MODEL M691
CADAVER SCISSOR
CARRIER w/ROLLERS
CAUTION
• Inspect unit and all components
for any loosening that may have
occurred during shipping •
ATTENTION
Review entire manual before
starting assembly
ATTENTION
All images and Drawing in this manual
may not represent your model.
Refer to your particular project for
exact specifications
Mortech™ Manufacturing Inc.
411 North Aerojet Avenue, Azusa, CA 91702
(626) 334-1471 www.mortechmfg.com
Technical Users' Manual
Installation and Operating Instructions
CAUTION
DO NOT USE CLEANERS
•
CONTAINING CHLORINE WHEN
CLEANING STAINLESS STEEL
•
Advertisement
Table of Contents
Related Manuals for MORTECH M691
Summary of Contents for MORTECH M691
- Page 1 Technical Users’ Manual Installation and Operating Instructions MODEL M691 CADAVER SCISSOR CARRIER w/ROLLERS CAUTION CAUTION • Inspect unit and all components DO NOT USE CLEANERS • for any loosening that may have CONTAINING CHLORINE WHEN occurred during shipping • CLEANING STAINLESS STEEL •...
-
Page 2: Safety Information
• Is unit draining properly? WARNING • Are all nuts, bolts, and pins secured in place? It is crucial that any work performed on Mortech If unit has an issue contact Mortech Manufacturing Inc. Manufacturing Inc. manufactured items are carried out... -
Page 3: Equipment Description
• Scissor lift with height adjustments • (4) 6 in./15 cm. Swivel casters w/ brake The Model M691 Cadaver Scissor Carrier with full rollers • Scissor lift mechanism elevates cadaver tray to allows for removal and transport of a decedent. The top 56.7 in. -
Page 4: Parts Listing
Parts listing M691 Cadaver Scissor Carrier w/Rollers 600040DS COVERED CADAVER SCISSOR CARRIER w/ROLLER The M691 in the raised position The M691 In the lowered position. The M691 is compatible w/ 1036-114 position and many other cooler configurations... - Page 5 M691 Cadaver Parts listing Scissor Carrier w/Rollers Model M691 Direct interaction TRANSFER FROM LIFT TO REFRIGERATOR Once the body tray has been transferred to the lifting device, w/ 1036-R114 Mortuary Refrigeration you have the ability to transfer the decedent to your morgue refrigerator and/or storage system.
-
Page 6: Critical Components
M691 Cadaver Critical components Scissor Carrier w/Rollers BATTERY PACK Features: • Functional and elegant design • High battery capacity: 24 V DC, 1 x 2.9 Ah (Normal speed (LA32JKSM and CBJ1), Thrust up to: 6000 N, The actuator does not reach the end position at any time, Stroke: S = 200 mm) •... -
Page 7: Control Box
M691 Cadaver Critical components Scissor Carrier w/Rollers CONTROL BOX Amongst other benefits the control box has: • Efficient and user friendly max. weight adjustment (according to EN10535) • Data collection in the control box • Possibility to read out service data on laptop •... -
Page 8: Operation
M691 Cadaver Operation Scissor Carrier w/Rollers Charging and Control Station Rechargeable Battery Cord Hand Held Push Button Lift Controller Piston Actuator Cord CAUTION • When lift is not in operation, the unit’s battery must be recharging • Rechargeable Battery Cord CAUTION When lift is not in operation, the unit’s battery... - Page 9 M691 Cadaver Critical components Scissor Carrier w/Rollers ACUATOR • Compatible with CB9 with EAS, CB12 with EAS, CB14*, Features: CB18, CB20 and CBJ, CB6 OBL/ F, CB16 OBL/ F, • Max. thrust 10,000 N (in push only) (* = only possible with customized software) •...
-
Page 10: System Description
This applies to both control boxes, which always run off battery and control boxes with battery backup. Contact your Mortech for specification of type, size etc. 5, 6, 7, 8 9, 10 1. - Page 11 M691 Cadaver Critical components Scissor Carrier w/Rollers • The products must be cleaned at regular intervals to Valid for control box and handset remove dust and dirt and inspected for mechanical damage, • Electronics must be inspected at attachment points, wires, cabinet, and plugs.
-
Page 12: Component Data
M691 Cadaver Critical components Scissor Carrier w/Rollers Component Data USE AND CARE FOR CASTERS 1. To engage brake mechanism, depress brake mechanism down, until you feel it lock. To release brake mechanism press forward to return for range of motion. Mechanisms are located on all (4) wheels. -
Page 13: Maintenance Instructions
M691 Cadaver Equipment maintenance Scissor Carrier w/Rollers one that does not contain chlorine, such as acetone, methyl alcohol, and mineral spirits. MAINTENANCE INSTRUCTIONS EFFECTIVE CLEANING METHODS The unit requires regular maintenance and follow the Commercial Cleaners - Many commercial cleaners manufactures directions. -
Page 14: Maintenance Record
Maintenance record M691 Cadaver Scissor Carrier w/Rollers MAINTENANCE RECORD Date... -
Page 15: Training Record
M691 Cadaver Training record Scissor Carrier w/Rollers TRAINING RECORD Date... -
Page 16: Warranty
Information in this Manual is subject to change without notice of (18) months from the date of shipment. Shipping and and does not represent a commitment on the part of Mortech Labor is not warranted. Items not manufactured by Mortech Manufacturing.
