AV Pro Edge AC-MAX-24 User Manual

AV Pro Edge AC-MAX-24 User Manual

24 i/o stereo audio matrix with audio extension

Advertisement

Quick Links

24 I/O STEREO AUDIO MATRIX
AUDIO EXTENSION
WITH
AC-MAX-24
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC-MAX-24 and is the answer not in the manual?

Questions and answers

Summary of Contents for AV Pro Edge AC-MAX-24

  • Page 1 24 I/O STEREO AUDIO MATRIX AUDIO EXTENSION WITH AC-MAX-24 User Manual...
  • Page 2: Table Of Contents

    I/O Config ......................................... 19 Stereo Audio Input Settings ................................19 Stereo Audio Output Settings ..............................19 Audio Configuration ..................................20 Equalizer ....................................... 20 Trigger Output Settings .................................. 21 System ........................................22 IP Settings ......................................22 Page 2 of 33 AC-MAX-24 USER MANUAL...
  • Page 3 Support .......................................... 31 Warranty ........................................31 The Basics ......................................... 31 Coverage Details ....................................32 Red Tape ........................................32 Obtaining an RMA....................................32 Shipping ........................................32 Limitation on Liability ................................... 33 Exclusive Remedy ....................................33 Page 3 of 33 AC-MAX-24 USER MANUAL...
  • Page 4: Important Safety Instructions

    Weight Injury Prevention WEIGHT INJURY: Installing some of the MXNet devices requires two installers to ensure safe handling during installation. Failure to use two installers may result in injury. Page 4 of 33 AC-MAX-24 USER MANUAL...
  • Page 5 The devices and their accessories should never be exposed to open flames or excessive heat. Page 5 of 33 AC-MAX-24 USER MANUAL...
  • Page 6: Introduction

    (such as a vinyl player) or extend audio out to a remote zone (such as a guest house or room with a local soundbar). The diagram below shows the basic application of the AC-MAX-24. The audio path can either come from the audio sources directly or from remote audio sources via the AC-AEX-KIT as shown below.
  • Page 7: Product Overview

    PRODUCT OVERVIEW Box Contents (1x) AC-MAX-24 Stereo Audio Matrix (2x) 2U Rack Mounting Brackets (pre-attached) (1x) 3-Pin Terminal Block Connector (4x) Mounting Feet (4x) Mounting Feet Screws (1x) Ground Wire (1x) AC Power Cord Technical Specifications Audio Frequency Response 20-20 kHz Analog Input Voltage 0.8 V...
  • Page 8: Front And Rear Panel Overview

    (2x) Digital Optical (TOSLINK) audio input ports 12V TRIGGER OUT • (4x) 3.5mm output ports AC POWER INLET • Main AC power for the AC-MAX-24 AEX OUTPUTS (1-2) • (2x) 8-pin RJ-45 female connector • Long-range audio extension input ports for connecting AC-AEX-KIT •...
  • Page 9 3-pin terminal block connector port ISP / CTL USB TYPE-C • Proprietary service port for AVPro Edge technical assistance • Ground screw • Connect with the provided ground wire to the conducting parts Page 9 of 33 AC-MAX-24 USER MANUAL...
  • Page 10: Installation

    INSTALLATION Rack Mounts The AC-MAX-24 can be mounted in a 2U rack-style enclosure and is compatible with all standard 19-inch rack mounts. The (2x) mounting brackets are pre-assembled to the unit for quick installation. Align the holes on the mounting brackets with the holes on both sides of the rack.
  • Page 11: Wiring And Connections

    WIRING AND CONNECTIONS Audio Connections AVPro Edge recommends using shielded RCA interconnected cabling between the AC-MAX-24 and connected analog devices to maintain a high level of audio performance. The diagram below shows the audio connections of the AC-MAX-24: Page 11 of 33...
  • Page 12: Rs-232 Control

    LAN Wiring The IP control port located in the bottom right corner on the rear panel is used to communicate with the AC-MAX-24 via a LAN, router, or third-party control system processor. For TCP/IP control, commands use Telnet Port 23.
  • Page 13: Initial Setup

    Make the physical connections to the input and output devices using the following steps below. For initial setup, it is recommended to connect the AC-MAX-24 to a LAN (Local Area Network) using a control PC on the same network once all the physical connections are made, followed by accessing the Web UI and checking for any firmware updates to the unit.
  • Page 14: Locating The Ip Address

    Accessing the Web UI The AC-MAX-24 features the built-in AVPro Edge User Interface (AEUI) that can be accessed through a web browser for configuration and control. For initial setup, it is recommended to connect the AC-MAX-24 to a local area network (LAN) with a computer on the same network to access the built-in Web UI and check for any firmware updates to the unit.
  • Page 15 From this screen, newer versions of firmware can be viewed before they are installed. Select the Upgrade button. The unit will now begin installing the latest versions of firmware. DO NOT refresh the webpage or power off the unit during the update. Page 15 of 33 AC-MAX-24 USER MANUAL...
  • Page 16 Once the progress bar reaches 100%, select the Close button and refresh the webpage. The unit will automatically reboot once the firmware updates are complete. After the unit reboots, refresh the webpage to verify that the firmware update was successful. Page 16 of 33 AC-MAX-24 USER MANUAL...
  • Page 17: Navigating The Web Ui

    NAVIGATING THE WEB UI The AC-MAX-24 features the built-in AVPro Edge User Interface (AEUI) that can be accessed through a web browser for configuration and control. Different tools and settings can be selected from the tab pages located on the navigation menu column on the left side of the screen.
  • Page 18: Matrix

    From the Outputs grid, select the desired output(s) to route the selected input to. This will highlight the output(s) with a green border to indicate the selection was made. The selected input’s audio signals are now routed to the selected output(s). Page 18 of 33 AC-MAX-24 USER MANUAL...
  • Page 19: I/O Config

    Select the toggle switch to enable or disable the audio output. Volume Adjust the volume by using the slider bar or entering a value (0~100) in the text field. Select to view the output’s Audio Configuration settings. Page 19 of 33 AC-MAX-24 USER MANUAL...
  • Page 20: Audio Configuration

    -10 is balanced left, 0 is balanced, and +10 is balanced right. Equalizer The AC-MAX-24 includes a digital 5-band parametric equalizer (EQ) with 29 presets and 24 user EQ profiles to enhance listener experience. EQ’s 1-27 consist of various combinations of bass, midrange, and treble attenuations in increments of 6dB up to a total of 12dB.
  • Page 21: Trigger Output Settings

    Trigger Output Settings The AC-MAX-24 is equipped with four 12V trigger ports that can be configured to automatically turn on/off an amplifier or AV receiver. The trigger port will continuously output 12 VDC when enabled and an audio signal is detected at any assigned audio output. When active, the trigger port will continue to output 12 VDC until no audio is detected at all assigned audio outputs for a minimum duration of the set Timeout period or when the trigger is disabled.
  • Page 22: System

    Shows the unit’s IP address. Subnet Mask Shows the unit’s subnet mask. Gateway Shows the unit’s default gateway. Primary DNS Shows the unit’s primary domain name server. Secondary DNS Shows the unit’s secondary domain name server. Page 22 of 33 AC-MAX-24 USER MANUAL...
  • Page 23: Ip Control

    With the Admin Web Interface enabled, the only menu that will be accessible on the Web UI will be the Matrix tab page. The rest of the settings will require the Admin login. Default username: admin Default password: admin Page 23 of 33 AC-MAX-24 USER MANUAL...
  • Page 24: User Web Interface

    Matrix tab page. The rest of the settings will require the Admin login. Default username: user Default password: user123 Hardware This section shows the unit’s current firmware versions and provides options for updating firmware, factory resetting the unit, and rebooting the unit. Page 24 of 33 AC-MAX-24 USER MANUAL...
  • Page 25: Cloud Services

    Enable Cloud Services toggle setting. IMPORTANT: This is a required step in order for the unit to perform OTA firmware updates. In the Hardware section, select the Update Firmware button. A new dialog box will open. Page 25 of 33 AC-MAX-24 USER MANUAL...
  • Page 26 Once the progress bar reaches 100%, select the Close button. The unit will automatically reboot once the firmware updates are complete. After the unit reboots, refresh the webpage. Page 26 of 33 AC-MAX-24 USER MANUAL...
  • Page 27: Console

    Web UI is opened to the Console tab page and does not record or store information internally. Clear Console Select to clear the information recorded in the console log. Page 27 of 33 AC-MAX-24 USER MANUAL...
  • Page 28: Command List

    Set EQ Mode x Band Frequency, Gain, and Q values {x=30~53, y=1~5, f=1~24000, g=-12.0~12.0, q=0.1~10.0} GET OUTx EQ Get Output x EQ {x=[0-24](0=All)} GET EQy BANDy Get EQ Mode x Band Frequency, Gain, and Q values {x=30~53, y=0~5 (0=All)} Page 28 of 33 AC-MAX-24 USER MANUAL...
  • Page 29 Set DHCP {y=[0~1](0=Dis,1=Enable)} GET RIP Get Route IP Address GET HIP Get Host IP Address GET NMK Get Net Mask GET TIP Get TCP/IP Port GET DHCP Get DHCP Status GET MAC Get MAC Address Page 29 of 33 AC-MAX-24 USER MANUAL...
  • Page 30: Troubleshooting

    TOSLINK port. Static, Buzzing, or Humming Noises - Use shielded RCA cabling between the AC-MAX-24 and the • connected analog devices to maintain a high level of audio performance. Ground the matrix to the conducting parts (equipment rack, mounting devices, truss systems, electrical switchboards, metal electrical conduits, etc.) This technique ensures all the equipment in an electrical system will use the...
  • Page 31: Damage Requiring Service

    If it’s broken, we will replace it in advance on our dime and we’ll also cover the return shipping. • Repair is an option too, but it’s YOUR call. We know you know what you are doing. We will not make you go through unnecessary steps to • troubleshoot an extender… Page 31 of 33 AC-MAX-24 USER MANUAL...
  • Page 32: Coverage Details

    For International (and Alaska and Hawaii) return shipping costs will be the responsibility of the returnee. Once the unit is scanned for return shipping AVPro Edge will ship the new unit for replacement. Page 32 of 33 AC-MAX-24 USER MANUAL...
  • Page 33: Limitation On Liability

    This warranty supersedes all other warranties, remedies, and conditions, whether oral or written, express or implied. Page 33 of 33 AC-MAX-24 USER MANUAL...
