  • Page 1 User manual IP Strobe M This product manual contains important information about the safe installation and use of the light. Please read and follow these instructions carefully and keep this manual in a safe place for future reference.

  • Page 2: Table Of Contents

    Content Safety instructions Installation Signal and power connection Function setting DMX address setting OPERATION DISPLAY DMX Channel Maintenance Trouble shooting Technical Data Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good condition before installation and use.

  • Page 3: Safety Instructions

    Safety instructions When unpacking and before disposing of the carton check there is no transportation damage before using the light. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector is for indoor and outdoor use, IP65. D not install the fixtures onto inflammable surfaces directly The fixture is only intended for installation, operation and maintenance by qualified personnel.
  • Page 4 Always disconnection from Power before the device’s installation, cleaning and maintenance！ INSTALLATIONS Product Overview...
  • Page 5 Product Dimensions Safety Information WARNING! Read the safety precautions in this section before unpacking, installing, powering or operating this product. This luminaries are multi-environmental fixtures with an IP-rating of 65, intended for professional use only. They are not suitable for household use. Review the following safety precautions carefully before installing or operating the fixture.
  • Page 6 WARNING! Risk of electric shock. Always power off/unplug the fixture before removing any covers. Ensure that the power is turned off when connecting the fixture to the AC mains supply. Ensure that the fixture is electrically connected to earth (ground). Do not apply power if the fixture is in any way damaged.
  • Page 7 WARNING! Take measure to prevent personal injury. Do not look directly at the light source from close range. Take precautions to prevent injury due to falls when working at height. For permanent installation, ensure that the fixture is securely fastened toa load-bearing surface with suitable corrosion-resistant hardware.

  • Page 8: Installation

    Installation The fixture may be installed in any orientation, but if installed horizontally with a downward beam-angle, water can potentially pool in the fan wells. Under normal operation the moisture will evaporate. However, in locations with high rainfall, you may wish to fabricate a rain shield above the fixture, or modify the position and orientation of the fixture to minimize pooling.
  • Page 9 Connecting AC Power The fixture can operate on any 100–240 V, 50/60 Hz AC mains power supply. It draws approximately 2 amps at full power. For permanent installation, have a qualified electrician wire the mains cable directly to a suitable branch circuit. The junction’s ingress protection (IP) rating must be suitable for the location.
  • Page 10 Configuring the fixture Set up the fixture using the control panel and LCD display at the arm side of the fixture. Navigate the menus and options using the arrow buttons and select items using the Enter button. The options available are listed in “Control menu” on page 13. After powering on, the display shows the currently selected operating mode and other information.
  • Page 11 Connecting to a DMX control device The fixture is controllable using a DMX control device and it can be connected using a DMX cable. If using a cabled DMX system, connect the DMX in cable (with male 3-pin XLR plug) and out cable (with female 3-pin XLR plug) to the DMX data link. Terminate the DMX out cable of the last fixture in the data link.
  • Page 12 Configuring the fixture for DMX control About DMX The fixture can be controlled using signals sent by a DMX controller on a number of channels (which varies depending on the DMX mode that has been set). The first channel used to receive data from a DMX control device is known as the DMX start address.
  • Page 13 Cleaning To maintain optimal performance, regular cleaning is essential. Cleaning schedules will vary depending on the operating environment, and the installation should therefore be checked at frequent intervals within the first few weeks of operation to see whether cleaning is necessary. This procedure will allow you to assess cleaning requirements in your par- ticular situation.
  • Page 14 DMX protocols...
  • Page 27 14 Channel mode Channel Name Description Value Tilt 0-255 Tilt Movement 0-255 Tilt Fine Movement Tilt Fine Dimme 0-255 Plate Macro Off Plate Macro 1 10-14 Plate Macro 2 Plate Macro 15-19 Plate Macro 3 … Plate Macro … 250-254 Plate Macro 50 Plate Macro 51 Plate Macro Color...
  • Page 28 5 Channel mode-Net DescriptionDMX Chan Name Value Coarse Tilt (MSB) 0- 185° 0-255 Coarse tilt + 0- 1.2° 0-255 Fine Tilt (LSB) Intensity 0- 100% Beam Intensity 0-255 Flash duration 7 - 6 5 0 Beam Duration 0-255 6-42 flash1 Beam Shutter 43-85 Flash2...

  • Page 29: Dmx Address Setting

    power-on password: UP - DOWN- UP - DOWN- ENTER 2nd LEVEL 1rd LEVEL 1th LEVEL LEVEL Address enter （1~499） IP (0-255) Enter IP (0-255) Enter IP Address IP (0-255) Enter IP (0-255) Enter Net IP 255.0.0.0 Enter 255.255.0.0 Enter Sub tmask 255.255.255.0 Enter Strobe Universe...

  • Page 30: Dmx Channel

    Offset Invert TILT < > Feedback Ch / En Display Normal Display Dir Reverse Backlight Manual Tilt Dimmer Strobe macro macroS Green Blue White Show RGB Auto Speed RGB Show W Speed W TILT RDM UID Informati Version DMX channel Run time Use time Temperature...
  • Page 31 12. Specification Strobe Panel LEDs LED Type: 5050 0.5W RGB 3in1 LEDs LED Count: 504 LED Colors: RGB LED Segments: 14 (2 x 7) Strobe Tube LEDs LED Type: 3535 5W 6500K LEDs LED Count: 392 LED Colors: Cool-White LED Segments:28(2x14...
  • Page 32 Movement Resolution: 8-16 Position Feedback: Tilt (Degrees): 185° Control Control Modes:8 Display: Illuminated graphic LCD Protocol: USITT DMX-512, RDM RDM: Bidirectional communication Wireless DMX: 2.4 GHz W-DMX™ (optional) Cooling: Temperature controlled, overheating protection Effects Dimmer: 0-100% electronic Shutter: electronic, max. 20 Hz Internal Effects: LED Macro Effects Connectors Signal connection: Seetronic IP65 XLR 5-Pin or 3-Pin In/Out...
  • Page 33 Shipping Single fixture: cardboard (inner and outer cartons) Tourpack: 4-way Flight Case Housing Colors Standard colors: black Dimensions & Weight Length: 502 mm / 119.8 in Width: 137 mm / 5.4 in Height (head horizontal): 326 mm / 12.8 in Weight N.W: 11.2 kg G.W: 13.5 kg...

  • Page 34: Name Quantity

    ACCESSORIES These items are packed together with the projector: Name Quantity Unit Remark Paper This manual 1.5m Power cable 1.5m XLR cable Safety cord...
