… 3,5 x 60° 1300 754-1250 700-1250 WR25 WP25 GP21 ® Table 6-3: Technical data der INOZet pendulum bridges Page 6-3 © Copyright ® INOZet Edition D HWR Spanntechnik GmbH...
-
Page 15: Technical Data Of Inozet Pendulum Bridges
GP11 WT(S)100-4-… 3,5x60° 1055 526-1000 470-1000 WR25-8 WP25-8 GP21 WT(S)120-4-… 3,5x60° 1200 526-1150 470-1150 WR25-8 WP25-8 GP21 Table 6-4: Technical data of INOZet® pendulum bridges for INOFlex ® chucks © Copyright Page 6-4 ® INOZet HWR Spanntechnik GmbH Edition D... -
Page 16: Used Symbols And Abbreviations
Centrifugal moment of the base Safety factor machining jaw of the chuck Distance between the cen- ® Total centrifugal moment of the tre of gravity of the INOZet InoZet INOZet®-pendulum bridge top jaw and the clamping surface Centrifugal moment of the INO- Maximum clamping force, Zet®-top jaws... - Page 17 According to VDI 3106 applies, this factor depends on the accuracy of the influ- encing parameters, such as the loads, tension coefficients and other influ- encing parameters. © Copyright Page 6-6 ® INOZet HWR Spanntechnik GmbH Edition D...
- Page 18 The centrifugal moment of the base jaw is to be taken from the tech- nical data. With the INOZet® pendulum bridge, the centrifugal moment of the INOZet® pendulum bridge and the INOZet® clamping jaws are added InoZet together.
- Page 19 INOZet®- InoZet InoZet pendulum bridge is to be taken from the technical data. Especially when calculating the top jaws of the INOZet® pendulum, a cor- rection factor is required because the jaws are at an angle to the base jaw.
- Page 20 (Acc. to VDI 3106) • 8660 Correction factor (see page 6-5 (application-specific) or 6-8) The calculation does not take into account the jaw fix- NOTICE ing T-nuts and jaw fixing screws. Page 6-9 © Copyright ® INOZet Edition D HWR Spanntechnik GmbH...
- Page 21 3860 1467 InoZet InoZet InoZet InoZet InoZet The centrifugal moment of the clamping jaws on the INOZet®-pendu- lum bridge is determined as follows: ...
- Page 22 2800 4055 → The calculated speed is lower than the maximum allowed speed of the − 2100 chuck and is therefore permissible. Page 6-11 © Copyright ® INOZet Edition D HWR Spanntechnik GmbH...
- Page 23 25,3907 0,2251 WT(S)031-… 5,2790 0,1119 WT(S)040-4-… 5,8376 0,1467 WT(S)063-4-… 13,6131 0,2329 WT(S)031-21-… 5,7403 0,1176 WT(S)045-… 11,5123 0,1567 WT(S)070-4-… 21,2772 0,2560 Table 6-7: Technical Data of the INOZet® pendulum bridges Page 6-12 © Copyright ® INOZet Edition D HWR Spanntechnik GmbH...
-
Page 24: Technical Data Inozet Pendulum Bridges
26,5901 0,2869 WT(S)100-… 48,0280 0,3784 WT(S)125-… 62,5171 0,4893 WT(S)080-4-… 26,0037 0,2873 WT(S)100-4-… 36,4888 0,3862 Table 6-7: Technical data of INOZet® pendulum bridges [continued] ® 6.7.3 INOZ ECHNICAL ATA FOR GRIPPER JAWS ® INOZet -gripper jaw type [kg] WU10 0,3312 0,002... -
Page 25: Technical Data Inozet Soft Top Jaws
0,2799 WP25 6,9659 WP73 9,5597 WI40 0,4187 WP25-8 6,9659 WI41 0,9551 WP50 0,6198 Table 6-9: Technical data of INOZet® soft top jaws ® 6.7.5 INOZ ECHNICAL ATA FOR NUTS T-nut type T-nut type T-nut type T-nut type [kg] [kg] [kg]... -
Page 26: Spare Parts
Locking bolt O-Ring Fastening bolt Ring bolt Pendulum element Pressure spring 1 (from WT(S)063 amount 2) Reset bolt 1 (from WT(S)063 amount 2) Retainer ring Table 7-1: Spare parts list Page 7-1 © Copyright ® INOZet Edition D HWR Spanntechnik GmbH...
