RV75
Access Point
Quick Setup Guide
This Quick Setup Guide provides step-by-step instructions on
how to set up your RV75 access point. After completing the
steps in this guide, you will be able to place the access point
(AP) at your site and provide wireless network access to users.
FIGURE 1 RV75 - Top
Before You Begin
Before deploying please check for the latest software and the
release documentation on our online portal.
© 2022 RIVI Networks Ltd. All rights reserved. Trade
Mark No: UK00003636458 Published Jan 2022,
Part Number 800-72377-301 Rev A
Package Contents
A complete RV75 installation package includes all of the
items listed below:
RV75 Access Point
•
One wall-mount anchor kit, including two 1" No. 8 steel pan
•
head Phillips sheet metal screws and wall-mount anchors.
• One external T-bar bracket (two unassembled
parts)
• Service Level Agreement/Limited Warranty
Statement
• Declaration of Conformity
• Regulatory Statement
• This Quick Setup Guide
Unleashed Network Configuration
Setup Using the Unleashed Mobile App
To perform setup using the Unleashed Mobile App, download
the iOS or Android app from the app store.
Scan here for IOS app
Scan here for Android app
1. As soon as the Unleashed AP is powered on and
connected to the local network, it boots up and begins
broadcasting a temporary unencrypted WLAN named
"Configure.Me-[xxxxxx]" from both radios.
2. Using your client's Wi-Fi connection settings, select
and associate to the "Configure.Me-[xxxxxx]" WLAN.
3. Launch the app, and follow the on-screen
instructions to configure your Unleashed network(s).
FIGURE 2 Unleashed Mobile App for iOS and Android
FIGURE 3 Configuring Unleashed from the Mobile App
Setup Using a Web Browser
1. As soon as the Unleashed AP is powered on and
connected to the local network, it boots up and begins
broadcasting a temporary unencrypted WLAN named
"Configure.Me-
[xxxxxx]" from both radios.
2. Using your client's Wi-Fi connection settings, select and
associate to the "Configure.Me-[xxxxxx]" WLAN.
3. Launch a web browser and enter the following into the
browser's URL bar: unleashed.rivinetworks.com, and
press Enter.
4. You will be redirected to the Setup Wizard. Complete the
steps in the Setup Wizard and click Finish.
Complete the Setup Wizard to set up your Unleashed
network
FIGURE 4
Page 1 of 4
