Page 1: Table Of Contents
Installation and Owner’s Manual (For Aftermarket Applications) Victory Step ™ Installation and Owner’s Manual (For Aftermarket Applications) Victory Step Kits Victory Step Kits Kit Part # Kit Part # Description Description 2023024500 Triple Step with handrail. Includes all attaching hardware.
Page 2: Introduction
Installation and Owner’s Manual (For Aftermarket Applications) Introduction The Victory Step is an entry step assembly that can be mounted to the side of any patio opening to provide ease of entry. The suggested deck height range should be THE “WARNING” SYMBOL ABOVE IS A SIGN THAT A between 23”-35”...
Page 3: Parts List
NOTE: Part numbers are shown for identification purposes only. Not all parts are available for individual sale. All parts with a link to the Lippert Store can be purchased. However, the steps listed below do not include attaching hardware. Letter...
Page 4: Resources Required
(For Aftermarket Applications) Resources Required To install the footman loop and angle brackets: 1. Place the Victory Step in the desired location in • Cordless or electric drill or • Tape measure patio opening, making sure there is enough space to screw gun •...
Page 5: Step Deployment
Installation and Owner’s Manual (For Aftermarket Applications) Step Deployment 1. Align the step latches at the top of the Victory Step with the installed footman loops (Fig.5), then lower step until both step latches click into place around the footman loops.
Page 6: Step Adjustment
Victory Step ™ Installation and Owner’s Manual (For Aftermarket Applications) Step Adjustment 1. To adjust the foot height, lift the step and remove the fastening pin that secures the foot tube to the step tube. 2. Align the tube (Fig. 7A) to the desired holes then reinsert the fastening pin (Fig.
Page 7: Handrail (If Equipped): Removal From Storage, Installation
1. To install the handrail, align the short end of the handrail tube with the top bracket (Fig. 9A) on the left side of the Victory Step and the long end of the handrail tube (Fig. 9B) with the bottom bracket (Fig. 9C).
Page 8: Handrail (If Equipped): Removal From Installed Position, Storage
Step Removal 1. Remove the quick-release lockpins (Fig.10A) from both of the adjustment plates (Fig.10B). Retain the pins for later use. 2. Collapse the Victory Step by pulling up on the back of the top step. 5/16 3. Insert the ”...
Page 9: Garage Storage Kit (If Purchased Separately)
Suspending the Victory Step above the floor could lead to wall damage. The garage storage brackets are designed to hold the Victory Step in a fixed position for travel where the feet of the step are resting on the floor and leaning slightly against the garage storage brackets, which are attached to the wall.
Page 10 2. Retract both feet of the Victory Step to the shortest position (Fig.13A), 3. Position the Victory Step with the feet on the floor and the edge of the feet about 3 to 4 inches away from the wall (Fig.14).
Page 11: Removal
Victory Step ™ Installation and Owner’s Manual (For Aftermarket Applications) Removal To remove the Victory Step from storage, push the step latch levers up (Fig.15A) and pull the step away from the clevis pins. Fig.15 lippert.com 432-LIPPERT (432-547-7378) CCD-0007757 Rev: 08.05.24...
Page 12 Installation and Owner’s Manual (For Aftermarket Applications) Notes Manual information may be distributed as a complete document only, unless Lippert provides explicit consent to distribute individual parts. All manual information is subject to change without notice. Revised editions will be available for free download at lippert.com.
