Summary of Contents for OpenEye OE-CC51D8
- Page 1 Hardware Manual - Features and Contents Important Safeguards View Important Safeguards before installing the camera. Warranty View the Product Warranty for the camera. secure and scale smart environments. Camera Dimensions Copyright © OpenEye 2023...
- Page 2 Connections Name 12vDC 12vDC (Ground) DI1+ DI1- DI2+ DI2- LINE OUT- LINE OUT+ LINE IN- Copyright © OpenEye 2023...
- Page 3 PoE+ using the PoE power injector provided with the camera, or if a Power Sourcing Equipment (PSE) switch is available. NOTE: OpenEye recommends against using more than one power source at a time. Installation To prepare the camera for wall of ceiling installation with accessories, see instructions on the Quick Installation Guide.
- Page 4 • NDAA Compliant Box Contents OpenEye CC51D8 cameras come with a mounting template, screws, screw anchor mounts, torx tool, and waterproofing kit. Identify the following components to make sure everything has been properly included with your new recorder. If any of the following items are missing, contact the dealer to arrange a replacement.
- Page 5 Screw Anchor Mounts Screws Torx Tool Conduit Adapter Related Links OE-CC51D8 Cloud Camera Dome Quick Installation Guide Copyright © OpenEye 2023...
