- Page 1 AC-AVDM-V3 18 G (4K60 4:4:4 HDR) Audio Down-mixer Video & with Downscaling ® ® Dolby Atmos DTS:X Support User Manual...
-
Page 2: Table Of Contents
Commented [RK1]: Change DTS:HD to DTS:X logo Contents Contents ......................................2 Important Safety Instructions ..............................3 Safety Classifications in this Document ..........................3 Electrical Shock Prevention ..............................3 Weight Injury Prevention ................................. 3 Introduction ....................................4 Key Benefits ....................................4 Features ..................................... -
Page 3: Important Safety Instructions
Important Safety Instructions Before installing, configuring, and operating this device and other vendor equipment, AVPro Edge strongly recommends that each dealer, integrator, installer, and all other necessary personnel access and read all the required technical documentation, which can be located by visiting AVProEdge.com. Read and understand all safety instructions, cautions, and warnings in this document and the labels on the equipment. -
Page 4: Introduction
Introduction In the AVPro Edge AC-AVDM-V3, the multichannel bitstream of an HDMI signal is decoded, then combined to create a downmixed secondary output for distribution by 2-channel audio systems. Commented [RK2]: Bypass refers to passthrough Downmixing is necessary when a multichannel signal is required to be sent through as few as two speakers, with no operation. -
Page 5: Features
Toggle Switches for simple EDID Management, Downmixing, and Scaling. • Micro-USB ISP for field firmware updates Product Overview Box Contents (1x) AC-AVDM-V3 (Unit) (1x) 5V/2A Locking Barrel Power Supply (1x) Type A Plug-in Outlet Attachment (2x) Mounting Brackets (4x) Mounting Screws (4x) Rubber Feet WWW.AVPROEDGE.COM •... -
Page 6: Technical Specifications
Technical Specifications Video Video Resolutions Up to 4K 60Hz 4:4:4 VESA Resolutions Up to DCI 4K (4096 x 2160) 4:2:0, 4:2:2, 4:4:4 (10- and 12-bit deep color) HDR Formats/Resolutions HDR10, HDR10+, HLG, Dolby Vision™ YUV (Component), RGB (CSC: Rec. 601, Rec. 709, BT2020, DCI, Color Space P3 D6500) Chroma Subsampling... -
Page 7: Front And Rear Panels
Front and Rear Panels Front Panel Rear Panel • When illuminated each blue LED shows the incoming audio signal type: PCM: indicates an active audio signal is being detected/decoded 1 Audio Detection LEDs DTS: indicates DTS bitstream audio is being detected/decoded DOLBY: indicates Dolby ®... -
Page 8: Installation
LED indicators will flash once, indicating the AC-AVDM-V3 has powered on. Power on the source device. Connect an HDMI cable to the HDMI INPUT port on the AC-AVDM-V3. The front panel SYSTEM STATUS IN LED will illuminate solid blue, indicating an active source is connected. -
Page 9: Dipswitch Settings
Dipswitch Settings Each dipswitch located on the AC-AVDM-V3 front panel corresponds to one control setting. Dipswitch UP position = OFF Dipswitch DOWN position = ON Audio Source Select Button Operation The AUDIO SOURCE SELECT button, located on the front panel, controls the extracted audio modes as indicated... -
Page 10: Front Panel Indicator Lights
OUT 2: Indicates HDMI OUTPUT 2 is active/connected If the LEDs are flashing or not illuminating, and there is no image on the display, verify the following: Bypass the AC-AVDM-V3 and plug the source directly into the display to confirm both are functioning properly. -
Page 11: Serial Communication
Serial Communication For communication with the AC-AVDM-V3, connect a micro-USB data cable to the USB ISP port located on the rear panel. The Serial-to-USB is internal and the required drivers (universal CH340 driver) will automatically install once plugged in. Set the Serial Communication protocols to:... -
Page 12: Troubleshooting
Troubleshooting • Verify Power – Confirm the power supply is properly connected and is outputting 5V. • Verify Connections – Confirm all cables are properly connected and/or terminated where applicable. • Verify Source Device – Confirm the source device is powered on and all mute settings are disabled. Maintenance To ensure the reliable operation of this device as well as protect the safety of any person using or handling this device when powered on, observe the following instructions:... -
Page 13: Warranty
Warranty The Basics AVPro Edge warranties products it manufactures and sells when purchased directly from AVPro Edge or an authorized AVPro Edge reseller. Products are guaranteed to be free from manufacturing defects and in sound physical and electronic condition when shipped by AVPro Edge. AVPro Edge has developed a warranty everyone can get behind. -
Page 14: Obtaining An Rma
Obtaining an RMA Dealers, resellers, and installers can request an RMA (Returned Merchandise Authorization) from an AVPro Edge Technical Support rep or Sales Engineer. Or you may email support@avproedge.com or fill out the general contact form at www.avproedge.com/contact. End users may not request an RMA directly from AVPro Edge and will be referred back to the dealer, reseller, or installer. - Page 15 Trademark Acknowledgements and License Notices Dolby, Dolby Atmos, and the double-D symbol are registered trademarks of Dolby Laboratories Licensing Corporation. Manufactured under license from Dolby Laboratories. Confidential unpublished works. Copyright © 2012-2021 Dolby Laboratories. All rights reserved. For DTS patents, see http://patents.dts.com. Manufactured under license from DTS, Inc. or DTS Licensing Limited.
- Page 16 WWW.AVPROEDGE.COM • 2222 EAST 52 STREET NORTH • SIOUX FALLS, SD 57104 • +1-605-274-6055...
