Bushnell neo PHANTOM User Manual

Gps rangefinder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
F.P.O.
Image-replace
User Manual
10-17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the neo PHANTOM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bushnell neo PHANTOM

Summary of Contents for Bushnell neo PHANTOM

  • Page 1 ® F.P.O. Image-replace User Manual 10-17...
  • Page 2 • Properly recycle or dispose of the battery. Do not dispose in fire or water. Legal Disclaimer By using this product, you agree that Bushnell Outdoor Products will not be held legally responsible for any injury or damage to you or any person or property caused by the user’s improper operation and/or poor judgment while using this product.

  • Page 3: Table Of Contents

    Table of Contents Contents Page # Charging the Battery Package Contents / Computer Requirements / Updates Buttons and Functions Getting Started Using the Play Golf Mode Button Functions in Play Golf Mode Using the Play Golf Menu / Play Menu Items Using the Settings Mode Settings Menu Items 9-11...

  • Page 4: Charging The Battery

    USB cable to the port at the bottom side of the unit and connect the large (standard) USB plug to your computer. The NEO Phantom and USB cable are compatible with all USB ports, including iPhone/other smartphone USB chargers. Once connected, press the PWR button-the display will read “CHARGING”.

  • Page 5: Buttons And Functions

    Buttons and Functions MENU PWR 6 ▲ SELECT ◄ DOWN SHOT ▼ F.P.O. Image-replace 1. SHOT DISTANCE Button: Press at starting point, walk to ball position to find length of shot. 2. MENU Button: View Menu options/items. ▲ 3. UP Button: Scrolls up through Menu.

  • Page 6: Getting Started

    GPS satellite signals. Now, you’re ready to power up and use your NEO Phantom. Press and hold the PWR button on the top side of the unit until it powers on (start screen as shown on right).

  • Page 7: Button Functions In Play Golf Mode

    Displayed Info in Play Golf Mode Hole # Information Center of the Green Distance Back of the Front of the Green Distance Green Distance Button Functions in Play Golf Mode NEXT HOLE MENU HAZARDS/ SHOT ROUND INFO F.P.O. Image-replace PREVIOUS HOLE BUTTON FUNCTIONS IN PLAY GOLF MODE •...

  • Page 8: Using The Play Golf Menu / Play Menu Items

    USING THE PLAY MENU IN PLAY GOLF MODE In PLAY GOLF Mode, press the MENU button to view the PLAY MENU. Select item from menu using UP/ DOWN buttons to highlight it, then press SELECT button. If multiple options are available for a setting, use UP/DOWN to highlight your choice, then press select.

  • Page 9: Using The Settings Mode

    USING THE SETTINGS MODE Highlight SETTINGS (if you are in PLAY GOLF mode, press MENU and select EXIT ROUND to go to the main menu) and press SELECT. Select item from menu using UP/ DOWN buttons to highlight it, then press SELECT button.
  • Page 10 • TIME/DATE > press SELECT then highlight and select one of these four time/date related settings: 1) TIME ZONE: scroll through list and highlight your time zone (list continues if DOWN button is pressed at bottom of screen), press SELECT. 2) SET TIME/DATE: press SELECT and highlight a method: •...
  • Page 11 3) DAYLIGHT SAVI: press SELECT and highlight current daylight savings time status for your location: • DST ON +1 • DST OFF -1 4) FORMAT: press SELECT and highlight preference for time display: • 12 HOUR • 24 HOUR • CONTRAST: press SELECT...

  • Page 12: Accessing Updated Golf Course Data

    The answer is yes, and it’s simple to do. Go to www.bushnellgolf.com and view the product page for any of the different color versions of the NEO Phantom. You’ll find three orange links you can click: •...
  • Page 13 BLUETOOTH SETTINGS The NEO Phantom can connect to the smartphone app via Bluetooth. Once connected the NEO Phantom can receive text, email, phone, calendar, and Tee Time alerts. Further the smartphone app can configure the NEO Phantom, display Fitness data and Swing Pro data.
  • Page 14 MAGNETIC BITE FEATURE The NEO Phantom features a powerful BITE magnet incorporated into the rear center of its housing, which allows it to be securely attached to the included belt/bag clip, or directly to a golf cart bar. To use the BITE clip, simple slide it onto your belt or golf...

  • Page 15: How To Find The Product Id / Serial Number

    How to Find the Product ID / Serial Number The serial # (Product ID) of your Phantom can be found on the back of the unit. Write it down below for future reference. You will need it to register on the iGolf site so you can access newly added golf courses or update data for existing courses.
  • Page 16 ONE YEAR LIMITED WARRANTY Your Bushnell NEO Phantom is warranted to be free of defects in materials and ® workmanship for one year after the date of purchase. In the event of a defect under this warranty, we will, at our option, repair or replace the product, provided that you return the product postage prepaid.
  • Page 17 · Consult the dealer or an experienced radio/TV technician for help. The device does not contain any user-serviceable parts. Repairs should only be made by an Authorized Bushnell repair center. Unauthorized repairs or modifi cations could result in permanent damage to the equipment, and will void your warranty and your authority to operate this device under Part 15 regulations.
  • Page 20 ® Customer Service: (800) 423-3537 www.bushnellgolf.com ©2017 Bushnell Outdoor Products...
