P r o d u c t s
Victorian
Product Number
85O/8OO/...
Product Number
Faucet with Spray
85O/86O/...
JADO USA
6615 West Boston
Chandler, AZ 85226
Phone: (8OO) 227 -2734
Fax: (8OO) 552-JADO (5236)
www.jadousa.com
© J A D O U S A 2 0 0 5
Single Lever Kitchen Faucet
Single Lever Kitchen Faucet
Installation Instructions
To ensure that your installation proceeds smoothly--please
read these instructions carefully before you begin.
L u x u r y
F a u c e t s
a n d
A c c e s s o r i e s
H 9 6 5 5 3 6 C
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for JADO Victorian 800
Summary of Contents for JADO Victorian 800
- Page 1 Faucet with Spray 85O/86O/... JADO USA 6615 West Boston Chandler, AZ 85226 Phone: (8OO) 227 -2734 Fax: (8OO) 552-JADO (5236) www.jadousa.com © J A D O U S A 2 0 0 5 H 9 6 5 5 3 6 C...
- Page 2 RECOMMENDED TOOLS Phillips Screwdriver Adjustable Wrench Plumbers' Putty or Caulking Regular Screwdriver Channel Locks Tubing Cutter ROUGHING-IN DIMENSIONS NOTE: Bore hole size is 1-3/8" 1-3/4" 8-7/8" (225mm) (44mm) 5-7/8" (149mm) 12" 2" (51) 8-5/8" (219mm) 2-3/4" 5-1/4" (70mm) 2-1/4" D. (133mm) (57mm) 1-3/4"...
- Page 3 INSTALL SPRAY HOLDER (Model 850/860/...) Apply a bead of putty to the underside lip of SPRAY HOLDER (1). Place the SPRAY HOLDER (1) into the appropriate mounting hole. Assemble the RUBBER WASHER (2) (2), BRASS WASHER (3) and LOCK NUT (4) onto the shank of SPRAY HOLDER (1). From below tighten LOCK NUT (4) to secure SPRAY HOLDER (1).
- Page 4 JADO will not be liable for labor or other costs relating to the sale, installation, or replacement of their products. In the event of a defect in any JADO product covered by this warranty, the product must be returned to the dealer where originally purchased JADO BATHROOM AND HARDWARE MFG.
