RIVI RV35 Quick Setup Manual

RV35 Access Point
Quick Setup Guide
This Quick Setup Guide provides step-by-step instructions on how to
set up your RV35 access point. After completing the steps in this
guide, you will be able to place the access point (AP) at your site and
provide network access to wireless clients.
FIGURE 1 RV35: Top View
Before You Begin
Before deploying please check for the latest software and the
release documentation on our online portal.
© 2022 RIVI Networks Ltd. All rights reserved. Trade
Mark No: UK00003636458 Published Jan 2022,
Part Number 800-72902-301 Rev A
Package Contents
A complete Unleashed RV35 installation package
includes all of the following items:
• RV35 Access Point
• One external T-bar bracket (two unassembled parts)
• One unit removal pin
• Declaration of Conformity/Regulatory
Statement
Unleashed Network Configuration
Setup Using the Unleashed Mobile App
To perform setup using the Unleashed Mobile App, download the
iOS or Android app from the app store.
Scan here for IOS app Scan here for Android app
1. As soon as the Unleashed AP is powered on and connected to
the local network, it boots up and begins broadcasting a
temporary unencrypted WLAN named "Configure.Me-
[xxxxxx]" from both radios.
2. Using your client's Wi-Fi connection settings, select and
associate to the "Configure.Me-[xxxxxx]" WLAN.
3. Launch the app, and follow the on-screen instructions to
configure your Unleashed network(s).
FIGURE 2 Unleashed Mobile App for iOS and Android
FIGURE 3 Configuring Unleashed from the Mobile App
Setup Using a Web Browser
1. As soon as the Unleashed AP is powered on and connected to the
local network, it boots up and begins broadcasting a temporary
unencrypted WLAN named "Configure.Me-[xxxxxx]" from both
radios.
2. Using your client's Wi-Fi connection settings, select and
associate to the "Configure.Me-[xxxxxx]" WLAN.
3. Launch a web browser and enter the following into the browser's
URL bar: unleashed.rivinetworks.com, and press Enter.
4. You will be redirected to the Setup Wizard. Complete the steps in
the Setup Wizard and click Finish.
FIGURE 4 Complete the Setup Wizard to set up your
Unleashed network
5. Once the Setup Wizard is finished, a "Configuring system settings and
rebooting" progress screen appears. Wait until the
process is complete.
Page 1 of 4
