ER208I+(B) Quick Installation Guide
Hard Drive Installation
1. Press the key (included in the package) into the lock slot located at the front of the hard drive tray until the tray
handle unlocks.
2. Pull on the tray handle to remove the tray from the enclosure.
3. Dismount the plastic tray protector rods by removing the screws on the sides of the tray.
4. Place the hard drive in the tray, and fasten it with the screws (included in the package) in corresponding locations.
5. Place the tray back into the enclosure and lock the tray by pushing in the tray handle.
Management Methods
There are three management methods to manage EliteRAID and TowerRAID iSCSI Series, describe in the following:
Web GUI
EliteRAID and TowerRAID iSCSI Series support graphic user interface to manage the system. Be sure to connect LAN
cable. The default setting of management port IP is DHCP
.
Type the IP address in the web browser.
Click any function at the first time; it will pop up a dialog to authenticate current user.
Login name: admin
Default password: 0000
Or login with read-only account which only allows reading the configuration and cannot change setting.
Login name: user
Default password: 1234
www.sansdigital.com
|
info
sansdigital.com
|
phone 800 980 1988
|
fax 626 322 3878
@
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sans Digital ER208I+
Summary of Contents for Sans Digital ER208I+
- Page 1 ER208I+(B) Quick Installation Guide Hard Drive Installation 1. Press the key (included in the package) into the lock slot located at the front of the hard drive tray until the tray handle unlocks. 2. Pull on the tray handle to remove the tray from the enclosure. 3.
- Page 2 Console Serial Port Use NULL modem cable to connect console port. The console setting is baud rate: 115200, 8 bits, 1 stop bit, and no parity. Terminal type: vt100 Login name: admin Default password: 0000 Remote Control – Secure Shell SSH (secure shell) is required for controllers to remote login.
- Page 3 Redundant Power Supply The redundant power supply feature consists of hot-swappable power supply modules. If one of the power modules failures, the remaining working modules will continue to provide power to the unit so users do not experience downtime. A replacement power supply could be installed while the unit is running. Once the replacement power supply has been installed, the unit will regain its redundant power feature.
