- Page 1 HDMI 4Kx2K 1x1 Repeater # 15220 Operation Manual...
- Page 2 Introduction The HDMI4K×2K Repeater is an advanced solution for extending an HDMI signal. It amplifies and equalizes the HDMI signal to provide high quality audio and video allowing you to extend the HDMI cable distance a further 15 meters at 1080p@60Hz/8-bit resolution. Features Compliant with HDMI, HDCP 1.2 and DVI 1.0 •...
- Page 3 Operation Controls and Functions Top Panel HDCP LED: This LED will illuminate when an HDCP encoded HDMI signal has been detected. Link LED: This LED will illuminate when an active HDMI signal is being received. Power LED: This LED will illuminate when the unit is connected to an active power supply.
- Page 4 Left Panel HDMI Out: Connect a TV/display with an HDMI cable for output of the combined audio/video HDMI signal. Note: For playback of 4K×2K/3D HDMI source signals, a 4K×2K/3D capable display and High Speed HDMI cables are required Rear Panel DC 5V: Connect the 5V DC power supply to the unit and plug the adaptor into an AC wall outlet.
- Page 5 Connection Diagram...
- Page 6 Specifications Video Bandwidth 300Mbps/10.2Gbps Input Ports 1×HDMI, 1×Mini-USB (Manufacturer use only) Output Port 1×HDMI Audio Sampling Rates HDMI: Up to 192kHz HDMI Audio Formats LPCM 2/5.1/7.1CH, Dolby Digital 2~5.1CH, DTS 2~5.1CH, Dolby Digital Plus, Dolby TrueHD & DTS-HD Master Audio HDMI Cable I/O Distance 10m@1080p/12-bit, 15m@1080p@8-bit, 10m@4K×2K Power Supply...
