  • Page 1 Version-E231102 Manual...
  • Page 2 Important Information General Before using your ALGE-TIMING device read the complete manual carefully. It is part of the device and contains important information about installation, safety and its intended use. This manual cannot cover all conceivable applications. For further information or in case of problems that are mentioned not at all or not sufficiently detailed, please contact your ALGE-TIMING representative.

  • Page 3: Table Of Contents

    Manual Video Wall Table of Contents Part 1 Design of the Frame ..................5 The cabinet and the display ..................5 Use of installation accessories ..................6 1.2.1 The connection bracket ........................... 6 1.2.2 The Bracket ............................. 7 1.2.3 To install the positioning bar ........................7 1.2.4 The fastener ............................
  • Page 4 Manual Video Wall 3.4.2 Check communication between computer and LDU ................43 3.4.3 Read back the parameters of LDU ......................43 3.4.4 3.4 Find all the cabinets ......................... 43 3.4.5 Basic test ............................... 43 3.4.6 Check the screen’s displaying ....................... 43 3.4.7 Adjusting abnormal modules or cabinets ....................

  • Page 5: Part 1 Design Of The Frame

    Manual Video Wall Part 1 Design of the Frame 1.1 The cabinet and the display imposa® : 480mm X640mmX150mm： Dimension for the cabinet (as shown in Figure 1) Figure 1 As can be seen in the following Figure 2, a LED display screen comprises “m” rows and “n” columns of the imposa®...

  • Page 6: Use Of Installation Accessories

    Manual Video Wall In order to make the installation work much easier and more convenient, we strongly recommend the users assemble the cabinets according to the serial number that we had put on the cabinets. As the following drawing shows, we have put the number label A(0,0) at the upper right corner of the back cabinet.

  • Page 7: The Bracket

    Manual Video Wall Drawing of the backboard: Nut:2- 780-61001 Figure 5 1.2.2 The Bracket As shown in Figure 4, the bracket is used for fixing the installation plate to the pre-designed column bar. The bracket and installation plate are installed onto the square bar. When the screws are not fastened, the bracket and the installation plate can slide in four directions.

  • Page 8: The Fastener

    Manual Video Wall Users can choose either type of the bars according to the number of the cabinets and dimension of the display for positioning and connecting. For example： 2 rows of cabinets 1280 3 rows of cabinets 1920 4 rows of cabinets 1280 1280 The Connector...

  • Page 9: Input Cable Seal Pipe

    Manual Video Wall 1.2.6 Input cable seal pipe Usually, the protecting input seal pipe is on the right side of the cabinet if you look from the back side. When the screen is very wide and there are many cabinets in a row, such seal pipes are found on both sides.

  • Page 10: Ways Of Installation

    Manual Video Wall 1.3 Ways of installation 1.3.1 Single pole supporting Single pole supporting is ideal for the open area, which is flexible in installation and neat in appearance. This way of installation is less likely to be restricted by the location of installation or by the size of the display.

  • Page 11: Installed On A Platform

    Manual Video Wall 1.3.3 Installed on a platform In such way of installation, the screen is seated on a platform on a building. Under this circumstance, users have to consider the weight of the sign, wind area and the loading rate of the building.

  • Page 12: Design Of The Main Frame

    Manual Video Wall 1.4 Design of the main frame 1.4.1 Confirmation for the measurements of the display and size of the frame. The dimensions of the display are determined by the resolution of the display or by the numbers of the modules (W XH). For the convenience of installation and housing or decorative structure, the size of the frame is usually built larger than the dimensions of the （...

  • Page 13: Example Of The Design For The Main Frame

    Manual Video Wall 1.4.2 Example of the design for the main frame: The main frame refers to the frame structure for supporting and assembling the imposa® cabinets. 1.4.2.1 Materials of the main frame Under usual circumstance, the material and size of the main frame need to be determined at the installing location.

  • Page 14: Decorating The Borders

    Manual Video Wall Hoisted at site Overall effect Figure 21 Figure 22 If the display is a large one, for example, using more than 10X6 imposa® cabinets, we suggest that a thicker main frame be used. Necessary reinforcement is also desirable. Consulting an architect for professional advice on structure strength and construction is very important.

  • Page 15: Air Flow And The Heat Radiation Problem

    Manual Video Wall 1.4.4 Air flow and the heat radiation problem Generally, a display with a simple structure which is exposed to the open air without a housing or enclosure is better for dissipating heat. When a display is built inside a wall or similar surface, or is enclosed in a housing , it will be necessary to consider dissipating heat from the structure.

  • Page 16: Maintenance Access

    Manual Video Wall In order to guarantee the viewing effect, sometimes the display needs to be tilted towards the front, especially under the following 2 circumstance: 1)When the location of the display is far too high for the viewer, and the viewing angle is beyond 25°; 2) The viewing distance is restricted due to the limited space.

  • Page 17: Part 2 Installing And Connecting The Display

    Manual Video Wall Part 2 Installing and Connecting the Display 2.1 Install the horizontal fastener First of all, the client should make sure that the fastener itself is positioned horizontally. Then fix the installation plates to the fastener. The installation starts with the 1 row of the cabinets from the bottom.
  • Page 18 Manual Video Wall Fix to the frame. Be sure the connecting bars are level. Front View Back View Figure 30 Page 18...
  • Page 19 Manual Video Wall Connection of the bars Figure 31 Users should make sure that all fastener and the connectors are vertical and horizontal before they can go on with the next step. Page 19...

  • Page 20: Install The 1St Cabinet

    Manual Video Wall 2.2 Install the 1st cabinet The principle of installing the cabinets: from the bottom to the top. From left to right or from the right to the left if the cabinets are in the same row. As the following drawing shows, when installing, first of all, put the Am-n cabinet on the left side of the frame.

  • Page 21: Install The Cabinets Of The

    Manual Video Wall Figure 33 Users should make sure that the cabinet is vertical and horizontal before they can go on with the next step. 2.3 Install the cabinets of the 1 Fig 34 Users should make sure that the cabinets are vertical and horizontal before they can go on with the next step.

  • Page 22: Install The Other Cabinets

    Manual Video Wall 2.4 Install the other cabinets Users can install the other cabinets in the same way as they install the 1 row. Figure 35 2.5 Install the water-proof seal pipe among the cabinets The drawing of the seal is shown below： seal seal Figure 36...

  • Page 23: Connect The Signal Cables

    Manual Video Wall 2.6 Connect the Signal Cables 2.6.1 Signal wiring block diagram A(0,0) A(1,0) A(n-1,0) CON2 CON2 CON2 CON3 CON3 CON3 CON3 CON3 CON3 CON2 CON2 CON2 CON2 TX+ R TX+ R TX+ R TX- B TX+ R TX- B TX- B RS+ G TX- B...

  • Page 24: Instructions And Installation For Ldu3000 /Ldu3000A

    Manual Video Wall 2.6.2 Instructions and Installation for LDU3000 /LDU3000A LDU3000 is not a water-proof product. It can only be used indoor. Figure 38 LDU3000A is built as a water proof instrument and can be used in the outside environment. It is usually placed at the mid-right position if you look from back of the screen.

  • Page 25: Signal Wire Connection Among Cabinets

    Manual Video Wall 2.6.3 Signal Wire Connection among Cabinets Signal wires are transmitted in the direction of row. Viewed from the back of the display, the signal wire begins with the first cabinet in the right, and concatenated to the left. A(1,0) A(0,0) A(n-1,0)

  • Page 26: Ldu3000/Ldu3000A-Display Connection

    Manual Video Wall 2.6.4 LDU3000/LDU3000A-Display Connection A(0,0) A(0,0) CON2 CON2 CON3 CON3 CON3 CON3 CON2 CON2 TX+ R TX+ R TX- B TX- B RS+ G RS+ G RS- Y RS- Y A(0,1) A(0,1) LDU3000A HUB Box CON2 CON2 CON3 CON3 CON5 CON3...

  • Page 27: Connection Between Lud3000/Ldu3000A And Light Sensor

    Manual Video Wall 2.6.5 Connection between LUD3000/LDU3000A and Light Sensor 1) Light Sensor Figure .43 2) LUD3000 Insert the provided light sensor directly to the Sensor socket behind LDU3000. As shown in the following figure. CHANNEL 1 CHANNEL 2 Figure.44 3) LUD3000A Insert the provided light sensor directly to the Sensor socket behind LDU3000A.

  • Page 28: The Communication Between Ldu3000/A And The Pc

    Manual Video Wall 2.6.6 The communication between LDU3000/A and the PC CON5 QS5003 TABLE OF SEL COM1 MODE RS232 CON8 CON9 CON1 CON7 OPEN RS485 COM2 COM1 SENSOR LUM SENSOR DC 5V • LDU3000/A' mainboard-QS5003.There are two separate COM ports in the mainboard COM1: RS232&RS485;...
  • Page 29 Manual Video Wall 3） RS232 connection This drawing shows the RS232 connection by using COM 1： CON5 QS5003 TABLE OF SEL COM1 MODE RS232 CON8 CON9 CON1 CON7 OPEN RS485 COM2 COM1 SENSOR LUM SENSOR DC 5V This drawing shows the RS232 connection by using COM 2： CON5 QS5003 TABLE OF SEL...
  • Page 30 Manual Video Wall 2.6.6.2 RS485 Communication CON5 QS5003 TABLE OF SEL COM1 MODE RS232 CON8 CON9 CON1 CON7 OPEN RS485 COM2 COM1 SENSOR LUM SENSOR DC 5V 2.6.6.3 Ethernet Communication Under the off line system, users can connect the Ethernet wire to the CON1 in mainboard 5003 of LDU300/A.

  • Page 31: Instructions And Connection For Vpu3000

    Manual Video Wall 2.6.7 Instructions and Connection for VPU3000 Illustration of the Back Connection for VPU3000 Optical fiber access indicator DVI indicator Power supply input: AC110V/220V Ventilation fan outlet RS232 port to the PC USB port to the PC “CHANNEL1”: Optical fiber output port. It is connected to LDU3000 for data transmission.
  • Page 32 Manual Video Wall 2.6.7.1 Optic Fiber Connection between VPU3000 and LDU3000 For the data output, there are two optic fiber interfaces. One is for data sending, and the other is for hot backup. LDU 300 0 SENSOR ETHERNET CHANNEL RS485 D- D+ Fiber optic VPU 3000...
  • Page 33 Manual Video Wall RS232: VPU 3000 OUTPUT INPUT CVBS 1 CVBS 2 S_VIDEO AC INPUT 84~260V RS232 CVBS 4 CVBS 3 RS232 Figure 50 2.6.7.4 Connection between VPU3000 and Video Sources For VPU3000, there are two video input channels, each of which has one video signal input. When the two video signals are input at the same time, the function of picture in picture can be realized.

  • Page 34: Connection Of Power Cords

    Manual Video Wall 2.7 Connection of Power Cords 2.7.1 General Block Diagram of Power Cable Connections POWER IN POWER INPUT POWER INPUT POWER INPUT POWER INPUT AC Input 3 phases 5 lines L N G L N G L N G L N G A(1,0) A(0,0)
  • Page 35 Manual Video Wall Principle Chart of the 25KW Distribution Box: L1 L2 L3 PSU-25 LDU3000A POWER IN PL N G PL N G Remote PL N G PF N G 2 N G 3 N G 4 N G 5 N G 6 N G 7 N G 8 N G 9 N G Jout POWER PL(LUD300A)
  • Page 36 Manual Video Wall Principle Chart of the 40KW Distribution Box: Main Switch 3Phases 80A OBO 3Ph L1 L2 L3 POWER IN KM1,2,3 Contactor X5 TE 2510 110V KT1,2 Timer X4 30 S Remote & Next Con X2 UK5N Lamp X1 110V Green Switch X1 NO Turning JOUT...

  • Page 37: Connection Of Cabinets

    Manual Video Wall “N” imposa® cabinets can be connected to the distribution box. As the following table shows: Table 2 pitch 10mm 13.3mm 16mm 17.7mm 20mm 26.7mm 32mm 40mm parameter pixels on each standard 48X64 36X48 30X40 27X36 24X32 18X24 15X20 12X16 cabinet...
  • Page 38 Manual Video Wall Due to the different pitches of each cabinet, the power consumption of each cabinet is different accordingly. For the number of allowed concatenated cabinet please consult the number of driven cabinets for each output of the distribution box. If the number of cabinet in row is more than that of the above mentioned, then one should lead the wires from both sides of the cabinet and cascade them toward the midst.

  • Page 39: Connection Check

    Manual Video Wall When we are leading the power supply cables from one cabinet to another, we must make sure that the cables do not block the closure of the cabinets. The cables should be led from the air intake hood in the bottom part of the cabinets. It is better to sheaf the cable with the binding-wire in the middle, as the following photo shows.

  • Page 40: Part 3 Commissioning And Maintenance Of The Display

    Manual Video Wall PART 3 Commissioning and Maintenance of the Display 3.1 Commissioning the Synchronous Display Check Status Connections of power supply for the screen, LDU, VPU and video sources equipment Signal sources connected to VPU Monitor Before power is applied to all the equipment Optic fiber Wire connections among cabinets...

  • Page 41: Start Up Computer And Vpu

    Manual Video Wall Item Connect to DVI output of computer Input DVI input of monitor Output VGA output of computer Input CVBS CVBS output of video sources Input S-Video output of computer or video S-Video Input sources YPrPb Y, Pr, Pb output of video sources Input TABLE 1.3 Video sources connected to VPU 3.3 Start up Computer and VPU...

  • Page 42: Search For Valid Video Sources

    Manual Video Wall 3.3.3 Search for valid video sources VPU3000 control software is required. For details please consult User's Manual for VPU3000 Control Software,6.2.1 Search Signal. • Click the “Search Signal” button in advanced setting to switch to the signal search interface.

  • Page 43: Power Up The Screen

    Manual Video Wall 3.4 Power up the Screen 3.4.1 Check if the cabinets and LDU are powered up, see TABLE 3.1 Item Check If the red and green LED indicators (STATUS and RUN) at the back Cabinets of the cabinets are twinkling are electrified If the indicators of the switch inside the cabinets are lighted If the red indicators beside optic fiber port at the back of VPU is...

  • Page 44: Adjusting Abnormal Modules Or Cabinets

    Manual Video Wall 3.4.7 Adjusting abnormal modules or cabinets Imposa Tools software is required. For details please consult User's Manual for Advanced Setting Up Software of Standard Cabinet, 6.7.3, Adjusting of Basic Color • Keep playing the screen. In the layout viewing window, select to adjust basic colors.

  • Page 45: Troubleshooting Of The Synchronous Display

    Manual Video Wall 3.6 Troubleshooting of the Synchronous Display 3.6.1 Common Malfunctions List 3.6.1.1 When communication part Phenomena Solution cann’t PC cann’t communicate with VPU communicate with VPU cann’t communicate with LDU Start up VPU, and check the power supply for VPU hasn’t be started VPU.
  • Page 46 Manual Video Wall 3.6.1.2 The LED Display Screen Body Phenomena Solution VPU or LDU can’t Check VPU or LDU. work. No input signals. Check the input signals. There is no display on The communication Check the video data communication. See ” VPU can’t the screen video data...
  • Page 47 Manual Video Wall Video window is too Set it bigger. small select It is normal. The content of DVI and video will overlay mode of with each other. Adjust the window’s site or choose other POP-DVI on top. mode. Show of other video Video equipment Check...
  • Page 48 Manual Video Wall 3.6.1.3 Cabinets of the display Phenomena Solution No display on several These cabinets are Look from the back side. Check power supply of dark neighboring cabinets in powered. cabinet and its right side neighboring cabinet. a row Cabinets are not Check the power supply of the first cabinet in the left powered.

  • Page 49: Trouble Shooting

    Manual Video Wall Power supply for the modules Change power is broken. supply. Signal wire connected to this Change the signal wire. cabinet damaged. Control board Change the control board. broken. show See “No show on a certain module”. certain module. Abnormal show on See “Abnormal show on a certain module”.
  • Page 50 Manual Video Wall amount of the cabinets are correct or not. The correct address of the cabinets should be continuous in number, ranging from 1, 2, 3……n-1. If you find that the amount of the number in the software is less than the actual cabinets, you can refer to “Layout” to find out the position of the faulty cabinets.
  • Page 51 Manual Video Wall 3.6.2.2.3 PHY Physical network You can test the problem by using the software--- “Advanced Setting of Full Color LED Display”. After you run this software, under the sub-menu of “advanced setting” –“Basic information,” choose the operation “Refresh”, then you will get the “layout” and “List” information of the cabinets.

  • Page 52: Repair And Maintenance

    Manual Video Wall to restore the setting. Under the interface of “Update & Repair”, choose the address of the main board that needs renovating from the address column, and the data of γ correction. For detailed information, please refer to the user’s manual “Update and Repair” 3.6.2.3.6 The problem of chaotic display on the whole screen or some pixels out of control on every cabinet...
  • Page 53 Manual Video Wall 3.6.3.2 Replace the modules • Turn off the power. Pull out the signal cable and the DC connector. • Loosen the installation screws of the module then take these old modules out. • Put the new modules in. Fasten the screws again. •...
  • Page 54 Manual Video Wall • Set the address and the model of the driver board. You can refer to the old control board to set the correct DIP switch and the driver board number. The setting will be explained in the following chapter. •...
  • Page 55 Manual Video Wall Pulling out the optical fiber connector, Step by the follow Step 1 Step 2 Step 3 Step 4 Step 5 Step 6 Inserting in the connector, Step by the follow Step 1 Step 2 Step 3 Page 55...

  • Page 56: Commissioning An Off-Line Led Display

    Manual Video Wall 3.7 Commissioning an Off-line LED Display Checking steps Phenomena Power supply of the display. LDU power supply Turn on the power Wire connection among the cabinets of all equipments Wire connection between the computer and LDU Check if the cabinets and LDU are powered or not Check if the communication between the computer and LDU is normal or not Read back the LDU parameter...

  • Page 57: Turn On The Computer And The Display

    Manual Video Wall Connector main Kind of link Note board COM1 RS232 RS232 When “SEL” connect to GND COM2 RS485 When “SEL” open CON8(RJ45 interfacing) Ethernet 10M/100M auto switch TABLE 5.3 Communicating cable that connects to LDU 3.7.2 Turn on the computer and the display 3.7.2.1 Check if all the cabinets are powered or not.

  • Page 58: Back Up (Ldu To Pc)

    Manual Video Wall 3.7.2.5 Basic test Please use the” Imposa Tools software” and refer to the user’s manual of “Advanced Setting of a Full Color LED Display” Chapter 6.74 Basic test Select all of the tiles, and do the Row scan and the Col scan test. 3.7.2.6 Sending the information to the screen to check the screen Please use the”...

  • Page 59: Trouble Shooting Of The Off-Line (Asynchronous) Display

    Manual Video Wall 3.8 Trouble Shooting of the Off-line (asynchronous) Display 3.8.1 A quick check list for common problems Communication Phenomena Solution VPU doen’t start Turn on VPU, and check the Power Input of VPU User didn’t choose the correct port Choose the correct com port communicating with VPU.
  • Page 60 Manual Video Wall Change the IP address of the PC, so that it can be in the The IP address same network area with the of the PC and LDU are not in Change the IP address of LDU same through the com port, and network field make it in the same network...
  • Page 61 Manual Video Wall control Change the control card. card is broken power supply of the display Change the power supply. module broken. All the cabinets in a signal row just show ”X” cable from or chaotic display Connect the signal cable well. cabinet loose signal...
  • Page 62 Manual Video Wall signal cable connected Change that signal cable the cabinet is broken. Control card is Change that control card broken Some display module doesn’t Refer to ”” some display module doesn’t work” show anything Some display module show Refer to ””some display module work abnormally”...

  • Page 63: Trouble-Shooting Instruction

    Manual Video Wall 3.9 Trouble-shooting instruction 3.9.1 System control data communication 3.9.1.1 RS232/485 communication If user uses RS232 to communicate, but the communication fails, please check the Com port and the baud rate, whether the signal cable is correct or whether it is broken. Especially, COM2 in LDU is selectable.

  • Page 64: Display Data Communication

    Manual Video Wall 3.9.2 Display data communication PHY Physical network The errors and their locations can be inspected and found through “RGB Full Color Display Advanced Setting” software. In the “Basic Information” interface of “RGB Full Color Display Advanced Setting” software, choose “Refresh”. Refer to “Layout” and “List”, judge whether the connection in cabinet PHY physical communication is correct or not according to “Ethernet connection condition”...

  • Page 65: Recovery And Maintenance

    Manual Video Wall card drive board data”, then click “Recover”. For more detail, please refer to “Upgrade and recover” function of “Full color display advanced setting”. 3.9.3.6 Chaotic display of the whole screen or some pixels in every cabinet are out of control The display was set to be VGA mode, change it to be Off-line mode.

  • Page 66: Replacement Of The Display Module

    Manual Video Wall 3.10.2 Replacement of the display module • Cut the power of the LED screen, drag out the signal cable and DC power cable of the bad display module • Loosen the screws and take out the bad display module •...

  • Page 67: Replacement Of Ldu3000

    Manual Video Wall instruction for address and switch settings. • Restart LDU3000. LDU3000 will inspect whether the data in the control card is normal or not automatically; if it is abnormal, the data saved in LDU3000 will be automatically upgraded to the control card. •...

  • Page 68: Appendix: Instructions For The Function Of The Main Control Board

    Manual Video Wall Appendix: Instructions for the Function of the Main Control Board 4.1 Instructions for the control board QS5002L in the imposa ® cabinet 4.1.1 Layout Data out Data input Power check port Indicator signal out 780-65001 Function Power input Control Signal Signal...

  • Page 69: Instructions For The Interface Functions Of The Control Board Qs5002

    Manual Video Wall 4.1.2 Instructions for the Interface Functions of the Control Board QS5002 P1~P6: VCC output, connected with LED board, provides power to IC on LED PCB CON2: digital signal input CON3: digital signal output JP7: power input, 5-12V JP2 JP4: FAN port JP12: signal output of the indicator lamp J7：Power check port...

  • Page 70: Instructions For The Ldu3000 Hub Board Qs5003

    Manual Video Wall 4.2 Instructions for the LDU3000 HUB Board QS5003 4.2.1 Layout Fiber optic port Add.DIP SW1 Power COM2 port COM1port Data out port Light sensor Light, temp, hum port Ethernet Data port port Fig 59 4.2.2 Instructions for the Interface ports P1-P16: Data output interfaces，connect respectively with the input signal of the control board of the first cabinet in each of the display’s row.

  • Page 71: Annexed Table: Technical Parameters Of The Cabinet Imposa

    Manual Video Wall 4.3 Annexed Table: Technical Parameters of the Cabinet imposa® Pitch 10mm 13.3mm 16mm 17.7mm 20mm 26.7mm 32mm 40mm Parameter Composition of LED 1R1G1B 2R1G1B 4R2G2B Size of module(mm) 160X320 Pixels on one module 16X32 12X24 10X20 9X18 8X16 6X12 5X10...

  • Page 72: Annexed Graph: System Block Diagram

    Manual Video Wall 4.3.1 Annexed Graph: System Block Diagram SENSOR ETHERNET Fiber optic INPUT OUTPUT CVBS 1 CVBS 2 GND TXD S_VIDEO AC INPUT 84~260V RS232 CVBS 4 CVBS 3 DVI OUT DVI IN RS232 VGA IN Instructions: In the graph, there are 64X48 pixels on one cabinet. Due to different pitches, the pixels on the imposa®...

  • Page 73: Items And Part Numbers

    Manual Video Wall 4.4 Items and Part Numbers Item Figure Model Part No Remark MD10-48X64-1R1G1B 781-01000 Pitch 10mm MD13-36X48-1R1G1B 781-01300 Pitch 13.3mm MD16-30X40-1R1G1B 781-01600 Pitch 16mm MD17-27X36-1R1G1B 781-01700 Pitch 17.7mm Cabinet Display MD20-24X32-1R1G1B 781-02000 Pitch 20mm MD26-18X24-1R1G1B 781-02600 Pitch 26.7mm MD32-15X20-2R1G1B 781-03200 Pitch 32mm...
  • Page 74 Manual Video Wall AC110V PSU-10A 781-10008 Output Distribution Box 10KW PSU-10 AC220V PSU-10B 781-10009 Output RS485 USB-RS485 781-10010 converter MO10-10-1R1G1B 780-01002 Pitch 10mm MO13-13-1R1G1B 780-01302 Pitch 13.3mm MO13-16-1R1G1B 780-01602 Pitch 16mm MO13-17-1R1G1B 780-01702 Pitch 17.7mm MO13-20-1R1G1B 780-02002 Tile Pitch 20mm MO13-26-1R1G1B 780-02602 Pitch 26.7mm...
  • Page 75 Manual Video Wall Connection bar 780-61005 Water-proof cannula QS-PG21 780-62001 pipe Water-proof cannula EH-PG21 780-62002 pipe(stright) Water-proof cannula KW-PG21 780-62003 pipe(elbow) Signal wire 4X24AWG 780-63101 1（L=1m ） Signal wire 4X24AWG 780-63102 2（L=10m ） Signal wire 4X24AWG 780-63103 3（L=10m ,with joint） Power 3X12AWG 780-63201...
  • Page 76 Manual Video Wall L=180 780-63301 L=220 780-63302 L=480 780-63303 2P Signal wire L=530 780-63304 L=600 780-63305 L=700 780-63306 L=150 780-63401 L=250 780-63402 12P Signal wire L=500 780-63403 L=600 780-63404 3P Signal wire L=900 780-63501 Cat.5 L=10m 780-63601 RS232 Cable L=5m 780-63602 Indoor Optic L=50m...
  • Page 77 Manual Video Wall Fan component AVP-925H12 780-64007 Connect to Power input YC10T1 780-64008 (PS-45) +(S- component 1 210(320)) Connect to S- Power input YC10T1 780-64009 component 2 +(S-210(320)) Power input Connect to S- YC10T1 780-64010 component 3 Indicator component QS5099 780-64011 Main board QS5002 QS5002L...
  • Page 78 Manual Video Wall S-150-12 780-66212 S-210-5 780-66305 S-320-5 780-66405 2P Direct plug MSTBVA2.5/2-G-5.08 780-67001 4P Direct plug MSTBVA2.5/4-G-5.08 780-67002 Sealing strip for cabinet L=2000mm 780-67003 Sealing strip for back L=1390mm 780-67004 cover Keys 780-67005 Page 78...

  • Page 79: Bolts Used In Imposa Box

    Manual Video Wall ® 4.5 Bolts Used in Imposa Ser No Description Drawing Usage M3x6 Cruciform slot cone Stainless. For the installation of head screw the air outtake hood Stainless. For the fixation of the Cross recessed pan head 2 air outtake hoods together, crew with flake main board, PS-45 power supply, power supply hood.
  • Page 80 M10x50 Hexagon socket stainless stud bolt Fixer for the bracket and the Ф10 stainless washer positioning and connecting bars. Ф10 stainless washer Subject to changes and misprints ALGE-TIMING GmbH Rotkreuzstraße 39 A-6890 Lustenau Austria Tel: +43-5577-85966 Fax: +43-5577-85966-4 office@alge-timing.com www.alge-timing.com...
