Summary of Contents for KERN EMB-S
- Page 1 KERN & Sohn GmbH Ziegelei 1 Tel: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-Mail: info@kern-sohn.com Internet: www.kern-sohn.com Servicemanual Precision balances KERN EMB-S Version 1.0 07/2016...
-
Page 2: Table Of Contents
KERN EMB-S Version 1.0 05/2016 Servicemanual Content Basic Information ................... - 3 - Introdution ...................... - 3 - Overview of display ..................- 4 - Keyboard overview ........................ - 4 - Transport Securing ....................... - 5 - Adjustment ..................... - 6 - Reset function .................... -
Page 3: Basic Information
2 Introdution This service manual covers the EMB-S series and is edited for the authorized servicing personnel. Note all rights are reserved. Copying any part of this manual is prohibited without our permission. In this lineup it is an eco product, Therefore, it is not intended to represent the repair manual in detail, since the construction of the balance is very simple. -
Page 4: Overview Of Display
Net weight Capacity display Weighing Units 3.1 Keyboard overview Switch on balance Tare balance Switch off the balance How to change weighing units Adjustment menu access (longer pressing of the button) EMB-S-SH-e-1610 - 4 -... -
Page 5: Transport Securing
Transport Securing Transport locking device locked Transport security loosened During transport of weighing scale In weighing mode If the transport locking device remains locked in weighing mode, an error message “E“ will appear on reaching max load. - 5 - EMB-S-SH-e-1610... -
Page 6: Adjustment
(See chap. 1, Specifications) will be displayed on the screen. (example) Now set the adjusting weight in the centre of the weighing plate. “--------“ will be shortly displayed, followed by “F“. EMB-S-SH-e-1610 - 6 -... -
Page 7: Reset Function
Display Adjustment „rst Y“ Reset menu to default settings. „rst n“ No reset of menu to default settings. Confirm your selection with the OFF-button. After a short period the balance returns automatically to weighing mode. - 7 - EMB-S-SH-e-1610... -
Page 8: Servicing, Maintenance, Disposal
Precautions against short circuit must be taken in cases where the service life of the batteries / storage batteries has not yet expired. EMB-S-SH-e-1610 - 8 -... - Page 9 Batteries with a low degree of noxious substances bear merely a crossed out bin. Return options are restricted to the types of battery that we keep or used to keep in stock as well as the quantity commonly disposed of by end users. - 9 - EMB-S-SH-e-1610...
-
Page 10: Instant Help
Great fluctuations in temperature. Electromagnetic fields / static charging (choose different location/switch off interfering device if possible) Should other error messages occur, switch balance off and then on again. If the error message remains inform manufacturer. EMB-S-SH-e-1610 - 10 -...
