The PressurePro is our groundbreaking and patent-pending line of differential pressure recorders
(manometers).
The PressurePro's capabilities include:
•
NIST Certificate of Accuracy
•
The 4.3" Color LCD with capacitive touchscreen is the best screen in the industry.
•
Advanced Pressure assist feature helps maintain negative air pressure in difficult environments
•
Printer can be replaced in minutes
•
Optional Spanish language operation with a simple language selection
•
16MB of internal data storage provides space for over 2 years of logs
•
Large window for viewing with the lid closed
•
Easy load printer paper
•
International power supply, 85-240 VAC 50-60Hz 15A max
•
Easy and intuitive user interface
Unpacking
The PressurePro arrives fully assembled and prepared for immediate use. Upon opening the package, kindly
inspect for the following components:
• 10 ft. inlet pressure tubing
• Power Cable (6 ft.) with a 90 degree up for ease of use
• 4 rolls of thermal paper
• Owner Manual
• NIST Certificate of Accuracy
Retain both the shipping box and its packing materials for potential future shipments or servicing needs. Should
any items listed on the packing slip be absent or if you have inquiries about your PressurePro, please contact your
dealer or Adaptive Manometer Systems Inc. at (888) 985-3955. Completing and returning the Registration Card is
required to activate the 12-month limited warranty.
PressurePro TM
Differential Pressure Recorder
Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AMS PressurePro
Summary of Contents for AMS PressurePro
- Page 1 Retain both the shipping box and its packing materials for potential future shipments or servicing needs. Should any items listed on the packing slip be absent or if you have inquiries about your PressurePro, please contact your dealer or Adaptive Manometer Systems Inc. at (888) 985-3955. Completing and returning the Registration Card is...
- Page 2 • Pressure Settings All pressure settings on the PressurePro are adjusted in units of negative air pressure. Pressing the “+” button on a pressure setting will increase the negative air pressure setting. Pressing the “–“ button will decrease the negative air pressure setting.
-
Page 3: Table Of Contents
Table Of Contents Page Basic Care Troubleshooting Setup Hanging the PressurePro Loading Thermal Paper Maximum Hose Length Starting/Ending a Job Pressure Assist Outlet Alarm Settings Printer Settings Date and Time Settings Log Rates Zero Calibration Flash Drive/Data Storage Shipping and Repair... -
Page 4: Basic Care
Do not close items onto the screen when closing the case (e.g. the power cord hose, extra paper, etc.). • Ensure that you connect your PressurePro to a power source that adheres to the standards set by the • National Electrical Code. Keep all connections dry. As is the case with any electrical appliance, this unit possesses the potential to pose an electrical shock risk. -
Page 5: Troubleshooting
The PressurePro will • 120v AC outlet . If 120v AC power is being supplied to the PressurePro 2. Unplug from AC power. Then unplug the power cord from the PressurePro. Check the fuse located inside the power cord connecter. If the fuse is blown a spare 20A slow blow replacement fuse is also in the connecter. -
Page 6: Hanging The Pressurepro
Hanging the PressurePro You can mount the PressurePro on a wall to make it easily visible and keep it safe from potential damage on the floor. By hanging it using the handle, you can close the cover, safeguarding the unit from water damage while still being able to see the monitoring screen through the window on the cover. -
Page 7: Starting/Ending A Job
Alarm settings. You can request a printout of the log from the previous job whenever needed. To start a new job 1. If PressurePro is not currently running a job, the status on the Home screen will display "START JOB" at the top. Touch START JOB, 2. -
Page 8: Pressure Assist Outlet
Pressure Assist Outlet (PAO) Adaptive Manometer Systems Inc’s innovative patent pending Pressure Assist Outlet is designed to assist with pressure regulation in difficult environments. The Pressure Assist Outlet is useful: On windy days. • When personnel are entering/exiting the work area. •... -
Page 9: Alarm Settings
NORMAL RANGE is reached. If touched, the alarm toggle icon on the Home screen will change the alarm icon to show a red X to indicate it is muted. Once the alarm condition is over and the PressurePro returns to Normal operation, the alarm will automatically re-arm. -
Page 10: Date And Time Settings
2. Select the job to be printed and press print. Printer Replacement: Use only official PressurePro printers. Other thermal printers will not function correctly and may damage the unit. 1. Unplug the unit from AC power. 2. Turn the unit off. -
Page 11: Zero Calibration
USB Flash Drive: The USB port on the PressurePro enables personnel to collect job logs directly at the job site or back at the office by using a USB flash drive. The USB flash port works with all common pHat 32 USB flash drives. These logs can be reviewed on a PC by utilizing any text viewing program such as Note or Word. -
Page 12: Shipping And Repair
To Erase Job Logs 1. From the Home screen, touch the settings icon to go to the settings screen. 2. From the setting screen, touch MANAGE DATA icon. 3. Select an individual job, group of jobs, or SELECT ALL. 4. Touch delete, then Done when completed. 5. -
Page 13: Warranty
PressurePro Model 1 Warranty Coverage: This warranty covers any defects in materials or workmanship in the PressurePro Model 1 Differential Pressure Recorder (hereinafter referred to as "Product") for a period of one (1) year from the date of original purchase by the original purchaser. - Page 14 Limitation of Liability: To the extent permitted by applicable law, the manufacturer's liability under this warranty is limited to the repair or replacement of the Product as described above. The manufacturer shall not be liable for any indirect, consequential, incidental, or punitive damages arising from the use or inability to use the Product.
- Page 15 PRESSUREPRO™ Registration/Warranty This information must be provided within 30 days of purchase to activate the 12 Month Warranty. Registration may be mailed to our office or submitted online at info.adaptivemonometers.com Manometer Differential Pressure Recorder Date of Purchase: ________________________ Retail Supplier: __________________________...
