SERIES 7011
PORTABLE MORTUARY
STORAGE RACK SYSTEMS
CAUTION
• Inspect unit and all components
for any loosening that may have
occurred during shipping •
ATTENTION
Review entire manual before
starting assembly
ATTENTION
All images and Drawing in this manual
may not represent your model.
Refer to your particular project for
exact specifications
Available in
Two, Three, Four and Five Tiers
Mortech™ Manufacturing Inc.
411 North Aerojet Avenue, Azusa, CA 91702
(626) 334-1471 www.mortechmfg.com
Technical Users' Manual
Installation and Operating Instructions
CAUTION
DO NOT USE CLEANERS
•
CONTAINING CHLORINE WHEN
CLEANING STAINLESS STEEL
WARNING
Biohazard Label is place on the
equipment signifying the potentially
infectiousness due to the samples
or reagents
•
OCTOBER 2016
ISO Doc. #OM7011 (REV F)
Advertisement
Table of Contents
Related Manuals for MORTECH 7011 Series
Summary of Contents for MORTECH 7011 Series
- Page 1 Refer to your particular project for exact specifications Available in Two, Three, Four and Five Tiers OCTOBER 2016 Mortech™ Manufacturing Inc. ISO Doc. #OM7011 (REV F) 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com...
-
Page 2: Bloodborne Disease Notice
• Are all nuts, bolts, and pins secured in place? If unit has an issue contact customer relations. It is crucial that any work performed on Mortech Mfg. Inc. manufactured items are carried out exclusively by skilled INSTRUCTION FOR HANDLING professionals who have the respective training. - Page 3 Series 7011 Portable Storage Rack System Parts listing RUBBER BUMPER (1) EACH TIER FULL LENGTH ROLLER ASSEMBLY (5) EACH TIER LOCKING LATCH MECHANISM (1) EACH TIER (4) Ø6 INCH CASTER WHEELS w/BRAKE MECHANISM SERIES 7011 The Portable Cremation Storage Rack is ideal for a variety of cadaver storage applications. It is more compact than conventional cantilever storage units allowing for greater storage capacity without increasing space.
- Page 4 Operation Series 7011 Portable Storage Rack System TRAY LATCH ASSEMBLY AFTER INSERTING THE TRAY, FLIP THE TRAY LATCH TO SECURE THE TRAY WHEN REMOVING THE TRAY SIMPLY LIFT THE TRAY LATCH TO REMOVE THE TRAY OCTOBER 2016 MFGISO DOC. #OM7011 (REV F)
- Page 5 Series 7011 Portable Storage Rack System Parts listing SERIES 7011 7011-5 5 TIER 7011-4 4 TIER 7011-3 3 TIER 7011-2 2 TIER OCTOBER 2016 MFGISO DOC. #OM7011 (REV F)
-
Page 6: Operation
Operation Series 7011 Portable Storage Rack System SERIES 7011 IN CONJUNCTION WITH 7010 PORTABLE MORTUARY RACK TOTAL ROLL CARRIERS, LIFTS & TABLES M678 HYDRAULIC LIFT T3626 S/S BODY TRAYS M600H ROLLER PALLET MANEUVER HYDRAULIC LIFT NEXT TO RACK. RAISE OR LOWER ROLLER PALLET TO MATCH DESIRED BODY TRAY. - Page 7 Series 7011 Portable Storage Rack System Operation SERIES 7011 IN CONJUNCTION WITH TOTAL ROLL CARRIERS, LIFTS & TABLES M678 Battery Operated Hydraulic Cadaver Lift Shown Transferring a T3624 Body Storage Tray into a 1036-R114EC Refrigerator M678 Battery Operated Hydraulic Cadaver Lift Shown Transferring a T3626HS Stainless Steel Body Tray Onto a 600040 Hydraulic Carrier M678 Battery Operated Hydraulic Cadaver Lift...
- Page 8 Parts listing Series 7011 Portable Storage Rack System MODEL T3626-HS Designed for use with mortuary refrigerators, mortuary racks, dissecting tables and cadaver carriers. The Model T3626HS is a smoothly finished 18 gauge stainless steel body tray. It is an integral part of the Total Roll System. •...
-
Page 9: Maintenance
METRIC CAP M8 X 1.25 X 50L Brake Lock METRIC NYLOC NUT TIGHTEN AND SECURE Brake Lock Release Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com OCTOBER 2016 MFGISO DOC. #OM7011 (REV F) -
Page 10: Maintenance Instructions
Series 7011 Portable Storage Rack System Maintenance MAINTENANCE INSTRUCTIONS The unit requires regular maintenance and follow the EFFECTIVE CLEANING METHODS manufactures directions. Commercial Cleaners - Many commercial cleaners DISINFECTING AND CLEANING compounded from phosphates, synthetic detergents, and Clean all surfaces of the stainless steel with a hard surface alkalis are available for the cleaning of severely soiled or disinfectant/cleaner such as Sheila Shine®... -
Page 11: Maintenance Record
Series 7011 Portable Storage Rack System Maintenance record MAINTENANCE RECORD Date OCTOBER 2016 MFGISO DOC. #OM7011 (REV F) -
Page 12: Training Record
Training record Series 7011 Portable Storage Rack System TRAINING RECORD Date OCTOBER 2016 MFGISO DOC. #OM7011 (REV F) -
Page 13: Warranty
Information in this Manual is subject to change without notice Labor is not warranted. Items not manufactured by Mortech and does not represent a commitment on the part of Mortech Manufacturing. Inc. will receive the manufacturer’s warranty. Manufacturing. Inc. Mortech Manufacturing. Inc. assumes no responsibility for any inaccuracies that may be contained in this Manual.
