- Page 1 Wind Up 100-4 Lighting Stand...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 22.06.2022, ID: 504973...
-
Page 3: Table Of Contents
General information..........................4 1.1 Further information........................... 5 1.2 Notational conventions........................6 1.3 Symbols and signal words....................... 7 Safety instructions............................. 9 Features............................... 11 Operating..............................12 Technical specifications........................19 EU declaration of conformity......................20 Protecting the environment......................22 Wind Up 100-4 Lighting Stand... -
Page 4: General Information
Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. Wind Up 100-4 Lighting Stand... -
Page 5: Further Information
Our online guides provide detailed information on technical basics Online guides and terms. Personal consultation For personal consultation please contact our technical hotline. If you have any problems with the device the customer service will Service gladly assist you. Wind Up 100-4 Lighting Stand... -
Page 6: Notational Conventions
The individual steps of an instruction are numbered consecutively. The result of a step is indented and highlighted by an arrow. Example: Switch on the device. Press [Auto]. ð Automatic operation is started. Switch off the device. Wind Up 100-4 Lighting Stand... -
Page 7: Symbols And Signal Words
NOTICE! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Wind Up 100-4 Lighting Stand... - Page 8 General information Warning signs Type of danger Warning – danger zone. Wind Up 100-4 Lighting Stand...
-
Page 9: Safety Instructions
Ensure that plastic bags, packaging, etc. are properly disposed of and are not in the reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the product. They could swallow the pieces and choke! Never let children play unattended with the product. Wind Up 100-4 Lighting Stand... - Page 10 The plasticiser contained in the rubber feet of this product may possibly react with the coating of your surface and after some time cause permanent dark stains. In case of doubt, do not put the rubber feet directly on the surface and use a suitable underlay if neces‐ sary, i.e. felt pads or similar. Wind Up 100-4 Lighting Stand...
-
Page 11: Features
Two telescopes, extendable by means of a crank 3/8" mount (suitable for holding speakers with a 35 mm flange) Maximum weight-bearing capacity: 100 kg Maximum height: 4 m Cross beam included in delivery optional truss adapter: Item no. 337351 Wind Up 100-4 Lighting Stand... -
Page 12: Operating
Danger of tipping when transported under load If the stand is moved without having removed the installed device, the stand may tip over and cause injuries and property damage. Remove the installed device before transporting the stand. Wind Up 100-4 Lighting Stand... - Page 13 Install the stand only on even and solid surfaces. CAUTION! Danger of tipping due to overload In case of overload, the stand may tip over and cause injuries and property damage. Never exceed the maximum load capacity specified for the stand. Wind Up 100-4 Lighting Stand...
- Page 14 In case of doubt, do not put the rubber feet directly on the surface and use a suit‐ able underlay if necessary, i.e. felt pads or similar. Comply with regulations When installing and operating, make sure to follow the standards and regulations that apply in your country. Wind Up 100-4 Lighting Stand...
- Page 15 Operating Setup & ö Loosen the safety screw [1] on the lower slide and unfold the tripod feet [2] until the safety bolt [10] engages in the desired position in the main tube [3]. Wind Up 100-4 Lighting Stand...
- Page 16 [7]. Fix the position of the square tube with the safety screw [6] on the tube clamp of the main tube [3]. Turn the crank [8] slightly counter-clockwise to avoid over-tensioning the wire rope. Wind Up 100-4 Lighting Stand...
- Page 17 [3]. Loosen the safety screw [1] on the lower slide, to which the four cross struts are attached, and fold up the feet of the tripod [2]. Wind Up 100-4 Lighting Stand...
- Page 18 Operating Pack all parts of the system in their original package, as possible, and store the package in a dry place protected against moisture. Wind Up 100-4 Lighting Stand...
-
Page 19: Technical Specifications
3/8" mount; flange, Æ 35 mm Tripod space, max. 1.6 m Load, max. (with centric load) 100 kg Transport size 1.75 m Weight 25 kg Dimensions cross beam 1300 mm × 35 mm × 35 mm Wind Up 100-4 Lighting Stand... -
Page 20: Eu Declaration Of Conformity
Name and address of Thomann GmbH manufacturer Hans-Thomann-Straße 1 96138 Burgebrach Germany 504973 Roadworx Win Up 100-4 Product identification THE PRODUCTS MENTIONED IN THIS DECLARATION ARE IN CONFORMITY WITH: EU Community Legislation Machinery Directive 2006/42/EC Wind Up 100-4 Lighting Stand... - Page 21 EU declaration of conformity Harmonised standards Safety of machinery EN 1005-3:2002 + A1:2008 EN 13157:2004 + A1:2009 EN ISO 12100:2010 SIGNED FOR AND ON BEHALF OF: Place and date of issue Burgebrach, 18 November 2021 Wind Up 100-4 Lighting Stand...
-
Page 22: Protecting The Environment
Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. Please follow the notes and markings on the packaging. Wind Up 100-4 Lighting Stand... - Page 24 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
