Pix-link AC22 Quick Installation Manual page 2

3、WAN settings, set the router's Internet access.
WAN Setting
You can configure the parameters of multiple Internet Access Modes.
Internet Access Mode DHCP
Host Name PIX-LINK
MTU 1500
MAC Address 00:22:44:66:88:23
Clone MAC Address
Apply
DHCP: The DHCP server can automatically
assign an IP address, subnet mask,
gateway address, DNS.
5 Ordinarily Troubleshoo ng
★ Unable to access administration page?
Please make more detailed checks as following:
Ensure your computer gets the address automatically.
Ensure your computer is connected to the router's LAN
port with the cable，and the network indicators on both
sides are lit.
Please Launch Internet Explorer Browser, select "tools" → "
Internet options" ,ensure the connection tab is configured
to never dial, and all options are not checked under "LAN
Settings".
Please relaunch your browser or try another browser
(such as firefox or chrome).
Please replace the network cable, or replace another
computer and try again Please reset the device factory
default and repeat the above steps again if the issue still
exists.
★
How to restore the device to the factory default?
Press and hold the "Reset" button on the back of the device
for more than 5s.
Note: All configurations will be cleared and you need to
reconfigure your device after set factory default.
WAN Setting
You can configure the parameters of multiple Internet Access Modes.
Internet Access Mode STATIC
IP Address
Subnet Mask
Default Gateway
DNS1
DNS 2
MTU 1500
MAC Address 00:22:44:66:88:23
Clone MAC Address
Apply
STATIC：Enter the IP address, subnet mask,
default gateway and DNS information
provided by the ISP.
★
The Internet still cannot be accessed after completing the configuration?
Please make more detailed checks as following: Ensure the
router's network cable is properly connected and both LAN and
WAN port's network indicators are lit.
Please check if the internet access settings match your actual environment.
Determine according to the following table:
Internet Access
No internet connection parameters provided
DHCP
IP address, subnet mask, gateway,
STATIC
DNS server, etc. provided by ISP
Broadband account and broadband password
PPPOE
4、 Wireless Setting
WAN Setting 2.4G Basic Setting
You can configure the parameters of multiple Internet Access Modes.
Enable/Disable
Internet Access Mode PPPOE
BandSteening
Account
SSID
Password
Maximum Clients
AC AUTO Leave Blank To Auto Detect
Hide SSID
Server AUTO Leave Blank To Auto Detect
Wireless Mode
MTU 1492
Bandwidth
MAC Address 00:22:44:66:88:23
Isolated
Clone MAC Address
Channel
Apply
TX Power
PPPOE：Enter the account and password
Encryption
provided by the ISP.
Pass Phrase
After entering the SSID and Pass Phrase,
complete the setup.
Description
5.8G Basic Setting
Enable/Disable
Enable
BandSteening
Disable
PIX-LINK-2.4G SSID
Maximum Clients
32
Range 1-32,default 32 Range 1-32,default 32
Hide SSID
11BGN Wireless Mode
AUTO Bandwidth
Disable Isolated
6 Channel
TX Power
100%
Encryptype Encryption
........
Pass Phrase
Apply
★
The cell phone, tablet or laptop cannot associate to
the WIFI network?
Please make more detailed checks as following:
Ensure the WIFI function on the mobile device works normally,
for example, the WIFI switch is turned on, and the
wireless signal can be scanned.
Ensure the router is set up correctly.
Please make sure that the wireless name selected and the wireless Pass
Phrase entered are correct (case sensitive) when establishing the wireless
association.
Please reset the device factory default and repeat the above steps again
if the issue still exists.
Enable
Disable
PIX-LINK-5.8G
32
11AC
80M
Disable
157
100%
Encryptype
........
Apply
