- Page 1 CAT6 to CAT6 Repeater ID# 787 Operation Manual...
- Page 2 Introduction This is the most advanced solution for CAT6 to CAT6 signal repeater. These two CAT6 connectors are for Video and DDC ports of transmitter and receiver which isolates the DDC capacitances of the two sides of the buffer. This is compatible with HDMI v1.3 specifications, a cutting-edge technology which defines the supports to transfer Deep Color (12 bits/color) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio.
- Page 3 Rear Panel 1. Video output: Connect the video output to the video input of the receiver unit using CAT-6 cable. 2. DDC output: Connect the DDC output to the DDC input of the receiver unit using CAT-6 cable. Installation and Connection Specifications Input Ports...
