Maintenance and Storage

The periodic maintenance operations are essential for the proper functioning of the system and its
duration in time. The below advice should be strictly followed:
- Check the level of the solution to be dosed to prevent the pump from running dry.
- Check that the suction and delivery pipes are clean and not containing any impurities, which could
damage the tube and cause flow rate anomalies.
- Frequently check the pump operation, when dosing aggressive liquids.
- Check that the filter is not clogged to avoid the decreasing of flow rate.
Replacing the peristaltic tube:
Pump wintering:
Before shutting down the system for wintering or anyway for a long period, dose
clean water to rinse the tube, then rotate the roller-holder clockwise to position it as
shown in the figure.
PoolTimerMini_r2.0 – 07/2021
Unscrew the two front screw and remove the transparent cover.
Remove the old tube first unlocking the fitting on the left and turning
the roller-holder as indicated by the arrow in the figure, to free the
tube to the fitting on the right.
Insert the left fitting into the new pipe, in its place, ensuring that the
rounded side is positioned inwards.
Then turn the roller-holder clockwise, so that the tube is inserted in its
seat.
Insert the right fitting in its place and secure the transparent cover by
tightening the two front screws.
