Idutex XTUNER E3 Quick Start Manual

Features
Extensive vehicle coverage for more than 70 brands (including US
domestic, European, Asian, Australian and Chinese vehicles makes).
Complete function capability including live data, ECU programming and so
many others.
Unparalleled OBDII functionalities-support ALL 5 OBDII protocols and ALL
10 test modes.
Automatic Wi-Fi or Bluetooth updates available in new software releases.
Wi-Fi internet capability allows for wireless access throughout the
workshop.
Can check out the year and model of the vehicles automatically and quickly.
Hardware architecture uses a new design with multiple protection,
interference and stability. Built-in overvoltage protection module is applied,
in order to protect scanner and vehicle against accidental damage during
checking.
Can work stably in high and low temperature environment, and work well.
The genuine Windows XP/7/8/10 operating systems allows for more stable
performances, better compatibility and expandability
Extremely easy-to-use with touch-screen operation and intuitive operation
in the windows.
Specifications
Operating System Windows XP/7/8/10
ARM 32-bit Cortex processor
Processor
Communications 802.11 b/g Wireless LAN
Input Voltage DC 8-16V
-10 to 70 ℃(14 to 158 ℉), Relative Humidity: <90%
Operating Temperature
Storage Temperature -30 to 120 ℃(-22 to 248 ℉), Relative Humidity: <90%
Wi-Fi or Blue tooth
Communication model
Dimension 150mm (5.91") * 94mm (3.70") * 40mm(1.57")
NW:0.07kg (0.154lb) GW:0.166kg (0.366lb)
Unit Weight
Protocols UDS, ISO 9141-2, K/L lins, SAE-J1850 VPW, SAE-
J1850 PWM, CAN ISO 11898 ISO 15765-4, High speed,
Middle speed, Low speed and Single wire CAN
1. Software operating environment
Hardware requirements: laptop, PC and PAD with Wi-Fi or Bluetooth.
Space of system disk can't less than 5G, and RAM can't less than 1G.
Operating Systems: Supporting Windows XP/7/8/10, but not Windows RT.
Network requirements: The software needs to be activated & downloaded
online, so please make sure your internet is connected.
2. Software downloading
Opening the website:
http://www.tdintel.com
Home page>>Support page
Then find the right software to download and install.
3. Software activation
At first, please keep network working. Run XTUNER APP, then click
"Online store" to get applications.
DTC Query App Mall
Diagnosis Service Test Track Feedback
Data record
Expert Service Data manage User Management
Mainteanance Service Dictionary Manual Settings Exit
Please input the hardware S/N number and password and then press "Login".
Login
Input the hardware S/N
E316120001
Input the password(In the password envelope)
Show password
*********
Login Cancel
If the product is not activated, please press"Yes".
Login
The product is not activated,
please register and activate first.
Yes No
Login Cancel
Please input your information, the email address and country is required,
and then press "Activate".
Activation
Email* service@tdintel.com Country/Region* China
Company TDINTEL TECH Co., Ltd.
*required
Please input correct information for better service!
Activate Cancel
After the information has been committed, please log in your email to
activate
Activation
Email* service@tdintel.com Country/Region* China
Company TDINTEL TECH Co., Ltd.
Customer information is committed
successfully!
The activated link has been sent to your
email, please log in your email and click
the link to activate the product.
*required
Please input correct information for better service!
Yes No
Activate Cancel
