Promaster 252 / 260 / 266 / 272
Owner/Operator Manual
Manuel Du Propriétaire/Utilisateur
992150 - PM252H XDZ
992152 - PM260M XDZ
992154 - PM260H XDZ
992156 - PM260H XDZ
992159 - PM260H XDZ
992160 - PM272H XDZ
992161 - PM252M XDZ
992162 - PM260M XDZ
992163 - PM252H XDZ
Models
ENGLISH
FRANÇAIS
992164 - PM260H XDZ
992165 - PM266M XDZ
992166 - PM260H XDZ
992167 - PM266H XDZ
992168 - PM272H XDZ
992170 - PM266H XDZ
992175 - PM260M XDZ
992176 - PM252M XDZ
US Patent 6,301,864
03899100 8/09
Printed in USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Promaster 266 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gravely Promaster 266

Summary of Contents for Gravely Promaster 266

  • Page 1 Promaster 252 / 260 / 266 / 272 Owner/Operator Manual Manuel Du Propriétaire/Utilisateur Models 992150 - PM252H XDZ 992164 - PM260H XDZ 992152 - PM260M XDZ 992165 - PM266M XDZ 992154 - PM260H XDZ 992166 - PM260H XDZ 992156 - PM260H XDZ 992167 - PM266H XDZ 992159 - PM260H XDZ 992168 - PM272H XDZ...

  • Page 2: Table Of Contents

    English may be obtained from your completely read your manuals. The contents Dealer. Visit your dealer or will provide you with an understanding of www.gravely.com for a list of safety instructions and controls during normal languages available for your operation and maintenance.
  • Page 3 UNAUTHORIZED REPLACEMENT NOTE: To locate your nearest Gravely dealer, PARTS go to www.gravely.com on the internet Use only Gravely replacement parts. The replacement of any part on this vehicle with...

  • Page 4: Safety

    SAFETY WARNING: This cutting machine WARNING: POTENTIALLY is capable of amputating hands HAZARDOUS SITUATION! If not and feet and throwing objects. avoided, COULD RESULT in Failure to observe the safety death or serious injury. instructions in the manuals and on decals could result in serious injury or death.
  • Page 5 Figure 2 OF1624 1. DANGER! TO AVOID SERIOUS Go up and down slopes, not across. INJURY OR DEATH 17° DO NOT operate on slopes over 17°. OL4450 Read Operator’s Manual. • If machine stops going uphill, stop blade and back down slowly. OL1801 •...
  • Page 6 Emission Keep people away from unit controls and components can only be while operating. adjusted by EPA and/or CARB authorized service centers. Contact your Gravely Equipment Retailer concerning emission OL3292 controls and component questions. Shut off engine, remove key,...
  • Page 7 Data indicates that operators, age 60 and Fumes from the engine exhaust can cause above, are involved in a larger percentage of death or serious injury. DO NOT run engine in riding mower related injuries. These an enclosed area. Always provide good operators should evaluate their ability to ventilation.
  • Page 8 DO NOT operate at too fast a rate. DO NOT Follow the manufacturer’s recommendations change engine governor settings or over- for weight limits for towed equipment and speed engine. Slow down before turning. towing on slopes. DO NOT operate in reverse unless absolutely NEVER allow children or others in or on necessary.
  • Page 9 Avoid Electric Shock. Objects contacting both NEVER store unit with fuel in fuel tank, inside battery terminals at the same time may result a building where any ignition sources are in injury and unit damage. DO NOT reverse present. battery connections. Shut off fuel and allow engine to cool Reverse connections may result in sparks completely before storing in closed area or...

  • Page 10: Assembly

    ASSEMBLY Place Discharge Chute in Operating Position WARNING: AVOID INJURY. Read and understand entire Safety section before proceeding. WARNING: Do not operate mower unless the discharge chute is in the operating position. Unpack Unit Remove unit and all other components from Prior to operating the unit, remove the shipping container.
  • Page 11 Check Tire Pressure Check Coolant Level (992152, 156, 159, 160, 176) Refer to Engine Manual. CAUTION: Avoid injury! Explosive separation of tire and rim parts is Fill Fuel Tank possible when they are serviced See FILLING FUEL TANK on page 15. incorrectly: •...

  • Page 12: Controls And Features

    CONTROLS AND FEATURES Dash Panel for Models 992156, 160 28 or 29 12, 14 Dash Panel for Models 992150, 152, 154, 159, 161, 162, 163, 164, 165, 166, 167, 168, 170, 175, 176 Figure 5 OF3223 1. Hood 20. Glow Plug Light (992156, 160) 2.

  • Page 13: Operation

    Perform the following tests to ensure the safety interlock system is working properly. If Throttle Lever the unit does not perform as stated, contact your Gravely dealer for repairs. Changes the speed of engine. IMPORTANT: With the parking brake engaged, the steering levers must be locked in neutral.
  • Page 14 Oil Pressure Light (992150, 154, 161, Steering Levers 162, 163, 164, 165, 166, 167, 168, 170, Control 175) speed, directional Indicates when engine oil control, and pressure is low. stopping unit. NOTE: It does not •Reverse (1) indicate engine oil level. –...
  • Page 15 Cylinder Stops (992150, 154, 156, 159, 160, 163, 164, 166, 167, 168, 170) CAUTION: AVOID PINCH POINTS. Always use the T-portion of the cylinder stop when removing or installing the cylinder stops. Ensure the same cutting height after raising mower deck to clear an obstacle. Cylinder 1.
  • Page 16 • Do not modify the fuel system to use 6. Adjust Seat different fuels. Be sure all controls can be reached safely • Never mix oil and gasoline. from operator’s position. NOTE: All gasoline is not the same. If the 7.
  • Page 17 To Start Diesel Units (992156, 160): 3. Disengage parking brake. 4. Push unit to desired location. 1. Insert ignition key. 5. Engage parking brake. 2. Move the throttle to 3/4 fast position. 6. Turn right and left bypass valves 3. Turn ignition key to Run (2) position. The clockwise 1/2 turn.

  • Page 18: Maintenance Schedule

    MAINTENANCE SCHEDULE Proper maintenance can prolong the life of unit. The following chart shows the WARNING: AVOID INJURY. Read recommended service schedule. More and understand entire Safety frequent service may be required due to section before proceeding. working conditions (heavy loads, high ambient temperatures, dusty conditions, or airborne debris).
  • Page 19 Interval Task Action Every Check Mower Ensure mower blade hardware is tightened to 115 – 160 lbf-ft. Blades (156 – 217 N•m). Check mower blades for wear. Sharpen or Hours replace mower blades as needed (see SHARPENING MOWER BLADE on page 23). Every Lubricate Oil all pivot points, pin connections, and apply grease to front...

  • Page 20: Service And Adjustments

    Gravely Dealers will provide any service which may be required to keep your unit operating at peak efficiency. Should engine service be required, it can be obtained from a Gravely Dealer or the engine manufacturer’s authorized service center. WARNING: AVOID INJURY. Read and understand entire Safety section before proceeding.
  • Page 21 Battery Removal and Installation Battery for models 992150, 152, 154, Removal (Figure 10) 159, 161, 162, 163, 164, 165, 166, 167, 168, 170, 175, 176 1. Place unit in the service position (see SERVICE POSITION on page 20). 2. Disconnect negative (–) cable first, then positive (+) cable.
  • Page 22 Removal and Installation on page 21). 1. Install mower blades, washers, and bolts Jump-Starting on spindle shafts. Gravely does not recommend jump-starting 2. Tighten bolts to 115-160 lbf-ft your unit. Jump-starting can damage engine (156-217 N•m). and electrical system components. See your Engine Manual for more detailed information.
  • Page 23 SHARPENING MOWER BLADE 3. Check mower blade balance. Slide mower blade on an unthreaded bolt. A NOTE: If mower is used under sandy soil balanced blade should remain in a conditions, replace mower blades when air horizontal position. If either end of lifts become eroded through at ends mower blade moves downward, sharpen (figure 12).
  • Page 24 Increased Spring Length = Decreased Force to Lift Mower Deck 1. Eye-Bolt 2. Mechanical Lift Spring Figure 15 Decreased Spring Length = OF4040 Increased Force to Lift 4. Lower mower deck all the way down. Mower Deck 5. Remove link chains from mower lift arms (figure 16).
  • Page 25 Check Blade Level and Pitch Blade Side-to-Side Level 1. Raise mower deck to a 3 in. (7.62 cm) cutting height. Right Left 2. Shut off engine. Engage parking brake. Remove the ignition key. NOTE: Place blocks under the bottom edge of the deck, not under the reinforcement bar welded along deck face.
  • Page 26 NOTE: The Ogura electric clutch can be adjusted if the clutch starts to slip. Contact your Gravely dealer for this adjustment. See CLUTCH ADJUSTMENT on page 32. Removal (Figure 20) 1. Open footboard (see MOWER DRIVE BELT AND PTO BELT ACCESS on page 26).
  • Page 27 Installation (Figure 21) MOWER DRIVE BELT REMOVAL 1. Install the new PTO belt on electric Removal (Figure 20) clutch, idler pulleys, and blade spindle NOTE: The PTO belt must be removed from pulleys. blade spindle pulleys prior to removing 2. Place 1/2-inch driver and ratchet mower drive belt.
  • Page 28 Installation (Figure 22) 1. Install new hydro pump belt by positioning belt on sheaves. Put belt onto right hand hydrostat sheave last. 2. Replace clutch anchor. 3. Install PTO belt on electric clutch (see PTO BELT REMOVAL on page 26). 1.
  • Page 29 STEERING CONTROL NEUTRAL Eliminating Excessive Creeping of the Unit (Figure 24) ADJUSTMENT If the steering levers do not line up (match) or the unit has excessive creeping when the WARNING: This adjustment steering levers are in neutral, adjust as requires operating the engine and follows.
  • Page 30 ADJUSTING UNIT TO TRACK STEERING LEVER HANDLE STRAIGHT HEIGHT ADJUSTMENT The handles have three height positions (figure 26). WARNING: Prior to adjusting the tracking of the unit, shut off engine, engage parking brake, and remove the ignition key. Check and adjust tire pressure. Increase pressure on side unit tracks to.
  • Page 31 Adjusting the parking brake HYDRAULIC OIL SYSTEM 1. Engage parking brake. WARNING: HYDRAULIC FLUID 2. Turn jam nuts counterclockwise until the can result in severe burns. Fluid in spring is completely extended and there hydraulic system can penetrate is no pressure on the spring. skin and result in serious injury or 3.
  • Page 32 Changing Hydraulic Oil and Filter 3. If coolant is below the low mark, remove cap, and add coolant to the full mark. NOTE: Change the hydraulic oil filter and Refer to Engine Manual for the correct hydraulic oil every 500 hours. Use Mobil 1 type of coolant.

  • Page 33: Storage

    3. Loose or corroded 3. Clean and tighten battery cables. battery cables (see SERVICING THE BATTERY on page 20). 4. Discharged battery. 4. Charge battery (see SERVICING THE BATTERY on 5. Faulty starter. page 20). 5. See your Gravely Dealer. GB - 33...
  • Page 34 992156, 160. 3. Radiator plugged with 3. Clean radiator. Refer to debris. Engine Manual. 4. Faulty radiator. 4. See your Gravely dealer. Oil Pressure / Coolant 1. Engine oil level low. 1. Refer to Engine Manual. Temperature Light is 2.
  • Page 35 1. Operator presence 1. Depress operator switch not depressed. presence switch by do not engage or shuts sitting on seat. off. 2. See your Gravely 2. Faulty PTO switch. Dealer. Unit does not drive. 1. Parking brake 1. Disengage parking engaged.

  • Page 36: Accessories

    ACCESSORIES ACCESSORIES Part No. Description Part No. Description 89201100 Snow Blade Kit (Requires kit 79101000 Solid Tire Kit 89203200 & 79204500) 79202600 60- and 72-Inch Striper Kit (Hydraulic Lift Models) 79202700 Headlight Kit 79204500 Weight Kit 79204000 Eye-Q Engine RPM Kit 89201300 Debris Blower Kit (Requires kit 89203200 &...

  • Page 37: Service Parts

    SERVICE PARTS SERVICE PARTS Part No. Qty Description Part No. Qty Description 07200435 1 66-Inch Right-Hand Mower 21536900 1 Air Filter Element (992150, Drive Belt - Kohler & 152, 154, 156, 158, 159, Kawasaki Vertical Shaft 160, 170, 176) 07200038 1 60-Inch Right-Hand Mower 21537000 1 Outer Primary Element...

  • Page 38: Specifications

    SPECIFICATIONS Model Number 992150 992152 992154 992156 Model PM252H XDZ PM260M XDZ PM260H XDZ PM260H XDZ Engine Engine Kohler Kawasaki Kohler Daihatsu Diesel Engine Model Number CV740S FD731V CV740S 950D Displacement - in. (cc) 44.0 (725) 41.19 (675) 44.0 (725) 58.1 (952) Governed RPM (May be different from...
  • Page 39 SPECIFICATIONS Model Number 992150 992152 992154 992156 Model PM252H XDZ PM260M XDZ PM260H XDZ PM260H XDZ Tires Front Tire Size – in. (cm) 15 x 6-6 (38 x 15-15) Rear Tire Size – in. (cm) 24 x 12-12 (61 x 30-30) Front Tire Pressure –...
  • Page 40 SPECIFICATIONS Model Number 992159 992160 992161 Model PM260H XDZ PM272H XDZ PM252M XDZ Engine Engine Kawasaki Daihatsu Diesel Kawasaki Engine Model Number FD731V 950DT FX751V Displacement - in. (cc) 41.19 (675) 58.09 (952) 51.99 (852) Governed RPM (May be different from 3600 3650 maximum RPM)
  • Page 41 SPECIFICATIONS Model Number 992159 992160 992161 Model PM260H XDZ PM272H XDZ PM252M XDZ Front Tire Pressure – psi (kPa) 20 – 25 (138 – 172) Rear Tire Pressure – psi (kPa) 12 – 15 (83 – 103) Mower Deck Mower Deck Lift Hydraulic Mechanical Cutting Width –...
  • Page 42 SPECIFICATIONS Model Number 992162 992163 992164 992165 Model PM260M XDZ PM252H XDZ PM260H XDZ PM266M XDZ Engine Engine Kawasaki Engine Model Number FX751V FX751V FX751V FX850V Displacement - in. (cc) 51.99 (852) Governed RPM (May be different from maximum 3650 RPM) Liquid or Air Cooled Cooling System Capacity...
  • Page 43 SPECIFICATIONS Model Number 992162 992163 992164 992165 Model PM260M XDZ PM252H XDZ PM260H XDZ PM266M XDZ Rear Tire Pressure – psi (kPa) 12 – 15 (83 – 103) Mower Deck Mower Deck Lift Mechanical Hydraulic Hydraulic Mechanical Cutting Width – in. (cm) 60 (152) 52 (132) 60 (152)
  • Page 44 SPECIFICATIONS Model Number 992166 992167 992168 992170 Model PM260H XDZ PM266H XDZ PM272H XDZ PM266H XDZ Engine Engine Kawasaki Kohler Engine Model Number FX850V FX850V FX850V CV750S Displacement - in. (cc) 51.99 (852) 45.58 (747) Governed RPM (May be different from maximum 3650 3600 RPM)
  • Page 45 SPECIFICATIONS Model Number 992166 992167 992168 992170 Model PM260H XDZ PM266H XDZ PM272H XDZ PM266H XDZ Rear Tire Pressure – psi (kPa) 12 – 15 (83 – 103) Mower Deck Mower Deck Lift Hydraulic Cutting Width – in. (cm) 60 (152) 66 (168) 72 (183) 66 (168)
  • Page 46 SPECIFICATIONS Model Number 992175 992176 Model PM260M XDZ PM252M XDZ Engine Engine Kawasaki Engine Model Number FX850V FX731V Displacement - in. (cc) 51.99 (852) 41.19 (675) Governed RPM (May be different from maximum 3650 RPM) Liquid or Air Cooled Liquid Cooling System Capacity Refer to Engine Manual Speed...
  • Page 47 SPECIFICATIONS Model Number 992175 992176 Model PM260M XDZ PM252M XDZ Tires Front Tire Size – in. (cm) 15 x 6-6 (38 x 15-15) Rear Tire Size – in. (cm) 24 x 12-12 (61 x 30-30) Front Tire Pressure – psi (kPa) 20 –...
  • Page 48 Genuine Ariens or Gravely brand service parts and accessories are warranted to be free from defects in material and workmanship for a period of 90 days after the date of purchase. An authorized Ariens or Gravely dealer will repair or replace any such part or accessory free of charge, except for labor, during that period.

  • Page 49: Warranty

    Eye-Q™ and Scan-Mate™ units are covered by their own warranty and are not covered by this warranty. • Parts that are not genuine Ariens or Gravely service parts are not covered by this warranty. • The following maintenance, service and replacement items are not covered by this warranty unless...
  • Page 50 GRAVELY 655 West Ryan Street Brillion, WI 54110-1072 920-756-2141 Fax 920-756-2407 www.gravely.com WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.
