Summary of Contents for TIFATECH NSM1G
- Page 1 S24-070 Coffee Machine Control Board NSM1G Instruction Manual...
- Page 2 S24-070 PREFACE Thank you for purchasing our NSM1G, Control board for the Coffee machine. This manual contains instructions for mounting, functions, operations, and notes when operating the NSM1G. To ensure safe and correct use, thoroughly read and understand this manual before using this instrument.
- Page 3 ▪ This board is intended to only use for the espresso coffee machine control board. Do not use it for any other purpose. PRECAUTIONS ❖ Installation precautions Read thoroughly the following conditions before installing the NSM1G board to the coffee machine. The mounting location must be: ▪ No flammable, explosive gases ▪...
- Page 4 S24-070 ▪ Ensure the board surface is completely dry before powering. ▪ Periodic cleaning will reduce the risk of damaging the board.
-
Page 5: Table Of Contents
S24-070 *** CONTENTS *** GENERAL ......................1 Introduction ..................... 1 II. TECHNICAL SPECIFICATIONS ..............1 Dimensions (mm) .................... 1 Specifications ....................1 III. WIRING ......................2 IV. USING ........................ 3 Turn off the machine ..................4 Coffee dispensing .................... 4 Hot water selection .................. -
Page 6: General
GENERAL 1. Introduction ▪ This manual contains important instructions regarding the safe intended use of the machine. ▪ If any damage or loss to this manual, request a copy from the TIFATECH manufacturer. II. TECHNICAL SPECIFICATIONS 1. Dimensions (mm) 2. Specifications ❖... -
Page 7: Wiring
S24-070 III. WIRING Important: Any mistake in connecting actuators will affect the normal operation of the coffee machine, and even cause damage. -
Page 8: Using
S24-070 Terminal Description Keyboard Keyboard input Boil Lev Ground Tank Lev Flow meter Level probe input FLOW Steam sensor input Heating element input FILL Steam solenoid valve Group solenoid valve STEAM Steam solennoid valve PUMP Pump HEAT Heating element PRESSURE SWITCH Pressure switch FILL Filling solenoid valve... -
Page 9: Turn Off The Machine
S24-070 1. Turn off the machine Press the power button for 3s until the other lights turn off and its light turn to the blink state. 2. Coffee dispensing Press the button to proceed to dispense coffee continuously until the user presses it again. -
Page 10: Programming
S24-070 V. PROGRAMMING 1. Programming doses To set the dose for any dispensing button, you will have to enter the setting mode and program for that key by the steps below. Note: The procedure can just be implemented when the machine is on. Step 1: Press the button and hold it down for 5 seconds until all dispensing button lights begin to flash. -
Page 11: Error Detection And Troubleshooting
S24-070 VI. ERROR DETECTION AND TROUBLESHOOTING 1. Water flow meter error a. Error symptom • The programming process will start normally but the coffee amount on the error group won’t be saved afterward. The key which is programmed in error condition will be locked after that. - Page 12 S24-070 TIFATECH Co., Ltd Address: 14 Tran Tu Binh Street, Hoa Chau Ward, Hoa Vang District, Da Nang City, Vietnam Email: tifatech@tifatech.vn Tel: +84 899 600 009 Website: https://tifatech.vn/ https://hardtech.vn/...
