- Page 1 Spooky Pinball Presents Texas Chainsaw Massacre...
-
Page 2: Table Of Contents
SPKY-0104 LOWER WINDMILL LAYOUT ......38 SPKY-0105 UPPER WINDMILL LAYOUT ......39 SPKY-0106 RIGHT OUTER ORBIT LAYOUT ......40 SPKY-0107 BBQ LAYOUT ............41 SPKY-0108 TOP INNER ORBIT LAYOUT ......42 SPKY-0109 RIGHT INNER ORBIT LAYOUT ......43 SPKY-0110 MAGNET LAYOUT ..........44 HH-0020 LED Harness Converter Schematic ......44 Spooky Pinball... - Page 3 Warden Board Out of Game ..........58 Chapter 4. Diagnose a Bad MOSFET on the Warden Board ....... 59 Tools Required ..............59 Texas Chainsaw Massacre Coil Chart ..........61 Chapter 5. Texas Chainsaw Massacre Switch Chart ........63 Texas Chainsaw Massacre Coil Chart ..........65...
-
Page 4: Chapter 1 Game Assembly And Setup
Setup without topper (h x w x d) - 75 x 29 x 55 in 3/8 OD Parts List 3/16 in Need to report a code bug in Texas Chainsaw Massacre? You Qty. Part (s) can send an email directly to service@spookypinball.com with... - Page 5 Game Assembly and Setup Rubber Rings 2. Using your wire cutters, cut the plastic strap that runs the length of the game. ATTENTION! DO NOT CUT THE PLASTIC STRAP JUST YET! Be careful there is some tension on this strap and it may release with some force.
-
Page 6: Update Instructions
Install the balls Update Instructions 1. Remove the pinballs from their package. Please take a SPOOKY PINBALL SOFTWARE UPDATE INSTRUCTIONS minute to inspect them for any nicks or scratches. Also, this is a good time to wipe them off before installing 1. -
Page 7: Updating The Tcm Base Image
2. Unzip the contents of your download and copy to a new, or freshly formatted USB drive. Need to report a code bug in Texas Chainsaw Massacre? You 3. Safely eject the USB drive after the file transfer can send an email directly to service@spookypinball.com with completes. -
Page 8: Chapter 2 Game Menu System
Door Sling Adjust 200ms Tournament Mode Door Magnet 30ms Table 2-1. Game Play Settings Apron Brightness High Score Entry Time 20 sec Ball Launch Time Out Never Cook Mode Units Kelvin/Celcius Fahrenheit Fahrenheit Table 2-1. Game Play Settings Spooky Pinball... - Page 9 Game Menu System Coil Settings Audio/Video Settings Right Stop Post 7 ms Rear Diverter 20 ms Default Upper PF VUK 20 ms Attract Mode Sounds Door Scoop Eject 15 ms Voice Level 100% Door Magnet 30 ms SFX Level Door Magnet Catch Music Level Power Ambience Level...
- Page 10 Match Boost Replay Award Credit Extra Ball Credit Replay Score 5,000,000 300,000,000 52,000,000 Replay Type Fixed Auto Adjust Auto Adjust Losing Streak Threshold Replay Minimum Score 25,000,000 150,000,000 25,000,000 Replay Maximum Score 100,000,000 300,000,000 150,000,000 Table 2-5. Pricing/Replay Settings Spooky Pinball...
- Page 11 Game Menu System Pricing/Replay Settings Replay Backdown Amount 1,000,000 20,000,000 1,000,000 Replay Increase Amount 1,000,000 20,000,000 1,000,000 Table 2-5. Pricing/Replay Settings Tests Switch Test Note: Use Switch Reports to display statistics on switch activations ● SW91: Menu button off "First report on screen" Default Switch ●...
- Page 12 Open Log ● Export Error Log To USB ● ● No Media ● Green Button Clears Log and Credit Clear Error Log & Credit Dot ● Export Game Settings To USB ● ● No Media Table 2-7. Utilities Spooky Pinball...
- Page 13 Table 2-8. Audits Games Playes Total Seconds Played Average Game Length Need to report a code bug in Texas Chainsaw Massacre? You can send an email directly to service@spookypinball.com with Total Modes Started the subject “Code Bug” Average Modes Started...
-
Page 14: Cabinet Components
Chapter 3 Layouts and Schematics Cabinet Components Service Outlet Tilt Bob Small Power Supply Action Button/Light Large Power Supply Power Switch/Fuse Cover Power Splitter Board Subwoofer Cabinet Switch Expander Shaker Motor Amplifier Spooky Pinball... -
Page 15: Head Breakdown
Head Breakdown Knocker Back Box Lights Topper/Speaker/Flipper LED Board Computer Knocker/Shaker Expansion Board Display Display Driver Board Speaker Speaker LED Kit... -
Page 16: Right Inside Cabinet
Right Inside Cabinet Left Inside Cabinet Lockbar Receiver Screw the brass screws in to tighten the lockbar; unscrew to loosen. Spooky Pinball... -
Page 17: Playfield Underside
Playfield Underside Right Flipper Middle Left Scoop Trough Drop Target Knockdown Auto Launch Drop Reset Left Flipper Left Flipper Right Flipper Magnet Left Sling Back Crate Scoop Right Sling Back Right Diverter Rocket Diverter Left Front Scoop TNT Post... -
Page 18: Boards On Playfield Underside
Boards on Playfield Underside Warden Servo Board Opto Board A Opto Board B Magnet Board Spooky Pinball... -
Page 19: Coin Door Wiring
Coin Door Wiring... -
Page 20: Finished Playfield
Finished Playfield Upper Playfield Spooky Pinball... -
Page 21: Lcd Display
LCD Display LCD Display Recommended Sett ings: (Access using Display Adjustment Panel board to the left of Display Packing List: the display’s driver board) 1× HD-MI VGA DVI LCD Controller Board M.NT68676.3 (new Brightness - 40% version) Contrast - 80% 1×... -
Page 22: Large Power Supply
Large Power Supply Small Power Supply Spooky Pinball... -
Page 23: Shaker Motor
Shaker Motor To Adjust Shaker Motor Vibration 1. With the shaker motor cover removed, locate the two counterweights on each side held in place with a hex screw. 2. Loosen the hex screw. You will be able to rotate the counterweight. -
Page 24: Shaker Motor Board
Shaker Motor Board Shaker Motor in Cabinet Spooky Pinball... -
Page 25: Service Outlet
Service Outlet... -
Page 26: Right Flipper Button
Right Flipper Button Spooky Pinball... -
Page 27: Start Button Connection
Start Button Connection... -
Page 28: Monitor Control Adjust Board
Monitor Control Adjust Board Spooky Pinball... -
Page 29: Led Control Board
LED Control Board... -
Page 30: Flipper Detail
Flipper Detail Amplifier Front View Amplifier Top View Spooky Pinball... -
Page 31: Amplifier Rear View
Amplifier Rear View... -
Page 32: Hh-0035 Pico Layout (Topper)
HH-0035 PICO Layout (Topper) Spooky Pinball... -
Page 33: Hh-0035 Pico Breakout (Topper)
HH-0035 PICO Breakout (Topper) -
Page 34: Hh-0065 Servo Expander
HH-0065 SERVO Expander Spooky Pinball... -
Page 35: Hh-0065 Servo Expander Breakout
HH-0065 SERVO Expander Breakout... -
Page 36: Spky-0100 Left Orbit Layout
SPKY-0100 LEFT ORBIT LAYOUT SPKY-0101 LOWER LEFT ORBIT LAYOUT Spooky Pinball... -
Page 37: Spky-0102 Plates Layout
SPKY-0102 PLATES LAYOUT... -
Page 38: Spky-0103 Right Lanes Layout
SPKY-0103 RIGHT LANES LAYOUT Spooky Pinball... -
Page 39: Spky-0104 Lower Windmill Layout
SPKY-0104 LOWER WINDMILL LAYOUT... -
Page 40: Spky-0105 Upper Windmill Layout
SPKY-0105 UPPER WINDMILL LAYOUT Spooky Pinball... -
Page 41: Spky-0106 Right Outer Orbit Layout
SPKY-0106 RIGHT OUTER ORBIT LAYOUT... -
Page 42: Spky-0107 Bbq Layout
SPKY-0107 BBQ LAYOUT Spooky Pinball... -
Page 43: Spky-0108 Top Inner Orbit Layout
SPKY-0108 TOP INNER ORBIT LAYOUT... -
Page 44: Spky-0109 Right Inner Orbit Layout
RIGHT INNER ORBIT LAYOUT SPKY-0109 Spooky Pinball... -
Page 45: Spky-0110 Magnet Layout
SPKY-0110 MAGNET LAYOUT HH-0020 LED Harness Converter Schematic... -
Page 46: Hh-0022 Trough Opto-To-Switch Converter Layout
HH-0022 Trough Opto-To-Switch Converter Layout HH-0022 Trough Opto-To-Switch Converter Schematic Spooky Pinball... -
Page 47: Hh-0023 Drop Bank Led Panel Layout
HH-0023 Drop Bank LED Panel Layout... -
Page 48: Hh-0023 Drop Bank Led Panel Schematic
HH-0023 Drop Bank LED Panel Schematic Spooky Pinball... -
Page 49: Hh-0000 Warden Root
HH-0000 Warden Root... -
Page 50: Hh-0000 Warden Inputs
HH-0000 Warden Inputs Spooky Pinball... -
Page 51: Hh-0000 Warden Uc
HH-0000 Warden uC... -
Page 52: Hh-0000 Warden Power
HH-0000 Warden Power Spooky Pinball... -
Page 53: Hh-0000 Warden Pwm Outputs
HH-0000 Warden PWM Outputs... -
Page 54: Hh-0000 Warden Led Out
HH-0000 Warden LED Out Spooky Pinball... -
Page 55: Hh-0000 Warden 48V0 Transistors
HH-0000 Warden 48V0 Transistors... -
Page 56: Hh-0000 Warden Aux Transistors
HH-0000 Warden AUX Transistors Spooky Pinball... -
Page 57: Hh-0000 Warden Rev 6 Diagram
HH-0000 Warden Rev 6 Diagram... -
Page 58: Populated Warden Board
Populated Warden Board Spooky Pinball... -
Page 59: Warden Board Out Of Game
Warden Board Out of Game Need to report a code bug in Texas Chainsaw Massacre? You can send an email directly to service@spookypinball.com with the subject “Code Bug”... -
Page 60: Chapter 4. Diagnose A Bad Mosfet On The Warden Board
Wire snips ● Insulating tape YOU ARE WORKING WITH SENSITIVE ELECTRONIC MATERIALS. PLEASE USE CAUSTION! To diagnose a bad MOSFET 1. Set the multimeter to 20k ohms. If 20k ohms is not available, use the closest available ohms setting. Spooky Pinball... - Page 61 Diagnose a Bad MOSFET on the Warden Board 3. To test the MOSFETs, identify the Q8-Q30 MOSFETs A functioning MOSFET should display no on the main Warden board. resistance reading. If there is any reading, it indicates a faulty component. Test all Figure 4-2.
-
Page 62: Texas Chainsaw Massacre Coil Chart
Note: Ensure safety precautions are taken, and the machine is disconnected from power during this process. Seek pro- fessional assistance if you are not comfortable or experienced in working with electronic components. Need to report a code bug in Texas Chainsaw Massacre? You can send an email directly to service@spookypinball.com with the subject “Code Bug”... - Page 63 Texas Chainsaw Massacre Switch Chart Chapter 5 Switch and Coil Charts Texas Chainsaw Massacre Switch Chart Switch Bank for Main Playfield Switch Bank 1 Switch Bank 2 Switch Bank 3 NONE Grey Stand Up Bank Top Grey Middle Scoop Grey...
-
Page 64: Chapter 5. Texas Chainsaw Massacre Switch Chart
Texas Chainsaw Massacre Switch Chart F 50 Inner Right Orbit NONE Action White E 51 Door Entry Purple Spinning Toy Home Purple Upper Right Flip- D 52 Upper Right Ramp Blue Lock Enter Blue Upper Left Flipper Purple Made C 53... - Page 65 Note: Ensure safety precautions are taken, and the machine is disconnected from power during this process. Seek professional assistance if you are not comfortable or experienced in working with electronic components. Need to report a code bug in Texas Chainsaw Massacre? You can send an email directly to service@spookypinball.com with the subject “Code Bug”...
