aspira induction
Model:
Centrale on board B4O 83
GB
INSTRUCTIONS ON MOUNTING AND USE
MONTAGE- UND GEBRAUCHSANWEISUNG
D
F
PRESCRIPTIONS DE MONTAGE ET MODE D'EMPLOI
ES
MONTAJE Y MODO DE EMPLEO
ISTRUZIONI DI MONTAGGIO E D'USO
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B4O 83 and is the answer not in the manual?

Questions and answers

Related Manuals for AIRFORCE B4O 83

Summary of Contents for AIRFORCE B4O 83

  • Page 1 Model: Centrale on board B4O 83 INSTRUCTIONS ON MOUNTING AND USE MONTAGE- UND GEBRAUCHSANWEISUNG PRESCRIPTIONS DE MONTAGE ET MODE D’EMPLOI MONTAJE Y MODO DE EMPLEO ISTRUZIONI DI MONTAGGIO E D’USO...
  • Page 3 Per tutte le operazioni di installazione e manutenzione utilizzare guanti da lavoro Always wear work gloves for all installation and maintenance operations Bei allen Installations- und Instandhaltungsarbeiten immer Schutzhandschuhe tragen. Draag bij alle installatie- en onderhoudswerkzaamheden werkhandschoenen. Todas las operaciones de instalación y mantenimiento se deben realizar utilizando guantes de trabajo. Para todas as operações de instalação e manutenção, utilize luvas adequadas para este tipo de atividade Πάντοτε...
  • Page 5 X + 477 X ( Min 135 ) X - 17,5 32.5...
  • Page 7 Torx t10...
  • Page 8 Torx t10 KTFOBH10...
  • Page 9 > KTFOBH10 Installation A Installation B > > >...
  • Page 10 Installation A Installation B Min.135 Max.140 Max.140...
  • Page 11 Installation B Installation A silicone X (Min.135) X-50 Torx t10 X-50...
  • Page 12 Installation A Installation B silicone...
  • Page 13 Installation A Installation B Torx t10...
  • Page 14 Installation A Installation B Y= H-395 > H-395...
  • Page 16 Plus Standard...
  • Page 17 Standard Plus accessories at page 37 Standard Plus accessories at page 37 accessories at page 37...
  • Page 18 Standard Plus AFCFCAASPC78...
  • Page 19 Standard Plus X=13 Z=230 AFCONFRACFP X=16 Z=250 accessories at page 37 accessories at page 37...
  • Page 20 KTFOBH6...
  • Page 21 KTFOBH6 Installation C Installation D >...
  • Page 22 Installation C Installation D Min.135 Max.140 Max.140...
  • Page 23 Installation C Installation D silicone X (Min.135) X-50 Torx t10 X-50...
  • Page 24 Installation C Installation D silicone...
  • Page 25 Installation C Installation D Torx t10...
  • Page 26 Installation C Installation D...
  • Page 31 Standard Plus AFCFCAASPC78...
  • Page 32 Standard Plus AFFCARFPH6...
  • Page 35 Accessories AFC4043001 (1000mm) AFC4043005 AFC4021003 AFC4043004 (90°) AFC4043003 (90°) AFCRAC0120994 AFC4043007 (15°) AFC4043006 AFC4043002 AFFCARFPH6 AFCONFRACFP KRASP003 KRFH6 AFCFCARFP AFCFCAASPC78...
  • Page 36 Nach der Installation Ueberprüfen Sie, ob das Produkt ordnungsgemäß funktioniert, danach warten Sie 24 Stunden, damit das Silikon vollständig trocknen kann. Once installation is complete, verify the correct functioning of the product, then wait 24 hours to allow the silicone to dry completely. Une fois l’installation terminée, vérifier que le produit fonctionne correctement.
  • Page 38 CLEANING AND MAINTENANCE FUNZIONAMENTO WARNINGS Caution his instruction handbook is conserved together with the centrale ob for future consultation. If the equipment is sold or transferred to another person, make certain the instruction handbook is supplied together with it, so that the new user can become aware of the operation of the cooker hood and related warnings.
  • Page 39 ANWEISUNGEN WARNINGS leaning and maintenance must not be carried out by children without proper supervision. f the power cord is damaged, it must be replaced by a qualified service centre or technician only. AUTION: The hob protection devices must be only those designed by the appliance manufacturer or those indicated as suitable in the manufacturers instructions or the hob protection devices incorporated in the appliance.

  • Page 40: Fire Hazard

    ANWEISUNGEN WARNINGS he induction hob should not be used as a work surface. The rough underside of food containers can scratch the surface of the cooktop. lways keep the cooking areas and underside of food containers perfectly dry. Fire hazard il and grease that are too hot will catch fire quickly.

  • Page 41: Burn Hazard

    ANWEISUNGEN WARNINGS Burn hazard AUTION: This appliance and its accessible parts become very hot during use. ay attention to avoid touching the heating elements. eep children under 8 years of age away from the appliance, unless they are continually monitored. o not place objects such as knives, forks, spoons or lids on the induction top, as they may overheat.
  • Page 42 ANWEISUNGEN WARNINGS Non-suitable food containers ever use recipients made of: normal finegrained steel, glass, pottery, copper and aluminium. Do not place empty containers on the cooking zone, as they may cause damage. o not place hot recipients on the control panel, in the area of the pilot lights or on the edge of the cooking top, as they may cause damage.
  • Page 43 ANWEISUNGEN WARNINGS ny interventions or repairs on the unit during the warranty period must be carried out solely by the manufacturer’s authorised service centre; conversely, the warranty will be is invalidated and terminated immediately. The manufacturer will not recognise any warranties under any circumstances for any problems subsequently encountered.

  • Page 44: Noise Emissions

    ANWEISUNGEN WARNINGS Noise emissions nduction can generate slight noise emissions, which can vary depending on the material, type of pot and power setting selected. When the cooktop is used frequently, the cooling fan turns itself on to protect the electronics, generating a buzzing sound: this is perfectly normal.

  • Page 45: Your Induction Hob

    FUNZIONAMENTO OPERATION YOUR INDUCTION HOB Description Cooking zone front left 210 x 190 mm / 2,1 kW (boost 3,0 kW) Cooking zone rear left 210 x 190 mm / 2,1 kW (boost 3,0 kW) Extractor Cooking zone rear right 210 x 190 mm / 2,1 kW (boost 3,0 kW) Cooking zone front right 210 x 190 mm / 2,1 kW (boost 3,0 kW) Connected cooking zones 21 x 39 cm / 3.7 kW Control panel...
  • Page 46 FUNZIONAMENTO OPERATION YOUR INDUCTION HOB Description Pause key Lock key Keep warm key Minute minder key Timer display Plus key timer Minus key timer Cooking zone key rear left (cooking zone display) and timer symbol Extraction key (extractor unit display) and timer symbol 10.

  • Page 47: Indications In The Display

    FUNZIONAMENTO OPERATION Indications in the display Cooking zone display Description Power level; 1 = low level / 9 = high level. Boost level active. No (suitable) pan on cooking zone (pan detection symbol). Residual heat indicator; The hob has a residual heat indicator for each cooking zone to show those which are still hot.

  • Page 48: Temperature Safety

    FUNZIONAMENTO OPERATION YOUR INDUCTION HOB Before use, read the separate safety instructions. Temperature safety A sensor continuously measures the temperature of certain parts of the hob. Every cooking zone is equipped with a sensor that measures the temperature of the bottom of the pan to avoid any risk of overheating when a pan boils dry.
  • Page 49 FUNZIONAMENTO OPERATION Use of the touch keys and slide control Place the tip of your finger flat on a key or the slide control to achieve the best results. You do not have to apply any pressure. The touch keys only react to the light pressure of a fingertip. Do not operate the controls with any other objects.

  • Page 50: Before First Use

    FUNZIONAMENTO OPERATION BEFORE FIRST USE Attention Make sure the bottom of the pan and the surface of the cooking zone are clean and dry. We recommend that you lift pans and not slide them over the hob. Pan detection • If the hob does not detect a (suitable)) pan after a pan is put on a cooking zone, the pan detection symbol flashes in the display.

  • Page 51: Cooking Guidelines

    FUNZIONAMENTO OPERATION BEFORE FIRST USE Cooking guidelines Because the levels depend on the quantity and composition of the contents of the pan, the table below is intended as a guideline only. Use level ‘boost’ to: • bring the food or liquid to the boil quickly; •...
  • Page 52 FUNZIONAMENTO OPERATION BEFORE FIRST USE Use of the downdraft Place the lid at an angle on the pan with the opening to the extraction side. This ensures maximum  extraction.

  • Page 53: Start Cooking

    FUNZIONAMENTO OPERATION OPERATION OF THE HOB Please read the chapter ‘Before first use’ very carefully before you start cooking. This prevents incorrect use of the hob. Start cooking Touch and hold the on/off key until you hear an audio signal. All displays light up;...
  • Page 54 FUNZIONAMENTO OPERATION OPERATION OF THE HOB Within 10 seconds, set the power level by touching the slide control. The cooking zone starts at the level that has been set.  Boost You can use the boost function to cook for max. 5 minutes at the highest cooking level. You can use the Boost function for a maximum of two cooking zones alongside each other at the same time.

  • Page 55: Finish Cooking

    FUNZIONAMENTO OPERATION OPERATION OF THE HOB Finish cooking Set the power level to ‘0’ to switch off the cooking zone. Switch off the induction hob by touching the On/off key. Symbol H will appear in the display of the cooking zone which is too hot to touch. The symbol disappears when the surface has cooled down to a safe temperature.
  • Page 56 FUNZIONAMENTO OPERATION OPERATION OF THE HOB Switch on the keep warm function Switch on the hob and put a suitable pan on a cooking zone. Touch the cooking zone key of the desired cooking zone. The ‘0’ of the selected cooking zone will light up clearly and a single beep sounds. ...

  • Page 57: Pause Cooking

    FUNZIONAMENTO OPERATION OPERATION OF THE HOB Disconnection of Bridge induction cooking zones Simultaneously touch the cooking zone keys of the connected cooking zones. The connection symbol will disappear on the rear cooking zone display.  Pause cooking This function stops the cooking activity temporarily (max. 10 minutes); the extraction will go to the lowest setting and timers are paused.

  • Page 58: Using The Minute Minder

    FUNZIONAMENTO OPERATION OPERATION OF THE HOB Using the minute minder The minute minder is not connected to a cooking zone. The minute minder does not switch off a cooking zone or the extractor unit. The hob is switched on. Touch the minute minder key to switch on the minute minder. The timer display shows ‘0.00’...

  • Page 59: Using The Cooking Timer

    FUNZIONAMENTO OPERATION OPERATION OF THE HOB Using the cooking timer The cooking timer is connected to a cooking zone. After the set time has elapsed, the cooking zone will switch off automatically. The hob is switched on and for at least one cooking zone a power level has been set. Touch the desired cooking zone key.

  • Page 60: Child Safety Lock

    FUNZIONAMENTO OPERATION OPERATION OF THE HOB Checking the remaining cooking time Touch the cooking zone key to select the zone of which you want to see the remaining time. A zone connected to the cooking timer is identified by a flashing timer symbol above the cooking ...
  • Page 61 FUNZIONAMENTO OPERATION OPERATION OF THE HOB The hob is now locked. It prevents unintended switching on. After 20 seconds, the hob will switch off automatically. To deactivate the child safety lock, the steps described must be completed within 10 seconds. Switch on the hob.
  • Page 62 FUNZIONAMENTO OPERATION OPERATION OF THE EXTRACTOR UNIT Manually switching on and off the extractor unit Touch the extraction key. The display of the extractor unit lights up.  Set the extractor speed level within 3 seconds by touching the slide control (1 to 9). The extractor unit switches on with the extraction speed that is set.
  • Page 63 FUNZIONAMENTO OPERATION OPERATION OF THE EXTRACTOR UNIT Switching on and off the automatic extraction mode In automatic extraction mode the extraction level adjusts automatically to the use of the cooking zones. A cooking zone is operating (level 8) and the automatic extraction mode is active (level 5). Touch the extraction key for three seconds.
  • Page 64 FUNZIONAMENTO OPERATION OPERATION OF THE EXTRACTOR UNIT Use the ‘+’ or ‘-’ key to set the desired delay time. Countdown starts automatically.  The extractor unit switches off after the time that has been set.  Saturation of the grease filter After 30 operating hours, ’F’...
  • Page 65 FUNZIONAMENTO OPERATION USER MENU The user menu enables the user to set a.o. the signals on the hob as desired. This concerns both audio (tone and volume) and visual signals. Menu code Discription Configuration value Total power available for the From 1400W to 7400W (default) in 100W steps appliance Ducted mode / Recirculation...
  • Page 66 FUNZIONAMENTO OPERATION USER MENU Release the pause key. “U” is flashing alternately with number “0” on the cooking zone display on the rear left.  With menu code U0, the configuration value appears in the timer display.  For all other menu codes, the configuration value appears in the cooking zone display on the front left. ...
  • Page 67 FUNZIONAMENTO OPERATION USER MENU Touch the cooking zone key on the front left and select the correct value (see table). Confirm the setting; touch and hold the on/off key until you hear an audio signal.

  • Page 68: Power Limiter

    FUNZIONAMENTO OPERATION POWER LIMITER Setting the power limiter should only be carried out by a registered and qualified installer. Please read the safety regulations and the installation instructions carefully. DANGER The hob is equipped with a power limiter. If the total power of operating cooking zones exceeds the maximum available amount of power, the power is automatically reduced.
  • Page 69 FUNZIONAMENTO OPERATION POWER LIMITER Release the minute minder key. “C” is flashing alternately with “0” on the cooking zone display on the rear left.  The configuration value appears in the cooking zone display on the front left.  Touch the cooking zone key on the rear left and choose “8” by using the slide control. “C”...

  • Page 70: Maintenance

    FUNZIONAMENTO OPERATION MAINTENANCE Cleaning First use • Use a damp cloth to clean and dry the glass surface before using it for the first time. • It is recommended to dry the appliance after having cleaned it with a damp cloth, in order to prevent the build-up of limescale.
  • Page 71 FUNZIONAMENTO OPERATION MAINTENANCE Recyrculation filters - (only for filter version) Filters can be restored in the oven, better if fan-assisted. Temperature of the oven should be 150°-180°, higher temperatures could damage the filters. It is better to place the filter bricks on the oven’s grid, non pre-heated, and let them cool down completely before removing.

  • Page 72: Troubleshooting

    FUNZIONAMENTO OPERATION TROUBLESHOOTING Attention If you see a crack in the glass top (however small), switch off the hob immediately and disconnect it from the power mains. Contact the service department. If the appliance does not work properly, this does not always mean that it is defective. Try to deal with the problem yourself first by checking the table below.
  • Page 73 FUNZIONAMENTO OPERATION TROUBLESHOOTING Symptom Possible cause Solution Error code ER21. Overheating. Let the hob cool down. Error code E2. Excess temperature of the Do not heat empty cookware. induction element. Empty cookware might have been used. Error code E3. Wrong pan. Use appropriate pans.
  • Page 75 AFLIASPCB4OB04 Ed.28-09-22...
