10.2 Installation of module M.2 2280

Unscrew the retaining screw on the stop and remove it. Slide the M.2 2280
gently into the connector until the cut-out in the module fits into the socket.
Secure the module by gently screwing it to the housing. Replace the
compartment cover and tighten the screws that secure it.
With the help of the tool located in:
Control panel \ All elements of the control panel \ Administrative tools \ Computer
management \ Disk management
you can create and delete partitions on the new disc. Once you have set up your
operating system partition, find the new disc and format it according to your
preferences.
We strongly advise against any manipulation of the parameters of " Disc 0 ",
which is a system disc, as any problems caused by interference in its structure may
result in voiding the warranty.

12. Safety remarks

12.1 Troubleshooting

If you have any problems with the device, please read the following advice and
follow the instructions below.
• MicroSD Memory Card - Make sure that the microSD memory card is
installed correctly in the correct microSD slot for the microSD cards. If it
does not help use another memory card of appropriate class and capacity.
• USB socket - Check the cable by connecting another device. If it doesn't
help, use another cable.
• Internet / Wi-Fi - Check if the aeroplane mode is not on because it disables
using any wireless network functions. Check network range. Check if the
function is activated in the device and the parameters set correctly. Check
the login password to the Wi-Fi network.
• Bluetooth - check whether the connection is active and Bluetooth
visibility options are enabled. Make sure that both devices are in Bluetooth
connection range and there are no obstacles between them (interesting
fact - some LCDs absorb magnetic waves). Make sure that the devices have
a sufficient amount of memory to exchange files. Check if both devices
work in aeroplane mode (Aeroplane mode blocks Bluetooth).
• Sounds - make sure that the sound in the laptop is not muted. Check other
laptop sound settings. Make sure that the headset, speaker, or microphone
cable plug is not plugged into the 3.5 mm mini-jack socket.
Some minijack tips are different from others, and this may also cause a
sound problem - try a different cable or use an adapter.
• Although the battery is being charged, its level of charge is constantly
dropping - turn off all options such as Wi-Fi, Bluetooth, Location, and then
