Dacor SGM464CG Planning Manual

CombINATIoN INsTALLATIoNs

030106

Stiffener

NOTE:
1.
The SGM464GG is not approved for installation above an
undercounter wall oven.
Web: http://www.Dacor.com
Corporate Phone: 800-793-0093
single wall oven/Drop-In Cooktop/
slim raised vent
Stud wall
Wall board
Mounting Rail
3"
(76mm)
1 15/16"
(49mm)
3/8"
(10mm)
22 7/16" (570mm) Min.

Cooktop and ERV cutout

All Dacor Drop-In
Cooktops
ERV/PRV
All Dacor
Single Wall Ovens

Support Leg

29 1/2" (749mm) Min.

CUTAwAy sIDEvIEw

3/4" (19mm) Max. backsplash thickness
1/4" (6mm) Min. flat area
2 1/8"
(54mm)
9/32" (7mm)
2 13/16"
(71mm)
1" (25mm)
Min from interior
wall board
6 1/16"
(154mm)
Face of cabinet
Countertop
31 1/4" (794mm)
Minimum from
finished
countertop to
oven platform
counter hieght
Face of cabinet
Finished floor
4 3/4" (121mm)
Typical oven
platform height
2. The PGM365-1 is approved for installation above an
undercounter wall oven.
Specifications are subject to change without notice.
See installation instructions for additional details.
PLANNING
GUIDE
1/1
All Dacor
Drop-In
Cooktops
All Dacor
Single Wall Ovens
36"
(914mm)
Typical
CI.2
