- Page 1 Victory Step™ OEM INSTALLATION MANUAL...
-
Page 2: Table Of Contents
Introduction The Victory Step is an entry step assembly that can be mounted to the side of any patio opening to provide ease of entry . The suggested deck height range should be between 23"-35" for a 3-step tread and 30"-45"... -
Page 3: Safety
Lippert limited warranty. The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause death or serious personal injury if not performed safely and within the parameters set forth in this manual. -
Page 4: Installation
There is an angle bracket (Fig. 1A) under each footman loop (Fig. 1B) to keep the Victory Step from shifting when latched. The angle brackets are offset, leaving more space on the right side of each footman loop (Fig. 2) to accommodate the latching mechanisms. -
Page 5: Step Deployment
Step Deployment Align the step latches at the top of the Victory Step with the installed footman loops (Fig. 5), then lower until both step latches click into place around the footman loops. Lower the Victory Step to the ground. -
Page 6: Handrail Installation
To install the handrail (if equipped), align the short end of the handrail tube with the top bracket (Fig. 8A) on the left side of the Victory Step and the long end of the handrail tube (Fig. 8B) with the bottom bracket (Fig. 8C). -
Page 7: Adjustment
Remove the handrail (if installed) by removing the top and bottom fastening knobs (Fig. 8D), then sliding the handrail tube out of the brackets. Secure the handrail (if equipped) to the front of the Victory Step by aligning the holes in the handrail with the holes in the Victory Step then secure with the fastening knobs. -
Page 8: Storage (If Installed)
Before installing the brackets, adjust the feet of the Victory step to their shortest position (Fig. 12A). This will help ensure that, after the garage storage brackets are properly attached to the wall, there will never be any situation where the garage storage brackets cause the step to be suspended above the floor. -
Page 9: Storage
Step latches to the clevis pins (Fig. 11A) on the garage storage brackets. Make sure both step latches click into place around the clevis pins (Fig. 14). Removal To remove the Victory Step, push the step latches levers up (Fig. 15A) and pull the step away from the clevis pins. Fig. 14 Fig. 15 Page 9 Rev: 10.25.23... - Page 10 Lippert representative has been provided. Any unauthorized use shall void any applicable warranty. The information contained in this manual is subject to change without notice and at the sole discretion of Lippert. Revised editions are available for free download from lippert.com.
