Summary of Contents for Idutex PU630
-
Page 2: Table Of Contents
Shenzhen IDUTEX Tech Co., Ltd Table of Contents 1 Statement......................1 1.1 Agreement.....................1 1.2 Copyright information................1 1.3 Disclaimer..................... 2 1.4 Safety Information................2 1.4.1 Inspection Precautions............2 1.4.2 Notes on the use of the instrument........3 1.4.3 Operating car ECU considerations........4 2 Product description..................5 2.1 Product Overview.................5... - Page 3 Shenzhen IDUTEX Tech Co., Ltd 3.12 User....................18 4 Vehicle Diagnosis..................19 4.1 First login activation................19 4.2 Data download and product connection......... 21 4.2.1 Download data............... 21 4.2.2 VCI and vehicle connection..........23 4.2.3 Tablet and VCI Bluetooth connection........23 4.3 Vehicle diagnosis................24 5 Software upgrade..................
-
Page 4: Statement
1 Statement You must carefully read the instruction manual, especially the safety instructions, before you can connect, commission and operate the products of Shenzhen IDUTEX Tech Co., Ltd. (hereinafter referred to as “IDUTEX”). 1.1 Agreement Once the product is used, it is an endorsement of the following: (1) Please refer to the packing list of the random distribution for the configuration equipment of this product, whichever is the actual product;... -
Page 5: Disclaimer
1.4.1 Inspection Precautions (1) IDUTEX PU-630 can only be connected to a safety outlet that is grounded. Before connecting, check and confirm that the diagnostic circuit is in good condition. Otherwise, it is not necessary to test to avoid damage to the main unit. -
Page 6: Notes On The Use Of The Instrument
Shenzhen IDUTEX Tech Co., Ltd pressure. (4) Exhaust gases from the engine contain a variety of toxic compounds and should be avoided. Park the vehicle in a well ventilated area before operation. (5) Do not place the device on the vehicle's power distribution unit. Strong electromagnetic interference can cause damage to the equipment. -
Page 7: Operating Car Ecu Considerations
Shenzhen IDUTEX Tech Co., Ltd (4) When the electrical components are energized, the circuit cannot be disconnected to prevent self-inductance, mutual inductance and current sensors and the vehicle ECU. (5) The operation of this instrument requires a certain basis for vehicle inspection and maintenance, and has a certain understanding of the electronic control system of the vehicle under test. -
Page 8: Product Description
2.1 Product Overview IDUTEX PU-630 Android-based multifunctional diagnostic tool with 8 inch tablet developed by IDUTEX. It has an extensive vehicle coverage for over 70 car makers from America, Asia, Europe, Australia and China to meet your basic vehicle diagnostic needs. -
Page 9: Host Structure Description
Shenzhen IDUTEX Tech Co., Ltd Lights up when the VCI is Light indicator connected to the vehicle ① diagnostic interface OBD connector For connection to the vehicle ② diagnostic interface VCI Box Parameters ARM 32-bit Cortex processor Processor Bluetooth Communications... - Page 10 Shenzhen IDUTEX Tech Co., Ltd 2.3-1 Host front Name Description Screen For screen display ① Front camera For taking pictures or recording video ②...
- Page 11 Shenzhen IDUTEX Tech Co., Ltd 2.3-2 host back Name Description Rear camera For taking pictures or recording video ③...
- Page 12 Shenzhen IDUTEX Tech Co., Ltd 2.3-3 Host right Name Description Long press the hole through the Reset hole ④ needle to reset the tablet Volume － lower the volume ⑤ Volume + Increase the volume ⑥ For turning the tablet ON and OFF, or Power switch ⑦...
- Page 13 Shenzhen IDUTEX Tech Co., Ltd 2.3-5 Host bottom Name Description speaker Audio output ⑩ Host parameters Screen Size 8〃 1200*1920 IPS Operating system Android 8.0 MTK*20(MT6797) Ten-core 4G call Hardware platform 64-bit(A72*2 2.1GHz+A53*4 1.85GHz+A53+4 1.4GHz) ROM Storage 32GB Front camera 2 million pixels, Rear camera 5...
-
Page 14: Product Menu Introduction
Shenzhen IDUTEX Tech Co., Ltd 3 Product menu introduction Turn on the power switch, turn the host on, and enter the following interface: 3.1 Diagnosis Vehicle diagnosis, different car systems, systems, etc., based on the actual display menu. -
Page 15: Special Function
Shenzhen IDUTEX Tech Co., Ltd 3.2 Special function Including BLEEDING, BATTERY, ,EPB, IMMOKEYS, INJECTOR, OILRESET, SAS, THROTTLE, TPMS, etc. -
Page 16: Update
Shenzhen IDUTEX Tech Co., Ltd 3.3 Update After logging in, you can view the model/system data. • Support WIFI automatic upgrade and one-click upgrade, easy to operate • Provides version information, software release time, and software upgrades, so users can quickly learn about updates. -
Page 17: Data Manager
3.4 Data Manager The storage location of vehicle applications, test pictures, videos, reports and for user reference. 3.5 Quick Support The function allows IDUTEX technical staff to connect to your host through the network remotely to help you diagnose the vehicle. -
Page 18: Dtc Query
Shenzhen IDUTEX Tech Co., Ltd 3.6 DTC Query The fault information corresponding to the fault code can be quickly retrieved to help the repairer locate the component fault. 3.7 Feedback This function allows you upload vehicle diagnostics problems encountered by users during the use of the software. It can help engineers repair... -
Page 19: Data Playback
Shenzhen IDUTEX Tech Co., Ltd 3.8 Data Playback Users can play back data and quickly analyze the communication data between the vehicle and the diagnostic tool to find out the problem. 3.9 Dictionary Support online search for words. Use a third-party tool to provide a... -
Page 20: User Manual
Shenzhen IDUTEX Tech Co., Ltd 3.10 User Manual Users can view the different systems and corresponding functions supported by the data packet. 3.11 Settings View or set the operating mode, unit, search engine, VCI information, OS version, about us, etc. -
Page 21: User
Shenzhen IDUTEX Tech Co., Ltd • OS version: You can check the current software version and manually check if there is a new version. The software itself can automatically prompt for updates. About: Including company profile, company culture and company •... -
Page 22: Vehicle Diagnosis
Shenzhen IDUTEX Tech Co., Ltd 4 Vehicle Diagnosis 4.1 First login activation 1) Press and hold the power switch to start the host. Click the software icon. (2) Click the 【Update】button. - Page 23 Shenzhen IDUTEX Tech Co., Ltd (3) Enter the account number and password on the password envelope, click 【Login】, and a prompt box will pop up. (4) Click 【Yes】 to fill in the activation information. (5) After the information is filled out, click 【ACTIVATION】.
-
Page 24: Data Download And Product Connection
Shenzhen IDUTEX Tech Co., Ltd (6) Log in to the mailbox where you just filled in the activation information and click the activation link to complete the activation. 4.2 Data download and product connection 4.2.1 Download data (1) Click 【App Store】 on the main screen of the software and log in. - Page 25 Shenzhen IDUTEX Tech Co., Ltd After checking the check box before the data, click the Download icon to download the vehicle type data for the vehicle to be diagnosed. Note: • Diagnostic vehicles must download [Common Data] and other vehicle model data required;...
-
Page 26: Vci And Vehicle Connection
Shenzhen IDUTEX Tech Co., Ltd 4.2.2 VCI and vehicle connection Connect the VCI box to the vehicle to be diagnosed through the main test leads and diagnostic connector. After the connection is successful, the power light is on and the Bluetooth indicator is flashing. -
Page 27: Vehicle Diagnosis
Shenzhen IDUTEX Tech Co., Ltd Turn on the tablet Bluetooth. (2) Wait a moment, you can search for the ID of the VCI box connected to the vehicle. Click to pair. (3) After the pairing is successful, the Bluetooth indicator of the VCI device is steadily displaying blue.The VCI icon at the bottom of the screen is... -
Page 28: Software Upgrade
Shenzhen IDUTEX Tech Co., Ltd 5 Software upgrade The system will automatically prompt for updates, or you can manually detect updates by: Click the 【Settings】 button from the main screen of the software. -
Page 29: Cleaning And Maintenance And Warranty
Shenzhen IDUTEX Tech Co., Ltd (2) Click【OS version】-【Check update】. (3) If there is a new version, download and then install it. 6 Cleaning and maintenance and warranty 6.1 Cleaning and maintenance (1) Do not disassemble it, try to handle it gently to avoid impact. -
Page 30: Warranty
6.2 Warranty This applies only to products purchased from a product dealer that has been authorized by IDUTEX. If products are purchased from anyone other than a IDUTEX authorized product dealer, buyers will be solely responsible for the cost of product maintenance services and will not be eligible to obtain any warranty from IDUTEX . - Page 31 (4) Not in the scope of the free warranty A. Failures, defects or flaws not directly related to the quality of the IDUTEX products, including but not limited to failing to use the product according to the user manual’s instructions, crash, fall, disassemble by...
- Page 32 Shenzhen IDUTEX Tech Co., Ltd Note: The valid purchase certificate is an important warranty service certificate. To protect your legal rights, you must obtain a formal invoice from the dealer when purchasing the machine. The name, model number, serial number and purchase date of the product should be clearly stated on the invoice.
- Page 33 Shenzhen IDUTEX Tech Co., Ltd...
