  • Page 1 CT3x Series Universal Dock and Standard Accessories User Guide...
  • Page 2 Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. HII makes no representation or warranties regarding the information provided in this publication.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Customer Support ..........................v Technical Assistance .......................v Product Service and Repair ....................v Limited Warranty ........................v Chapter 1 - Introduction .................. 1 List of Universal Dock and Booted Accessories..............2 Agency Models.......................... 3 Chapter 2 - Protective Boot................5 Out of the Box ..........................
  • Page 4 Connect Power..........................16 Charge the Battery Pack ......................16 Chapter 5 - Universal Dock 5-Bay Charge Base........17 Features............................18 Out of the Box..........................19 Insert the Battery Charger......................20 Connect Power..........................21 Charge the Battery Pack ......................21 Status LED............................21 Chapter 6 - Universal Dock Display Dock..........23 Features............................23 Out of the Box..........................24 Dock Connectors..........................24...
  • Page 5 Chapter 7 - Quad Battery Charger...............29 Features ............................29 Out of the Box ..........................30 Connect Power ..........................30 Charge the Battery........................31 Status LED ............................31 Chapter 8 - Universal Dock Cups ..............33 Out of the Box ..........................33 Replacing a Universal Cup .......................34 Chapter 9 - Scan Handle ................37 Features ............................37 Out of the Box ..........................38 Attach Scan Handle........................38...
  • Page 6 CT3x Series Universal and Standard Accessories User Guide...

  • Page 7: Customer Support

    Customer Support Technical Assistance Go to sps.honeywell.com, and then select Support > Productivity to find a host of options to help you quickly find the support you need and/or who to contact. Product Service and Repair Honeywell International Inc. provides service for all of its products through service centers throughout the world.
  • Page 8 CT3x Series Universal and Standard Accessories User Guide...

  • Page 9: Chapter 1 - Introduction

    CHAPTER INTRODUCTION Honeywell offers a full range of universal and boot-compatible accessories for the CT30 XP and CT37 mobile computers, including: • Protective Boots (page • Home Bases and Ethernet Bases for one device and one battery (page • Charge and Ethernet Bases for up to four devices (page •...

  • Page 10: List Of Universal Dock And Booted Accessories

    List of Universal Dock and Booted Accessories Note: For information on CT30 XP or CT37 RFID Bracket options for your Honeywell RFID reader, refer to the RFID reader user guide. Product documentation is available for download at sps.honeywell.com. Accessory Part Number...

  • Page 11: Agency Models

    (CT37-BTEC) CT37 battery. For a complete list of accessories for your mobile computer and their part numbers see the Accessory Guide for your device, available for download at sps.honeywell.com. Contact your local sales representative for ordering information. Agency Models CT30P-QBC, CT37-QBC. CT40-CB, CT40-DB, CT40-EB, CT40-HB, CT40-NB,...
  • Page 12 CT3x Series Universal and Standard Accessories User Guide...

  • Page 13: Chapter 2 - Protective Boot

    PROTECTIVE BOOT Honeywell offers the following protective boots: CT30P-PB-XP and CT37-PB-x (x = kit variation). Honeywell also offers a series of boot-compatible communication and charge accessories that do not require you to remove the protective boot from the device before use.

  • Page 14: Remove Protective Boot

    2. Press down evenly. 3. Verify that the mobile computer fits securely in the protective boot. Remove Protective Boot Note: The protective boot does not need to be removed for battery replacement or charging with a compatible base (see page 2). Routinely inspect the protective boot for damage, and replace if needed.
  • Page 15 3. Lift the unit up and out of the bottom of the boot. CT3x Series Universal and Standard Accessories User Guide...
  • Page 16 CT3x Series Universal and Standard Accessories User Guide...

  • Page 17: Chapter 3 - Universal Dock Home Base And Ethernet Home Base

    CHAPTER UNIVERSAL DOCK HOME BASE AND ETHERNET HOME BASE A Home Base is a charge/communication base for one mobile computer and one spare battery. The Home Base has one USB client connector. An Ethernet Home Base is also a charge/communication base for one mobile computer and one spare battery.

  • Page 18: Features

    Features Battery LED Removable Device Cup Release Latch Removable Battery Ethernet port Ethernet Home Power Base only USB Port Out of the Box Make sure that your shipping box contains these items: • Home Base (CT30P-HB-UVN, CT30P-HB-UVB, CT37-HB-UVB, or CT37-HB-UVN) CT3x Series Universal and Standard Accessories User Guide...

  • Page 19: Connect Power

    Connect Power Use only a UL Listed power supply that has been qualified by Honeywell with an output rated at 12V/3A. The power supply input rating is 90-264 VAC, 50/60 Hz.
  • Page 20 You can also insert a battery pack into the Home Base for charging. CT3x Series Universal and Standard Accessories User Guide...

  • Page 21: Remove The Battery Pack

    Remove the Battery Pack Status LED Status Description Battery Solid Green The battery is connected to external power and is fully charged. Solid Amber The battery is connected to external power and is charging. Flashing Red There is a battery charging fault, such as over-temperature. CT3x Series Universal and Standard Accessories User Guide...
  • Page 22 CT3x Series Universal and Standard Accessories User Guide...

  • Page 23: Chapter 4 - Charge Base And Ethernet Base

    CHAPTER CHARGE BASE AND ETHERNET BASE Universal Dock Charge Bases CT30P-CB-UVN, CT37-CB-UVN, and CT30P-CB- UVB charge up to four mobile computers. Model CT30P-CB-UVB is boot compatible. Ethernet (Net) Bases CT30P-NB-UVN, CT37-NB-UVN, and CT30P-NB-UVB hold four mobile computers and function as both charge and communication bases, with two RJ45 Ethernet ports.

  • Page 24: Out Of The Box

    Connect Power Use only a UL Listed power supply that has been qualified by Honeywell with an output rated at 12V/7A. The power supply input rating is 100-240 VAC, 50/60 Hz.

  • Page 25: Chapter 5 - Universal Dock 5-Bay Charge Base

    BASE The Universal Dock 5-Bay Charge Base provides the flexibility of charging five units, or four units and four batteries with the battery charger. Honeywell offers the following 5-bay chargers for the CT30 XP and CT37 mobile computers: • CT30-5CB-UVN-BAT and CT37-5CB-UVN-BAT with one battery charger and four universal cups for use without a protective boot •...

  • Page 26: Features

    Features 5 Bay Charge Base with One Battery Charger and Four Universal Cups Battery LEDs Battery Charger Battery Charger Release Latch 5 Bay Charge Base with Five Universal Cups Removable Cup CT3x Series Universal and Standard Accessories User Guide...

  • Page 27: Out Of The Box

    5 Bay Charge Base (Rear View) Cup Release Power Latch Connector Out of the Box Make sure that your shipping box contains these items: • 5-Bay Charge Base (CT30-5CB-UVN-BAT, CT37-5CB-UVN-BAT, CT30-5CB-UVB-BAT, CT37-5CB-UVB-BAT, CT30P-5CB-UVN, CT37-5CB-UVN, or CT30P-5CB-UVB ) • Power supply •...

  • Page 28: Insert The Battery Charger

    Insert the Battery Charger Note: The Battery Charger must be installed in the location shown below. 1. Insert the battery charger tilted slightly to the left of the base. 2. Press the latch release button as you push the battery charger down until it snaps in.

  • Page 29: Connect Power

    Connect Power Use only a UL Listed power supply that has been qualified by Honeywell with an output rated at 12V/8.3A. The power supply input rating is 100-240 VAC, 50/60 Hz. The operating temperature is 0 °C to 45 °C (32 °F to 113 °F).
  • Page 30 CT3x Series Universal and Standard Accessories User Guide...

  • Page 31: Chapter 6 - Universal Dock Display Dock

    CHAPTER UNIVERSAL DOCK DISPLAY DOCK A display dock allows a mobile computer to become a personal computer. A monitor, keyboard, mouse, and audio can be connected through the dock via the USB ports. The dock also provides an Ethernet connection. •...

  • Page 32: Out Of The Box

    Dock Connectors Connect Power Use only a UL Listed power supply that has been qualified by Honeywell with an output rated at 12 VDC and 3 A. The power supply input rating is 100-240 VAC, 50/ 60 Hz. The operating temperature is -10°C to 50°C (14°F to 122°F). The maximum output of the base is 5VDC/2A.

  • Page 33: Connect To A Usb Device

    The dock is not connected or lost connection through HDMI. Check Software on Computer Computers powered by Android 8 or higher have the DisplayLink software installed by Honeywell. Insert Computer into the Dock Ensure the computer is fully seated into the dock.

  • Page 34: Configure The Display Dock Settings

    The Display Dock Settings app is available from the all apps menu under Settings. 1. Swipe up from the bottom of the Home screen to access all apps. 2. Tap Settings > Honeywell Settings > Display Dock. Set Monitor Settings 1.

  • Page 35: Set Peripheral Settings

    Set Peripheral Settings 1. Swipe up from the bottom of the Home screen to access all apps. 2. Tap Settings > Honeywell Settings > Display Dock. 3. To set the right mouse button to the back key, tap Right mouse button to toggle the feature on or off.

  • Page 36: Usb Devices

    Non-Supported Devices • HDMI splitter for two monitors • Display Port USB Devices Supported Devices • Standard three button mouse with scroll • Standard QWERTY keyboard without HUB/USB type A ports on the keyboard • USB headset/USB to 3.5mm audio converter •...

  • Page 37: Chapter 7 - Quad Battery Charger

    CHAPTER QUAD BATTERY CHARGER The CT30P-QBC and CT37-QBC Quad Battery Chargers allow for charging up to four batteries. The CT30P-QBC uses the CT30P-QBC-UCP Battery Universal Dock Cup, and the CT37-QBC uses the CT37-QBC-UCP Battery Universal Dock Cup. Both dock cups can be replaced and are also compatible with the Universal Dock 5-Bay Charge Base.

  • Page 38: Out Of The Box

    Connect Power Use only a UL Listed power supply that has been qualified by Honeywell with an output rated at 12V/3A for the CT30P-QBC or 12V/7A for the CT37-QBC. The power supply input rating is 100-240 VAC, 50/60 Hz.

  • Page 39: Charge The Battery

    Charge the Battery Insert one to four battery packs into the charger. Status LED Status Description Battery Solid Green The battery is connected to external power and is fully charged. Solid Amber The battery is connected to external power and is charging. Flashing Red There is a battery charging fault, such as over-temperature.
  • Page 40 CT3x Series Universal and Standard Accessories User Guide...

  • Page 41: Chapter 8 - Universal Dock Cups

    CHAPTER UNIVERSAL DOCK CUPS Universal Bases have removable cups that can be replaced with Universal Cups. The 5-Bay Charge Bases can include a removable battery charger that can also be replaced. • CT30P-UCP-N and CT37-UCP-N are for use with computers without a boot attached •...

  • Page 42: Replacing A Universal Cup

    Replacing a Universal Cup Note: The Universal Charge base is shown in the instructions below for illustration purposes. The steps for removing and inserting a cup are the same for all universal bases. 1. Push the latch towards the front of the base. 2.
  • Page 43 4. Insert the new cup tilted slightly towards the front of the base. 5. Push the cup into the base until it snaps in. Inserting a Battery Charger For information about inserting a battery charger in a 5-Bay Charge Base, see Insert the Battery Charger on page 20.
  • Page 44 CT3x Series Universal and Standard Accessories User Guide...

  • Page 45: Chapter 9 - Scan Handle

    CHAPTER SCAN HANDLE A scan handle attaches to the mobile computer to provide a handle grip and pull-trigger for barcode scanning. Honeywell offers the following scan handles: • CT30P-SH-00 and CT37-SH-UVN for use without a boot attached • CT30P-SH-UVB and CT37-SH-UVB for use with a boot attached...

  • Page 46: Out Of The Box

    Out of the Box Make sure that your shipping box contains the following: • Scan Handle (CT30P-SH-00, CT30P-SH-UVB, CT37-SH-UVN, or CT37-SH-UVB) • Lanyard If any items are missing or appear damaged, contact your Customer Account Representative. Keep the original packaging in the event that you need to return the scan handle for service or if you want to store the scan handle while not in use.

  • Page 47: Scan A Bar Code

    Scan a Bar Code Press the trigger on the handle to scan a bar code. Remove Scan Handle Note: In the following images, the CT30 XP is shown for demonstration. 1. Slide the latch lock to the left. 2. Press the release latch button on both sides. CT3x Series Universal and Standard Accessories User Guide...
  • Page 48 3. Lift unit out. CT3x Series Universal and Standard Accessories User Guide...

  • Page 49: Chapter 10 - Wearable Kit

    CHAPTER WEARABLE KIT The CT30P-WS-KIT and CT37-WS-KIT Wearable Kits allow the user to mount a mobile computer without a protective boot on either arm. It consists of an arm mount sled and an armband. The sled includes a replaceable rubber pad that helps keep the wearable kit in place.

  • Page 50: Out Of The Box

    Orientation for Wearing on Left Arm Label Rubber pad Sled Armband attachments Strap adjustment Armband loops Out of the Box Make sure that your shipping box contains the following: • Wearable Kit (CT30P-WS-KIT or CT37-WS-KIT) including sled, rubber pad, and armband If any items are missing or appear damaged, contact your Customer Account Representative.

  • Page 51: Assemble Wearable Kit

    Part Part Number Sled For CT30 XP: CT3OP-WS-KIT-03 For CT37: CT37-WS-KIT-03 Rubber pad For CT30 XP: CT3OP-WS-KIT-02 For CT37: CT37-WS-KIT-02 Armband For CT30 XP: CT3OP-WS-KIT-01 For CT37: CT37-WS-KIT-01 Note: When you order a Wearable Kit, the label on the sled will have the part number for the kit (CT30P-WS-KIT or CT37-WS-KIT).
  • Page 52 3. Pull the end of the strap through the adjustment loop. You can adjust the length of the strap by using the top or bottom loop. 4. Tighten the strap around the arm so that the sled is held firmly in place in a comfortable position.

  • Page 53: Scanning Barcodes

    User Guide. For details on using a Bluetooth scanner, see the User Guide for the selected device. Product documentation can be downloaded from sps.honeywell.com. Remove Wearable Kit 1. To remove the Wearable Kit, loosen the strap. It is not necessary to remove the strap from the adjustment loop.

  • Page 54: Replace Rubber Pad

    Replace Rubber Pad The rubber pad on the Wearable Kit can be replaced if necessary due to wear or damage. Note: The rubber pad should always be used with the Wearable Kit to ensure that the kit stays in place on your arm. 1.

  • Page 55: Cleaning

    Sled Rubber pad 3. Insert the sled’s front feet into the front slots on the pad. 4. Fold the middle flaps over the sled. Cleaning All parts of the Wearable Kit can be cleaned between uses with a non-abrasive, damp cloth and a mild dish soap solution. Allow all parts to air dry completely before use.
  • Page 56 CT3x Series Universal and Standard Accessories User Guide...

  • Page 57: Chapter 11 - Mount A Charging Dock

    CHAPTER MOUNT A CHARGING DOCK Mounting a Charging Dock You can mount charge docks and the Quad Bay Battery Charger on a flat, horizontal surface such as a desktop or workbench with an optional DIN rail. Mounting hardware required: • DIN rail •...
  • Page 58 2. Secure the DIN rail to the flat surface with the hardware. Note: Charging cup appearance may differ depending on model. CT3x Series Universal and Standard Accessories User Guide...
  • Page 60 Honeywell 855 S. Mint Street Charlotte, NC 28202 sps.honeywell.com ™ CT30-UV-EN-UG-01 Rev E 08/24...
