ePower 200AV+ mini
User Manual
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ePower 200AV+ mini and is the answer not in the manual?

Questions and answers

Related Manuals for MSI ePower 200AV+ mini

Summary of Contents for MSI ePower 200AV+ mini

  • Page 1 200AV+ mini User Manual V1.0...

  • Page 2: Table Of Contents

    200AV+ mini User Manual Contents Introduction ......................1 Product features ..................1 Application ..................... 2 System requirements................3 Packing list .................... 3 Safety precautions ..................... 4 Getting to know the adapter ................5 Ethernet interface .................. 5 Adapter's buttons................... 5 Adapter's LEDs..................

  • Page 3: Introduction

    200AV+ mini User Manual Introduction The ePower 200AV+ mini is a mini-PLC pass-through adapter. It can transmit data up to 200 Mbps in the household power line. It can be connected to the power socket directly without wiring. The device provides a female socket by which you can connect your terminal or power stripe directly without an outlet.

  • Page 4: Application

    200AV+ mini User Manual Application High Definition (HD) and Standard Definition (SD) video distribution Higher data rate broadband sharing for power line LAN Shared broadband internet access TV over IP (IPTV) and Voice over Internet Protocol (VoIP) PLC Camera...

  • Page 5: System Requirements

    200AV+ mini User Manual System requirements Operating system: Windows 98SE, 2000, ME, XP 32/64 bit and Vista 32/64 Bit, Win7 32/64 Bit CPU: Intel® Pentium III or better, clock rate faster than 2.0 GHz recommended RAM: At least 128MB...

  • Page 6: Safety Precautions

    200AV+ mini User Manual Safety precautions This device is intended for connection to the AC power line. For installation instructions, please refer to the installation section of this user manual. The following precautions should be taken when using this product.

  • Page 7: Getting To Know The Adapter

    200AV+ mini User Manual Getting to know the adapter Ethernet Interface Ethernet: The Ethernet port connects to an Ethernet network cable. The other end of the cable connects to your computer or other Ethernet-enabled network device. Adapter's Buttons The following table describes the adapter’s buttons.
  • Page 8 200AV+ mini User Manual Figure 2 Top view...
  • Page 9 200AV+ mini User Manual The following table describes the LEDs on the device. Color Behavior Description Green System runs normally. Green Blink System enters the power save (Power) mode. System is resetting. Password synchronization is in progress. PLC adapter is powered off.

  • Page 10: How To Install The Utility

    200AV+ mini User Manual How to install the utility Note: Before installing the PLC utility software, make sure that there is no any other power line utility installed on your computer. If there is another utility installed, please uninstall it and restart your computer.
  • Page 11 200AV+ mini User Manual Step 2 Click Next > to show the following page. Figure 4 Selecting the folder...
  • Page 12 200AV+ mini User Manual Step 3 Click Browse… to select the installation folder, and then click Next > to continue. Figure 5 Completing the installation Step 4 Click Close to complete the installation.

  • Page 13: How To Use The Utility

    200AV+ mini User Manual How to use the Uutility Main tab The Main screen provides a list of all power line devices logically connected to the computer when the utility is running. The top panel shows the local HomePlug devices connected to the network interface card (NIC) of the computer.
  • Page 14 200AV+ mini User Manual same network is displayed above the remote device panel. Network type (Public or Private) depends on the network status of the local device. Autoscan shows whether the autoscan function is on. The following information is displayed for all the devices that appear in the lower panel.
  • Page 15 200AV+ mini User Manual Figure 7 Setting the device password Step3 Click OK to verify the password. The password field accepts the device password in any case formats, with or without dash. A confirmation box appears if the password is entered correctly. If a device is not found, a message appears, providing suggestions to solve the common problems.
  • Page 16 200AV+ mini User Manual Figure 8 Adding the remote device Note: The device must be in the power line (plugged in), so that you can confirm the password and add the device to the network. If the device is not located, a warning message appears.

  • Page 17: Privacy Tab

    200AV+ mini User Manual Privacy tab In the Privacy screen, you can maintain security for the logical network and select the device included in the network. See Figure 9. Figure 9 Privacy tab All HomePlug devices are loaded using a default logical network (network name), which is normally “HomePlug”.
  • Page 18 200AV+ mini User Manual Note: If the network name changes to anything other than HomePlug, the network type in the main screen is displayed as Private. Set local device only This button is used to change the network name and password of the local device. If...

  • Page 19: Diagnostics Tab

    200AV+ mini User Manual Diagnostics tab The Diagnostics screen shows the system information and history of all remote devices appeared over a period of time. See Figure 10. The Upper panel shows technical data concerning software and hardware on the host computer that are used to communicate through HomePlug on the power line network.
  • Page 20 200AV+ mini User Manual Figure 10 Diagnostics tab The Lower panel displays the history of all remote devices appeared on the computer over a certain period of time. All the devices and the parameters of the devices on the power line network are listed. Devices that are active on the current logical network show a transfer rate in the rate column.

  • Page 21: 4.4 About Tab

    200AV+ mini User Manual The diagnostics information displayed can be saved to a text file for later use, or be printed for reference for a technical support call. Click Delete to delete the devices which are no longer part of the network. A dialog window pops up with a confirmation message if the user wants to delete a device whose password has been entered.

  • Page 22: Appendix A Specifications

    200AV+ mini User Manual Appendix A Specifications Chipset Intellon INT6400 Protocol HomePlug AV 1.0 Co-exists with existing HomePlug 1.0 System Support Windows 98SE, 2000, ME, XP 32/64 bit and Vista 32/64 bit PLC Rate 200 Mbps Modulation Band 2~30 MHz...
  • Page 23 200AV+ mini User Manual Appendix B Contact Information For help with the installation or operation of the MSI ePower 200AV mini adapter, please contact us. Technical Support for all MSI Products Notebooks Tel.: 01805-215 521 (0,14 €/Min. german landline!)
