- Page 1 HDMI repeater with Audio Decoder 1 input : 1 output ID# 698 Operation Manual...
- Page 2 Introduction HDMI repeater with Audio Decoder used to extend a HDMI signal for transmission over long distances. The audio decoder function allows you to take a HDMI input and output the audio via Optical (Toslink) or LPCM 7.1/5.1/2 channel through the multi-channel output ports. The unit also supports compressed digital bitstream (Dolby TrueHD, Dolby Digital Plus, and DTS-HD Master Audio) through the input and output ports.
- Page 3 2. Multi channel output: Connect the audio channel output to the input of your amplifier equipment and follow the amplifier connections. FL: Front Left FR: Front Right LFE: Low Frequency Effect FC: Front Center RL: Rear Left RR: Rear Right RLC: Rear Left Center RRC: Rear Right Center 3.
- Page 4 Specifications Input port 1 x HDMI HDMI input audio format LPCM 7.1, 5.1 or 2 channels and Bitstream (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) Output port 1 x HDMI HDMI output audio format LPCM 7.1, 5.1 or 2 channels and Bitstream (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) Multi channel output ports 4 x 3.5mm phone jack...
