PRODUCT DATA
MODEL
WEIGHT
NOMINAL HEAT OUTPUT
FB2
95KG
12KWs
CONTENTS
OPERATING INSTRUCTIONS
Lighting the fire
Firebox linings and baffle
Wood burning tips & theory
Running temperatures
Cleaning and Maintenance
INSTALLATION INSTRUCTIONS
Building regulations
Positioning and Clearances
Chimney
Flue connection
Problem solving
Lee Bridge Ind. Est., Halifax, HX3 5HE, UK
www.firebellystoves.com mail@firebellystoves.com
height to
rear flue
outlet
2
2
2
3
3
4
4
4
5
Advertisement
Related Manuals for Firebelly FB2
Summary of Contents for Firebelly FB2
- Page 1 PRODUCT DATA MODEL WEIGHT 95KG NOMINAL HEAT OUTPUT 12KWs height to rear flue outlet CONTENTS OPERATING INSTRUCTIONS Lighting the fire Firebox linings and baffle Wood burning tips & theory Running temperatures Cleaning and Maintenance INSTALLATION INSTRUCTIONS Building regulations Positioning and Clearances Chimney Flue connection Problem solving...
- Page 2 Operating Instructions Building regulations Installation of the Firebelly woodburning stove must comply with all local building regulations, including those referring to national and European standards. It is a good idea to consult your local chimney sweep to check the suitability of the chinmney and ensure there is adequate updraft and suggest any remedies to potential chimney problems.
- Page 3 combustion air and the gases that are released from the wood as it heats up. The heat of the fire ignites and burns these gases. In contrast, the dense smoke from a slow, smouldering fire is potential heat energy that escapes up the chimney and either clings to the chimney flue as creosote or pollutes the outdoor air.
- Page 4 The high temperature paint finish normally requires no treatment. Any damage or wear to small areas of the paint finish may be remedied using STOVEBRIGHT’s high temperature aerosol paint (colour ‘charcoal’ , available from stove shops and from Firebelly). Make sure the stove is cold and read the instructions on the can carefully before applying the paint.
- Page 5 Document J of the Building Regulations contains further information regarding the installation of solid fuel appliances and can be viewed here : www.odpm.gov.uk or follow the link on the Firebelly website. Ventilation There must be a constant supply of fresh air to the room in which the stove is to be installed.
- Page 6 Operational problems Blackened glass • The wood is too damp. Only use wood stored for at least 12 months under cover and with a moisture level not exceeding 20% • Insufficient intake of air from the top air control. Open the top air control further. The air shield system is more efficient the more air is allowed to run over the glass panel.
- Page 7 Warranty This stove has a two year guarantee covering any defects arising from faulty workmanship dur- ing normal use of the stove. The guarantee does not cover parts deemed to be replaceable in the normal usage of the stove. These include: Glass &...
