- Page 1 Wind Up 100-4 Lighting Stand...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 30.10.2023, ID: 504973...
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features................................9 Operation..............................10 Technical specifications........................15 EU declaration of conformity......................16 Protecting the environment......................18 Wind Up 100-4 Lighting Stand... - Page 4 Wind Up 100-4 Lighting Stand...
-
Page 5: General Information
Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. Wind Up 100-4 Lighting Stand... - Page 6 This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – danger zone. Wind Up 100-4 Lighting Stand...
-
Page 7: Safety Instructions
Risk of injury due to tipping of the stand during loaded transport! If the stand is moved without having removed the installed devices, the stand may tip over and cause injuries and property damage. Remove the installed devices before transporting the stand. Wind Up 100-4 Lighting Stand... - Page 8 The plasticiser contained in the rubber feet of this product may react with the coating of the floor and cause permanent dark stains after some time. If necessary, use a suitable mat or felt slide to prevent direct contact between the device’s rubber feet and the floor. Wind Up 100-4 Lighting Stand...
-
Page 9: Features
Two telescopes, extendable by means of a crank 3/8" mount (suitable for holding speakers with a 35 mm flange) Maximum weight-bearing capacity: 110 kg Maximum height: 4.13 m Cross beam included in delivery optional truss adapter: Item no. 337351 Wind Up 100-4 Lighting Stand... -
Page 10: Operation
Risk of injury due to tipping of stand on an unsuitable ground! When the stand is installed on soft or uneven ground, the stand may tip over and cause injuries and property damage. Install the stand only on even and solid ground. Wind Up 100-4 Lighting Stand... - Page 11 Never exceed the specified maximum load for the truss beam. Spread the weight of the mounted devices evenly on the truss beam. Comply with regulations When installing and operating, make sure to follow the standards and regulations that apply in your country. Wind Up 100-4 Lighting Stand...
- Page 12 Loosen safety screw [1] on the lower carriage and unfold stand feet [2] until safety bolt [10] engages in the desired position in main tube [3]. Fix the position with safety screw [1] on the lower carriage to which the four cross beams are attached. Wind Up 100-4 Lighting Stand...
- Page 13 [7]. Fix the position of the square tube with safety screw [6] on the tube clamp of main tube [3]. Turn crank [8] slightly anti-clockwise to avoid over-tensioning the wire rope. Wind Up 100-4 Lighting Stand...
- Page 14 Loosen safety screw [1] on the lower carriage, to which the four cross struts are attached, and fold up the feet of stand [2]. Pack all parts of the system in their original package, as possible, and store the package in a dry place protected against moisture. Wind Up 100-4 Lighting Stand...
-
Page 15: Technical Specifications
3/8" mount; flange, Æ 35 mm Tripod space, max. 2.13 m Load, max. (with centric load) 110 kg Transport size 1.95 m Weight 28.8 kg Dimensions cross beam 1300 mm × 35 mm × 35 mm Wind Up 100-4 Lighting Stand... -
Page 16: Eu Declaration Of Conformity
Name and address of Thomann GmbH manufacturer Hans-Thomann-Straße 1 96138 Burgebrach Germany 504973 Roadworx Win Up 100-4 Product identification THE PRODUCTS MENTIONED IN THIS DECLARATION ARE IN CONFORMITY WITH: EU Community Legislation Machinery Directive 2006/42/EC Safety of machinery Harmonised standards... - Page 17 EU declaration of conformity SIGNED FOR AND ON BEHALF OF: Burgebrach, 18 November 2021 Place and date of issue Wind Up 100-4 Lighting Stand...
-
Page 18: Protecting The Environment
Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling. Please follow the instructions and markings on the packaging. Observe the disposal note regarding documentation in France. Wind Up 100-4 Lighting Stand... - Page 20 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
