- Page 1 Home Battery 48V Installation Guide for Europe and APAC Home MAN-01-00954-1.2 Version 1.2 Home Battery 48V Installation Guide...
-
Page 2: Disclaimers
However, SolarEdge assumes no responsibility for the use of this material. SolarEdge reserves the right to make changes to the material at any time and without notice. You may refer to the SolarEdge web site (www.solaredge.com) for the most updated version. -
Page 3: Table Of Contents
Contents Disclaimers ..........................1 Important Notice ......................1 Handling and safety instructions ................... 3 Installation ........................3 Operation ......................... 4 Installation tools ........................6 Charging cable requirements ................... 6 What's in the package ....................... 6 Battery accessories ......................6 Select and prepare the installation site............... 7 Configurations ........................ -
Page 4: Handling And Safety Instructions
Handling and safety instructions Read these instructions carefully before installing or operating the SolarEdge Home Battery 48V (referred to as the Battery or Battery Pack). Failure to do so, or to follow any of the instructions or warnings in this document can result in electrical shock, serious injury, or death, or may damage the battery and other property. -
Page 5: Operation
WARNING! In case of an electrolyte leak from the battery, avoid contact with the electrolyte and follow the instructions in the SolarEdge Home Battery 48V Emergency Response Guide. WARNING! Use the battery only as directed in this document. - Page 6 WARNING! Do not use fluids, parts, or accessories other than those specified in this guide, including the use of non-genuine SolarEdge parts or accessories, or parts or accessories not purchased directly from SolarEdge or a SolarEdge certified party.
-
Page 7: Installation Tools
Do not attempt to remove or transport a damaged or non-functioning battery. Contact SolarEdge or your SolarEdge certified installer for support. WARNING! Do not dispose of this product with general household waste. Consult your local regulations for proper disposal instructions. -
Page 8: Select And Prepare The Installation Site
IAC-RBAT-5KCINV-02 Phase (PN SE*K-RWS48) Accessory SolarEdge Home Battery 48V , cable set battery IAC-RBAT-5KCBAT-01 module to battery module Accessory SolarEdge Home Battery 48V , cable set tower to IAC-RBAT-5KCTOW-01 tower Floor stand support SolarEdge Home Battery 48V (optional) IAC-RBAT-5KFSTD-01 Accessory 10 * Spare connector kit for battery to Inverter... -
Page 9: General Guidelines And Requirements
Figure 1: Battery Pack Configurations General guidelines and requirements The battery may be installed in an outdoor or indoor location. The battery must be secured to a wall using the supplied mounting bracket and the installation location must be adjacent to a wall. When installed indoors, the battery must not be obstructed by any building structure, room furniture or equipment. -
Page 10: Restricted Locations
Version 1.2, August 2024 Restricted locations Do not install the battery at any of following locations: Residential rooms Wall or ceiling niches Entrance/exit areas or below a staircase/passage Environments with humidity and condensed water level of over 90% Earthquake zones where additional safety measures are required Sites at altitudes of more than 2000 meters above the sea level Sites exposed to direct sunlight or sites where the ambient temperature may exceed the specified maximum temperatures... -
Page 11: Residential Barrier
Figure 2: Clearance Note the following dimensions: Width Height Depth Battery module 540mm 500mm 240mm Tower Cover 540mm 120mm 240mm Floor Stand 535mm 50mm 210mm Residential barrier To prevent a fire from spreading, install a non-combustible barrier on the other side of the wall or structural surface, on which the battery is installed. If the installation surface is not made of a non-combustible material, a non-combustible barrier can be installed between the battery and the wall or structural surface. -
Page 12: Install The Battery Modules
Version 1.2, August 2024 Install the battery modules Battery description The image below displays a single battery module with completed connections. Figure 3: Battery Description CAN-bus (RJ45) connection to 5 Circuit breaker, 120A inverter communication RJ45 communication socket to connect between Grounding terminals battery modules. - Page 13 The floor stand is optional, however, for durable and robust insulation, SolarEdge recommends installing the battery modules on top of a floor stand, to be purchased separately from SolarEdge. Depending on wall leveling, consider when installing more than one module.
- Page 14 Version 1.2, August 2024 Figure 6: Floor stand—tightening the nut CAUTION! Before moving the battery module to its location, make sure that both the CB switch Connecting and the power button (soft switch) of the battery module are off – refer to Single Battery Module.
- Page 15 4. Put the bracket on the wall, mark the drilling holes location, then remove the bracket and drill holes in the wall. Figure 8: Drilling the holes for the wall bracket NOTE Don’t drill through the bracket. 5. Assemble the supplied mounting bracket to the battery module using two M5 screws.
-
Page 16: Connect A Single Battery Module
Version 1.2, August 2024 Figure 10: Connecting the mounting bracket 7. When installing battery modules in a tower configuration (one on top of the other): Before securing the wall brackets, make sure the battery modules are aligned (see the following image). Secure all battery modules to the wall as described above. - Page 17 1. Make sure the battery module's DC switch is off. 2. Before connecting the cables between the towers and the inverter, make sure the accessory kit is the correct length (see the following image). CAUTION! Note the following cable parameters, it is extremely important for durable installation as the current flowing through the cables may exceed 100A.
- Page 18 Version 1.2, August 2024 control interfaces on the left side of the battery module, to allow clear and secure access to the battery module interfaces. Figure 12: Access to the left side interfaces 4. Before continuing with the installation, make sure the battery is OFF, then make sure that the front panel LEDs are OFF.
- Page 19 b) Press the power button (soft switch, position 4 below) for 3-6 seconds until the indicator lights go out. Figure 14: Battery LED indicators Battery Capacity/ Alarm ID Indication LED Operation Indicator Power/Reset Button 5. Connect the CAN-bus communication cable (RJ45) coming from the inverter, with the top battery module connector marked "Inverter".
- Page 20 Version 1.2, August 2024 6. Depending on local regulations, use the left grounding terminal to connect the battery module to the inverter grounding or the main grounding. Figure 16: Connect the grounding terminal 7. Make sure the Inverter is turned off, then use the upper pair of DC connectors (BAT- and BAT+) to connect power from the inverter.
- Page 21 LED or the first and second green LED should light constantly. No other LEDs should light. If you observe a different LEDs sequence, refer to for LED troubleshooting. or contact SolarEdge support with the Battery module SN and the LED sequence. Until this is solved, do not proceed with the installation.
-
Page 22: Connect Multiple Battery Modules
CAUTION! Connecting a Single Battery Use only cables recommended by SolarEdge—see Module. Contact SolarEdge or your distributor to order the appropriate cable kit for What's in the your configuration. For cable kits and accessories, see Package 1. Open the side doors of the battery modules. -
Page 23: Power On The Battery Module
Figure 20: Connecting cables between the battery modules 4. Connect the DC and communication cable of the first or last battery module to the inverter. For ease of installation, SolarEdge recommends connecting the inverter to the top battery module. See the inverter’s installation guide for connection instructions. -
Page 24: Top Cover Installation
Version 1.2, August 2024 Figure 21: Battery LED indicators Battery Capacity/ Alarm ID Indication LED Operation Indicator Power/Reset Button 2. Turn on the DC switch. Figure 22: Turning on the DC switch 3. Fasten the side door with the three screws. Top cover installation After installing the battery and making all the connections, install the top cover on the top battery module in every tower. -
Page 25: Add Or Remove A Battery Module
4. Assemble the top plate with the 5 screws. Figure 23: Top Cover Installation Add or remove a battery module Install the battery when there is enough PV to charge the battery pack after adding the module. Before adding or removing a battery module: 1. -
Page 26: Led Indications
The added module may have a different state of charge (SoC) level compared to existing modules, this is normal and balances after a few charge/discharge cycles. LED indications The following section describes the LED behavior of the SolarEdge Home Battery 48V. Mode Behavior... - Page 27 Cell under voltage 3 blinks Off Off Charge MOS fault 3 blinks On On Discharge MOS fault 3 blinks On Off Cell over 3 blinks Off On temperature Cell under 3 blinks Off Off temperature Charging Over 3 blinks On On Alarm Current Discharge Over...
-
Page 28: Support Contact Information
3.75S Blinks three times every 6 seconds 0.5S 1.5S Support contact information If you have technical problems concerning SolarEdge products, please contact us: https://www.solaredge.com/service/support Before contacting SolarEdge, have the following information. Model and serial number of the product in question. - Page 29 System configuration information, including the type and number of panels connected and the number and length of strings. The communication method to the SolarEdge server, if the site is connected. The product's software version as it appears in the ID status screen.
