Daktronics Sportsound SSN-250 Installation Instructions

Sportsound SSN-250 Installation Work Instructions
Task (Major Step) Process / Key Points /
THESE ARE FIELD SERVICE INSTALLATION INSTRUCTIONS. REFER TO SUBCONTRACTOR SCOPE OF WORK FOR THEIR RESPONSIBILITIES.
1. Receive Equipment a. Equipment for audio system is generally crated together.
b. Store all control equipment in a secure location
F Unload equipment from truck
F Store control equipment in secure location
2. Inspect Equipment for Damage a. Visually inspect the exterior finish of all items for deep
F Inspect equipment for dirt/damage
b. Contact PM/PC about any damaged goods.
F Clean/repair/report dirt/damage to PM
3. Install Speaker Cluster a. Mounting options vary. Follow drawings for proper
F Hang and assemble speaker cluster
b. Verify proper assembly and rigging - connections are
F Verify proper rigging
c. Install Speaker J-box near speaker cluster to ceiling
F Install Speaker J-box
4. Aim and Set Speakers
a. Speakers need to be aimed properly to fit venue. A good
F Aim speakers to fit venue
b. Verify Equalization switch is set to Music on column
F Record Angles:
Column 1:____________
c. Verify Vertical Coverage switch is set to Broad on column
Column 2:____________
Court 1:____________
Court 2:____________
5. Mount Control Enclosure (Amp Rack)
a. The control enclosure (AKA "amp rack") should be
F Determine location for control enclosure
F Mount backpan to the wall
b. Mount the backpan to the wall using approved
F Mount rack to the backpan
c. Lift and mount the rack to the backpan using supplied
6. Route and Terminate 8-Conductor a. Verify the speaker cable is pulled into the speaker J-box
Speaker Cable
b. Terminate the speaker cable to the amplifier as shown.
F Verify cable is pulled
c. Terminate the speaker cable to the speaker J-box as
F Terminate speaker cables to amp
If these connections were done by others, double-check
F Terminate speaker cables to J-box
and verify.
7. Test and Terminate Speakers to J-box a. The top and bottom half of the column speakers get
F Test resistance of speakers
F Record resistance values:
1 Top: _________ 1 Bottom: ___________
b. Both court speakers get paralleled together on the
2 Top: _________ 2 Bottom: ___________
Court 1: _________ Court 2: ___________
Subwoofer: ___________
c. The subwoofer gets terminated to the 4th set of terminals
F Terminate the column speakers
F Terminate the court speakers
F Terminate the subwoofer
DD4791303
Rev 00
18 December 2020
Reason Why (if applicable)
to
prevent damage or theft.
scratches, dents, chips, etc.
mounting.
tight and made properly.
structure.
starting point is 10 degrees down.
speakers.
speakers.
installed in a location near the speaker cabinet easily
accessible from the ground where the speaker wire will
reach.
hardware.
hardware.
and amplifier rack.
shown.
paralleled together in the J-box. Use fork connectors
on the speaker terminals. Before J-box termination, test
resistance between white and black wire of each pair.
third set of terminals in the J-box. Use fork connectors
on the speaker terminals. Before J-box termination, test
resistance between white and black wire of each pair.
in the J-box. Use fork connectors on the speaker
terminals. Before J-box termination, test resistance
between white and black wire.
Tools Required / Reference Materials
Sportsound Indoor SSN-250 Audio System
Installation Manual (DD3580600)
This manual includes all drawings
referenced below.
• mild soap
• nonabrasive cloth
• Section 3 of Installation Manual
DWG-3393643 , DWG-3394171,
•
and/or Site-Specific Drawings
• Tools to install hardware
4b/4c. Equalization &
Section 3 of Installation Manual
•
• DWG-1200806
• Tools to adjust hardware, small flat
screwdriver
Section 3 of Installation Manual
•
• DWR Series Instruction Sheet
(included in Appendix B of
installation manual)
• DWG-3750728
• Tools to install anchors/hardware
6a. Terminate Speaker
-
+
Cable to Amp
• Section 4 of Installation Manual
DWG-3822601
•
• wire stripper
• small flat screwdriver
• Section 4 of Installation Manual (see
also Resistance Check in Section 5)
DWG-3822601
•
• multimeter
• wire stripper, crimper
• E-1078 fork terminals
• Phillips and small flat screwdrivers 7a/7b. Fork connectors
201 Daktronics Drive
Brookings, SD 57006-5128
www.daktronics.com/support
800.325.8766
Vertical Coverage
+ RED
- BLK
+ BLU
- BRN
+ WHT
- GRN
+ YEL
- ORG
6b. Terminate Speaker
Cable to J-box
7c. Fork connectors on
on Column & Court Subwoofer
Page 1 of 2
All Outputs =
+ WHT & - BLK
