- Page 1 Air conditioner User & installation manual EHS Wi-Fi Kit DB98-40278A • Thank you for purchasing this Samsung Product. • Before operating this unit, please read this manual carefully and retain it for future reference.
-
Page 2: Table Of Contents
SmartThings app SmartThings app Checking the power connections • Setting up and connecting to a Wi-Fi access point using your smartphone • Downloading the SmartThings app and registering your Samsung account Connecting the SmartThings app to your product Appendix Troubleshooting... -
Page 3: Safety Precautions
Safety precautions This installation manual explains how to install a EHS Wi-Fi Kit to an indoor unit of Samsung system air conditioners. Read the installation manual thoroughly before installing the EHS Wi-Fi Kit. (Refer to the appropriate manual for installing product or other optional parts.) WARNING Hazards or unsafe practices that may result in severe personal injury or death. - Page 4 Safety precautions CAUTION Do not install the product in a place where it is or might be exposed to inflammable gas leakage. • There is risk of fire or explosion. Do not install the product in a place where it will be exposed to oil or vapor etc. •...
-
Page 5: Checks Before Installation
Checks before Installation Accessories EHS Wi-Fi Kit - with WIRE Manual Users & Install CAUTION • The EHS Wi-Fi Kit must be installed by a certified technician. • Before installation, be sure to cut off power. • Install the cables of the EHS Wi-Fi Kit inside the product to prevent user access, in accordance with the relevant electrical wiring regulations. -
Page 6: Installing The Wi-Fi Kit Single
Installing the EHS Wi-Fi Kit Installing the EHS Wi-Fi Kit EHS R-290 MONO pump intergated Outdoor Unit (AE***CXYB*K) Where to install 1 Open the switch side cover. 2 Remove 2 screws and pull the plate to the left. 3 If the plate is rotated to where the hook is, it will be fixed to the hook. English... - Page 7 4 Insert the cables at the rear of the unit, and route them through the factory mounted cable sleeves into the switch box. Communication cable 5 Connect the wire of EHS Wi-Fi kit to the "Wi-Fi" connector (white, 7-pin) EHS Wi-Fi Kit 6 Use the double-sided tape attached to the back of the EHS Wi-Fi kit and attach it indoors with a good Wi-Fi connection.
-
Page 8: Smartthings App
• If you have enquiries regarding the items mentioned above, please contact us on st.service@samsung.com. 2 Registering your Samsung account • A Samsung account is required to use the NOTE SmartThings app. To create your Samsung account • The setup may differ depending on your and log in to your account, follow the instructions smartphone model, OS version and manufacturer. -
Page 9: Connecting The Smartthings App To Your Product
2 Connecting the SmartThings app to your product NOTE • Follow the instructions displayed on the • If you already have a Samsung account, log SmartThings app to connect to your product. in to the account. When your smartphone is a Samsung device and you have a Samsung •... -
Page 10: Appendix
• If you are using a Samsung smartphone, the server may not be connected temporarily. Restart the SmartThings app and then try adding the device I found a failure message again. -
Page 11: Specifications
2412 - 2472 MHz 20 dBm 2402 - 2480 MHz 20 dBm Open Source Announcement The software included in this product contains open source software. The following URL http://opensource.samsung.com/opensource/SMART_TP1_0/seq/0 leads to open source license information as related to this product. English... -
Page 12: Declaration Of Conformity
Por la presente, Samsung declara que este equipo radioeléctrico cumple con la Directiva 2014/53/UE y con los requisitos legales relevantes en el Reino Unido. El texto completo de la declaración de conformidad con la UE y Spanish de la declaración de conformidad con Reino Unido está... - Page 13 Reino Unido está disponível no seguinte endereço da Internet: http://www.samsung.com, vá a Suporte > Pesquisar Suporte do produto e insira o nome do modelo. Družba Samsung izjavlja, da je ta radijska oprema v skladu z Direktivo 2014/53/EU in ustreznimi zakonskimi zahtevami v Združenem kraljestvu.
- Page 14 Regatul Unit este disponibil la următoarea adresă de internet: http://www.samsung.com, accesați asistența > Căutați asistența produsului și introduceți numele modelului. Samsung erklærer herved at dette radioutstyret er i samsvar med direktiv 2014/53/EU og med de relevante lovpålagte kravene i Storbritannia. Den fullstendige teksten til EU-samsvarserklæringen og den britiske Norwegian samsvarserklæringen er tilgjengelig på...
- Page 15 English...
- Page 16 (Name and signature of authorized person) ※ This is not the address of Samsung Service Centre. Please see the address or the phone number of Samsung Service Centre in the warranty card or contact the retailer where you purchased your product.
- Page 17 ( Name and signature of authorized person) ※ This is not the address of Samsung Service Centre. Please see the address or the phone number of Samsung Service Centre in the warranty card or contact the retailer where you purchased your product.
- Page 18 (For India only) For more information on safe disposal and recycling, visit our website www.samsung.com/in/support or contact our Helpline numbers - 1800 40 SAMSUNG (1800 40 7267864) 1800 5 SAMSUNG (1800 5 7267864).
