Daktronics Sportsound 1000 Series Installation And Operation Manual

2nd generation
Hide thumbs

Advertisement

Quick Links

Download this manual
Sportsound 1000 series
nd
2
Generation
Installation and Operation Manual
Rev 0 – 16 November 2007
ED-18519

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sportsound 1000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Daktronics Sportsound 1000 Series

Summary of Contents for Daktronics Sportsound 1000 Series

  • Page 1 Sportsound 1000 series Generation Installation and Operation Manual Rev 0 – 16 November 2007 ED-18519...
  • Page 2 – graphic, electronic, or mechanical, including photocopying, taping, or information storage and retrieval systems – without written permission of the publisher. ® Sportsound is a trademark of Daktronics, Inc. Other trademarks used in this manual are the property of their respective owners.
  • Page 3 Portable Announcer's Rack Enclosure Case Components ..........4 CD player/cassette deck ....................4 Microphone/line mixer ....................5 Power conditioner ......................5 Sportsound 1000 Series Options .................... 5 Wireless handheld microphone system ................ 5 Referee microphone system .................... 6 Wireless in-ear talent, personal monitor system ............6 Hearing assist system ......................
  • Page 4 Section 7: Replacement Parts ....................19 Cabinet parts .......................... 19 Portable announcer’s rack parts ..................19 Sportsound 1000 series options replacement parts ............19 Section 8: Daktronics Exchange and Repair & Return Programs .......... 21 Exchange Program ......................21 Before Contacting Daktronics ..................21 Repair &...
  • Page 5 The reference manuals that will be included for non-Daktronics components are listed in the Reference Manuals section on page 27. Daktronics identifies manuals by an ED number located on the cover page of the manual. For example, this manual would be referred to as ED-18519.
  • Page 6 Reference Drawing: Shop DWG, Standard 1000 Series Cabinet ........Drawing B-246571 The model numbers of a Daktronics system can be found on the ID label on the system. The label will be similar to the one shown in . When calling Daktronics Customer Service,...
  • Page 7 Equipment List Note: All products purchased in this system are individually tested for product safety approval. The Sportsound 1000 series sound systems come complete with all of the following elements: All necessary design, fabrication, processing and amplification equipment, acoustic devices,...
  • Page 8 Portable Announcer's Rack Enclosure Case Components Each Sportsound 1000 series includes a portable announcers control rack. Figure 8 and 9, below, illustrate how the components fit into the rack (H 20"xW 22"xD 21.5"). Figure 8: Portable announcer's rack...
  • Page 9 Weight: 11 lbs (5 kg) For more information, refer to the manufacturers manual in the Manuals Section on page 27. Sportsound 1000 Series Options Wireless handheld microphone system This wireless microphone system option for small and medium sized installs contains a receiver and a handheld transmitter.
  • Page 10 Referee microphone system This wireless microphone system option contains a receiver, a body pack transmitter and a weatherproof headset for referee announcements and a lapel microphone, wind screen and accessories. The receiver is mounted and wired in the portable announcers rack that receives information from the body pack transmitter.
  • Page 11 Shop Drawing, Standard 1000 Series Cabinet ........Drawing B-246571 The Sportsound 1000 series systems are shipped with two lift plates attached to the top of the cabinet. Each lift plate contains a 1" hole. Use a spreader bar or a bridle when lifting the cabinet into place.
  • Page 13 Preparing for Power/Signal Connection Reference Drawing: System Riser Diagram; 1000 Series Sportsound ........Drawing A-246801 Power/signal Drawing A-246801 details power and signal wire hookup of the Sportsound 1000 series. Power The system requires two 20A circuits at 120 VAC for incoming power.
  • Page 14 System Riser Diagram; 1000 Series Sportsound ........Drawing A-246801 Systems must be grounded according to the provisions outlined in Article 250 and 600 of the National Electrical Code and according to the specifications in this manual. Daktronics requires a resistance-to-ground of 10 ohms or less.
  • Page 15 Preparation Ensure that you have a fresh supply of 9V batteries for the wireless microphones. Daktronics advises placing a new battery in each microphone before the beginning of each game. Install the microphone on the Referee, and lock the refs belt to [ON], so that the Referee cannot accidentally bump the system off.
  • Page 16 Power-Up The power switch turns the speaker cabinet ON as shown in Figure 16. Note: Power does not need to be turned on in the announcers rack for this to work. Always Figure 15: Power switch turn off and unplug the 5-Pin XLR from the back of the Announcers Rack when not in use.
  • Page 17 Send a signal from a connected device (mp3 player, video, etc) and turn up corresponding knobs to desired volume levels. Speak into the microphone and turn up their corresponding knobs to desired volume level. Perform a Clear Scan The Sportsound 1000 control system may include wireless microphones. This microphone consists of a microphone interfaced to a battery-powered transmitter.
  • Page 18 Powering Down Turn the sound system knob to [O Turn the power conditioner to [O Unplug the 5 pin XLR and power connections to the announcers rack. When the scoreboard is powered off at the breaker panel, power off the breaker that controls the cabinet.
  • Page 19 Reference Manuals section on page 27. If the problem persists, please contact Daktronics for assistance. Note: The standard level used to test Sportsound equipment is Level 5, or knobs turned to the 12 o’clock position.
  • Page 20 No sound Announcer microphone is not Plug in announcer microphone from cabinet plugged into appropriate input on into appropriate input in the the back of the portable back of the portable announcers rack announcers rack No sound The in-line announcers handheld Press the press to talk switch from cabinet press to talk microphone switch is...
  • Page 21 Announcers Rack This is a critical point in the trouble shooting process because it confirms that audio is leaving the mixer. Current models are equipped with a peak signal Figure 17: Peak signal indicator indicator shown in Figure 19, with red indicating that the signal leaving the rack is clipped or clipping is eminent.
  • Page 23 A-1958 combination CD player /cassette deck A-1960 microphone/line mixer A-1959 power conditioner 0A-1340-0126 rack indicator and switch plate assembly Sportsound 1000 series options replacement parts A-2024 Telex 500 HD A-Band UHF Wireless Microphone System A-2056 receiver (base, in rack) A-2146 microphone (handheld)
  • Page 24 A-2051 microphone (belt pack) A-2141 Telex, Lapel mic A-1211 switch box A-2140 antenna for transmitter A-1972 Special Projects mic A-1972 Head worn Microphone A-1951 Wireless In-ear Talent Personal Monitor System A-2016 ADA hearing assist kit A-1908 in-ear speaker A-2049 transmitter A-2050 receiver A-1907 universal antenna kit A-1908 single ear bud...
  • Page 25 Repair & Return Program. Exchange Program Daktronics unique Exchange Program is a quick service for replacing key parts in need of repair. If a part requires repair or replacement, Daktronics sends the customer a replacement, and the customer sends the defective part to Daktronics. This decreases display downtime.
  • Page 26 Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps Call or Fax Daktronics Customer Service: Refer to the appropriate market number in the chart listed on the previous page.
  • Page 27 Reference Drawings Drawings in this manual are referenced by their last set of digits and the letter preceding them. Drawings in this appendix are listed in alphanumeric order. Sportsound System Structural Mount ................ Drawing A-239409 System Riser Diagram; 1000 Series Sportsound ............Drawing A-246801 Shop Drawing, Standard 1000 Series Cabinet ............
  • Page 35 Reference Manuals Rane Microphone/Line Mixer (A-1960) ..................ED-15655 Furman Sound Pro PM-8 Series II (A-1959)................ED-15658 Shure PSM600 Wireless In-Ear Monitor System (A-1951) ............ED-15659 Telex FMR-500HD UHF Wireless Microphone System (A-1985 B-Band) ....... ED-15660 Listen Tech LT-800 Transmitter ....................ED-15661 Listen Tech LR-400 Receiver ....................
  • Page 37 OPERATORS MANUAL MLM 82a MIC/LINE MIXER MONO MIC/LINE INPUTS STEREO LINE INPUTS OUTPUTS MLM 82a MIC/LINE MIXER ASSIGN ASSIGN ASSIGN ASSIGN MONO MONO MONO MONO POWER LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL QUICK START This section is provided as a convenience for those in a rush. If you are experienced with this unit or other Rane products, these few words will refresh your memory.
  • Page 38 FRONT PANEL DESCRIPTION MONO MIC/LINE INPUTS STEREO LINE INPUTS OUTPUTS MLM 82a MIC/LINE MIXER ASSIGN ASSIGN ASSIGN ASSIGN MONO MONO MONO MONO POWER LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL SIGnal present/OverLoad LED. This bi-color LED lights green for a -30 dBu signal, and turns red when the Input is within 3 dB of clipping.
  • Page 39 REAR PANEL DESCRIPTION OUTPUTS LINE INPUTS MIC/LINE INPUTS MLM 82a POWER MADE IN U.S.A. RANE CORP. N108 600mA LINE LINE LINE LINE PHANTOM CLASS 2 EQUIPMENT BALANCED OR UNBALANCED POWER MIC/LINE INPUTS 1 through 4. These XLRs connect either balanced Microphone or Line signals, depending on the LINE switch setting (see ).
  • Page 40 OPERATING INSTRUCTIONS MONO MICROPHONE/LINE LEVEL INPUTS 1-4 STEREO LINE LEVEL INPUTS 5-8 The microphone pre-amps in the MLM 82a have a The STEREO LINE INPUT LEVEL controls adjust both A and B Inputs equally. Use the OUTPUT LEVEL controls combination gain trim, Level control. The LEVEL control together for overall output adjustment, or separately to control adjusts both the input dynamic range and mix level.
  • Page 41 SERIES II 15 AMP POWER CONDITIONERS...
  • Page 42 SERIES II 15 AMP POWER CONDITIONERS Furman Series II Features SMP+ with extreme voltage shutdown • LiFT (Linear Filtering Technology) with zero ground contamination • Eight rear panel outlets and one front panel outlet • 15 amp rating, with circuit breaker •...
  • Page 43 SERIES II 15 AMP POWER CONDITIONERS I N T R O D U C T I O N all too frequent accidental connections to 208 or 240 VAC, by shutting off the incoming power until the over voltage condition is corrected. Thank you for purchasing a Furman Series II [For E versions: Furman’s SMP clamps at 376 Power Conditioner, and congratulations on...
  • Page 44 SERIES II 15 AMP POWER CONDITIONERS the condition of the cords and cables at the WA R N I N G plugs, and the point where they exit your To reduce the risk of electrical shock, do not Series II unit. To prevent risk of fire or injury, expose this equipment to rain or moisture.
  • Page 45 SERIES II 15 AMP POWER CONDITIONERS extremely long life span. A dimmer control gauge heavy-duty power cable. for the rack lights allows the user to adjust PL-PLUS D SERIES II the level of illumination or simply switch the lights off. Additionally, a rear mounted BNC The PL-Plus D II features LED rack lights jack accepts any standard (12VAC 0.5 amp) which produce virtually no heat and provide...
  • Page 46 SERIES II 15 AMP POWER CONDITIONERS O P E R AT I O N LED lamps must be replaced by qualified Furman service personnel. Retractable Rack Lights, Rear Panel Lamp Multi-Segment LED voltmeter: and Dimmer Control: (PL-Plus II only) The PL-8 II, PL-Plus, and PL-Plus D II utilize This three-color, 20-LED bargraph is an a dimmer control for the two retractable front accurate, self checking AC voltmeter that...
  • Page 47 SERIES II 15 AMP POWER CONDITIONERS many Power Amplifiers. Additionally, the semi- (3) If none of the LED’s on the voltmeter transparent rocker lights when switched to the are lit, and the Extreme Voltages “ON” position. (E-versions feature 10 amp capacity) LED indicator is illuminated, then the PL-Plus II has shut down power to its Extreme Voltage Shutdown Indicator:...
  • Page 48 SERIES II 15 AMP POWER CONDITIONERS is below 85 - 90 volts at turn on, the unit will not NOTE: If the mains power is above the high allow AC voltage to reach the outlets. cutoff voltage and has caused the unit to remove power from its outlets, it cannot restore Action Needed: Correct the line voltage, then power without the operator manually turning...
  • Page 49 SERIES II 15 AMP POWER CONDITIONERS frequencies than the 50 or 60 Hz AC line, it can THE FOREGOING IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, be effectively reduced through use of low-pass INCLUDING BUT NOT LIMITED TO THE filtering.
  • Page 50 SERIES II 15 AMP POWER CONDITIONERS S E R V I C E SPECIFICATIONS Current rating: Before returning any equipment for repair, 15 amps (“E” versions 10 amps) please be sure that it is adequately packed and Operating Voltage: cushioned against damage in shipment, and 90 to 140 VAC (“E”...
  • Page 51 SERIES II 15 AMP POWER CONDITIONERS Circuit Breaker Light Switch Voltmeter Power Switch Lights Dimmer Control LED Rack BNC Connector for Goosneck Light 8 Switched Outlets...
  • Page 52 SERIES II 15 AMP POWER CONDITIONERS Furman Sound, Inc. 1997 South McDowell Blvd. Petaluma, California 94954-6919 USA Phone: 707-763-1010 Fax: 707-763-1310 Web: www.furmansound.com 111804-C E-mail: info@furmansound.com...
  • Page 53 Personal Stereo Monitor System PSM 600  Wireless Personal Stereo Monitor System User Guide 2003, Shure Incorporated Printed in U.S.A. 27C8557 (Rev. 3)
  • Page 54 WARNING! USE OF THIS SYSTEM AT AN EXCESSIVE VOLUME MAY RESULT IN PERMANENT HEARING DAMAGE. OPERATE AT THE LOWEST POSSIBLE VOLUME. In order to use this system safely, avoid prolonged listening at excessive sound pressure levels. Please refer to the following guidelines established by the Occupational Safety Health Administration (OSHA) on maximum time exposure to sound pressure levels before hearing damage occurs.
  • Page 55 TABLE OF CONTENTS Getting Started with the PSM600 ..............Introduction .
  • Page 56 GETTING STARTED WITH THE PSM600 SYSTEM Thank you for purchasing the PSM600 Personal Stereo Monitor System. The PSM600 is a revolutionary new product family designed to meet the diverse audio monitoring needs of musicians, engineers, and stage performers. This section outlines step-by-step instructions to quickly show you how to connect your PSM system to an audio source while introducing you to some of its features.
  • Page 57 INTRODUCTION Description The Shure PSM600 Personal Stereo Monitor System is a UHF wireless, two-channel stereo, monitor system designed for onstage applications. The PSM has several advantages over onstage loudspeaker monitors: it is less visible, has better sound, allows freedom of movement, and reduces the chances of feedback. It is a versatile system, designed for use in many different sound reinforcement applications: public address, live music, theater, and electronic news gathering (ENG).
  • Page 58 OVERVIEW P6T Transmitter Front Panel Ê Ë Ì Í Î Ï Ð Ê Î INPUT Dial. This controls the signal level to the Headphone Connectors — -in. phone and 3.5 transmitter modulator. For optimum sound, the mm ( -in) mini. Each connector is configured as input level should be set in the –3 dB to +3 dB left=tip, right=ring, ground=sleeve.
  • Page 59 P6R Receiver Controls and Connectors Ê Ì Ï ÊË Í Î Ð Ï Î Ò Ñ Ó Ó Ê counter-clockwise to lower the volume in the Balance Dial. In stereo mixes, this controls the earpieces. left/right balance. In MixModet, this controls the Ï...
  • Page 60 INSTALLATION AND APPLICATIONS The flexible design of the PSM600 Personal Stereo Monitor System makes configuring a monitor mix very simple. In addition, the unique MixMode circuitry enables you to customize your own individual mix in a multiple mix environment. To help you install the PSM600 into your sound system, the tables and diagrams in this section describe three distinct modes of operating or controlling the system.
  • Page 61 MixMode Control This diagram shows how to connect the PSM600 system with two monitor mixes combined at the receiver. This allows you to vary the level between the two mixes to create a custom mix. VOICE MIX FULL LEFT FULL RIGHT Ñ...
  • Page 62 LOOP Applications The LOOP OUT L (left) and R (right) outputs allow the signal going through the P6T to be run to other devices. The LOOP feature of the P6T can be used for any number of applications. Shown here are only a few examples of how it can be used. NOTE: The LOOP connectors act as either inputs or outputs.
  • Page 63 Running Multiple PSM Wireless Systems Under MixMode Control A main mono monitor mix can be sent to multiple P6T transmitters, then independent monitor mixes can be sent to the second channel of each. This will allow an entire band to hear the same monitor mix, while giving each individual player a separate mix of their own.
  • Page 64 ACCESSORIES Several additional products have been developed as part of the PSM product family. These products can enhance the operation of your system, and must be purchased separately. PA705 Unidirectional Antenna The PA705 is a unidirectional, remote-mountable, wideband transmit- ting antenna designed to provide wireless coverage in a cardioid pattern. You can use the PA705 to secure a line-of-sight transmission path from the transmitter to the receiver when the actual transmitters are obscured.
  • Page 65 TROUBLESHOOTING PROBLEM SOLUTION No sound at the Receiver n Check the power cord on the Transmitter and make sure it is powered on. n Make sure both the transmitter and the receiver are set to the same frequency. n Make sure the earpiece is plugged into the receiver. n Make sure receiver is on and the battery is good.
  • Page 66 IMPORTANT!: Antenna External, threaded connector THIS RADIO EQUIPMENT IS INTENDED FOR USE IN Power Requirements MUSICAL PROFESSIONAL ENTERTAINMENT AND 9 V battery SIMILAR APPLICATIONS. Battery Life NOTE: THIS RADIO APPARATUS MAY BE CAPABLE 4–6 hours, volume dependent OF OPERATING ON SOME FREQUENCIES NOT AUTHORIZED YOUR REGION.
  • Page 67 CUSTOM EARPIECES Tip = hot Assignments: ring = cold For information regarding a complete line of custom sleeve = ground made musicians’ earpieces, contact: Phantom Power Protection? Up to 60 VDC Ultimate Ears Inc. 2657 Windmill Pkwy. #391 Henderson, NV 89014 FURNISHED ACCESSORIES (702) 263–7805 Body-Pack Antenna...
  • Page 68 APPENDIX B. RACK MOUNTING OPTIONS Rack Mounting the P6T Transmitter NOTE: Dual mounting with other Shure products. The P6T can also be dual mounted with a Shure SC or LX half-rack wireless receiver. These same instructions apply, but the front panels will not align evenly. The SC and LX receivers must use the SC and LX rack ears.
  • Page 69 Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ Ñ...
  • Page 70 TABLE 1 TABLEAU 1 TABELLE 1 TABLA 1 TABELLA 1 Country Code Code de Pays Lander–Kurzel Código de país FREQ CODE FREQ1 (MHZ) FREQ2 (MHZ) Codice del Paese 626.475 (TV 40) 632.550 (TV 41) 629.975 (TV 40) 634.775 (TV 41) 642.275 (TV 42) 646.500 (TV 43) 647.525 (TV 43)
  • Page 71 SHURE Incorporated Web Address: http://www.shure.com 5800 W. Touhy Avenue, Niles, IL 60714–4608, U.S.A. Phone: 800-257–4873 Fax: 847-600-1212 In Europe, Phone: 49-7131-72140 Fax: 49-7131-721414 In Asia, Phone: 852-2893-4290 Fax: 852-2893-4055 Elsewhere, Phone: 847-600–2000 Fax: 847-600-6446...
  • Page 73 T elex Op er at ing In struc tions FMR-500 User Guide...
  • Page 76 Sec tion 1 - Quick Set-Up Quick Set-up: Re ceiver 5. Use the up and down ar rows to change the Group num ber to match the Group num ber dis - - 1. Do not con nect the re ceiver to any other equip - - played on the re ceiver.
  • Page 77 Sec tion 3 - De tailed Com po nents De scrip tion FMR-500 Re ceiver Con trols, Con nec tors, and In di ca tors 8 8 5 5 Balanced U.S. Patent No. 6,256,484 Audio Telex 12-15V Antenna Telex FMR-500 BAND A AC/DC power...
  • Page 78 NOTE: Groups 9 and above are set up to work Now re fer ahead to trans mit ter setup and re turn with the other US fre quency band (A and B). If to step 9 when that is com pleted. you are us ing a mix of Band A and Band B, scroll 9.
  • Page 79 Rack Mount In stal la tion The FMR-500 is sup plied with rack mounts for sin - - Four dou ble mount ing of two FMR-500's pro ceed gle and dou ble mount ing in a stan dard EIA 19"/ as fol lows: 483mm equip ment rack (see Fig ure 3).
  • Page 80 Handheld Trans mit ter HT-500 755050 Fig ure 5 Handheld Trans mit ter Fig ure 6 HT-500 Con trols, Trans mitt er Con nec tors, and In di ca tors 5. Chan nel/Fre quency Up Switch 1. Main Dis play - LCD (Chan nel, Fre quency or Bat tery Level In di ca tion) 6.
  • Page 81 8. Ver ify re cep tion. With the trans mit ter and re - - To ad just the trans mit ter gain, gently in sert the pro vided screw driver (or other 3/32 - 2.5 mm ceiver on and match ing Group and Chan nel, the main re ceiver dis play should be in di cat ing a RF screw driver) into the ad just ment hole above the sig nal on the bar graph.
  • Page 82 Have the speaker or singer use the mi cro phone Bodypack Trans mit ter Setup in a nor mal per for mance level voice. The Au dio and Op er a tion Me ter in the main re ceiver dis play screen should show peaks around the -3 dB level.
  • Page 83 Sec tion 4 - Re ceiver Dis play Screens and Func tions Main Op er at ing Screen -20 -10 -5 0 +3 CLEARSCAN R R F F 1 3 10 30 100 Fig ure 10 Main Op er at ing Screen Dis play: Con trols: 1.
  • Page 84 Trans mit ter On/Off Lock-Out There are two On/Off lock out modes avail able, One Once the work ing Group has been es tab lished, Time and Everytime. leave the first trans mit ter on, set the next re ceiver Group to the work ing Group and run ClearScan for One Time: Cy cle the power switch 3 times in un der Chan nels.
  • Page 85 Sec tion 5 - Trou ble Shoot ing Guide Pos si ble Causes So lu tions Prob lem Re ceiver is off Make sure that the power No au dio and no dis play on sup ply is prop erly con nected the re ceiver and the on/off but ton is in the on po si tion...
  • Page 86 Trou ble Shoot ing Guide (con tin ued) Pos si ble Causes So lu tions Prob lem Re ceiver is too close to dig i - - Move the re ceiver to a In ter fer ence (con tin ued) tal sig nal pro ces sor or sim i lar dif fer ent lo ca tion de vice...
  • Page 87 Sec tion 6 - Tech ni cal Spec i fi ca tions FMR-500 Re ceiver Spec i fi ca tions Over all Re ceiver Type ........... . Syn the sized PLL Fre quency Range (RF) .
  • Page 88 Sec tion 7 - Ac ces so ries and Parts MODEL No. Or der No. Omnidirectional La pel Mi cro phone WLM-50 64277000 Uni di rec tional La pel Mi cro phone UML21 ULM21 Pre mium Omnidirectional La pel Mi cro phone ELM-22 70925006 Pre mium La pel/In stru ment...
  • Page 89 User’s Manual LT-800 Stationary Transmitter D o n ’ t m i s s a s i n g l e s o u n d . L i s t e n . Listen Technologies Corporation 8535 South 700 West, Suite A Sandy, Utah 84070-2515 U.S.A.
  • Page 90 Dear Valued Customer, Thank you for choosing Listen! All of us at Listen are dedicated to providing you the highest quality products and prompt, efficient customer care. Our products are manufactured in an ISO-9000 factory that has been independently certified to the highest quality standards.
  • Page 91 Table of Contents Specifications ............2 Block Diagram .
  • Page 92 Specifications Architectural Specifications The stationary FM transmitter shall be capable of broadcasting on 57 channels. The transmitter shall have a SNR of 80dB or greater. The output power shall be adjustable to quarter, half or full. Channel tuning shall be capable of being locked. The device shall broadcast on both wide and narrow band channels. The device shall have an audio frequency response of 63 Hz to 15k Hz, ±...
  • Page 93 LT-800 Block Diagram POWER 3.5MM Stereo CHANNEL SELECT In-Line Power Supply 115VAC6 LA-201 0 Hz HEADPHONE (provided) 15VAC, 1A Power Supply Down CPU Module Volume Listen LCD Display Backlighted MIX Level Top Mounted Compression Ratio VU Meter Antenna Stud (internal adjustment) Remote Antenna Connection...
  • Page 94 Quick Reference LT-800 Front Panel: Controls & Displays Top mount antenna connection: Indicates Remove rubber plug and screw Process Mode antenna in place is active LCD: Shows Indicates which channel Adjust audio input levels of Indicates audio input Super Quiet is selected Input 1 and Input 2 here.
  • Page 95 LT-800 Setup Instructions Unpack the Product Connect Power Remove outer packaging and plastic cover. Inspect for Plug the power supply into the power connector on the physical damage. back panel, then plug the power supply into an outlet. Only use a Listen Mount in Rack (if necessary) approved power supply If rack mounting the unit, install the optional rack...
  • Page 96 LT-800 Setup Instructions continued Set SQ (Super Quiet) and Process Features Connect Audio Inputs Your transmitter is shipped to you with SQ (super The LT-800 has two audio input options: Input 1 and quiet) enabled and Process disabled. For a detailed Input 2.
  • Page 97 LT-800 Operating Instructions LT-800 Audio Control Power Unit On Adjust Audio Input Level Turn power on by pressing the power button. Adjust the input knob counterclockwise to add gain to Input 1. This will decrease gain to Input 2. Adjust input knob clockwise to add gain to Input 2.
  • Page 98 LT-800 Compatibility with Other Manufacturers If you are using another manufacturers’ receivers with the LT-800, determine the frequency of their receivers then refer to Listen’s Frequency Compatibility Tables (pages 12-14) to find the LT-800 channel that corresponds with the receiver’s frequency. We recommend verifying corresponding channel designations on these tables to ensure compatibility and provide the best possible reception.
  • Page 99 Listen SQ™ (Super Quiet) - Improving Your Listening Experience People are accustomed to listening to low noise, high fidelity audio (delivered via SQ Summary CD, DVD, etc.). FM radio systems, such as those made by Listen, have more · SQ is NOT squelch inherent noise compared to most sound systems.
  • Page 100 RF Reception Maximization Strategies For proper and dependable operation, Listen receivers need to receive a strong and consistent signal from the originating transmitter. Note that on portable receivers the headset wire is the receiving antenna. The following strategies should be used maximize this signal: 1.
  • Page 101 Channel Selection It is important to choose channels that are free from interference to achieve proper Wide Band Recommendation operation of your Listen equipment. This process is trial and error. Before turning Listen recommends that you always use on the transmitter, listen to the wide band channels on the receivers (lettered a wide band channel unless you need to channels at 72 MHz and channels that start with a “2”...
  • Page 102 72 MHz Compatibility Chart Frequency Phonic Listen Comtek Phonak Williams* Gentner Telex Drake 72.0250 (11, 1) 72.0500 72.0750 (12, 3) 72.1000 A, (13, 4) 72.1 72.1250 (14, 5) 72.1500 72.1750 (15, 7) 72.2000 K, (8) 72.2 72.2250 (16, 9) 72.2500 (10) 72.2750 (17, 11)
  • Page 103 216 MHz Compatibility Chart Frequency Phonic Light Listen Comtek Phonak Williams Gentner Speed 216.0125 216.0250 216.0375 216.0625 216.0750 216.0875 216.1125 216.1250 216.1375 216.1625 216.1750 216.1875 216.2125 216.2250 216.2375 216.2625 216.2750 216.2875 216.3125 216.3250 216.3375 Wideband frequencies are indicated in highlighted rows. 216.3625 The highlighted channels also indicated those channels 216.3750...
  • Page 104 Phonak Frequency Chart Frequency Listen Phonak 216.0125 216.0250 216.0375 216.0625 216.0750 216.0875 216.1125 216.1250 216.1375 216.1625 216.1750 216.1875 216.2125 216.2250 Wideband frequencies are indicated in highlighted rows. 216.2375 The highlighted channels also indicated those channels 216.2625 216.2750 available in the “basic” mode (default). All channels 216.2875 can be accessed when in the “expanded”...
  • Page 105 LT-800 Troubleshooting The LT-800 has no power Make sure the LA-201 power transformer is connected to a power source and is connected to the jack marked “Power Input”. Make sure the POWER button is pressed in. There is no audio or the audio level is too low Make sure that your audio source is properly connected to Input 1 and/or Input 2.
  • Page 106 LT-800 Troubleshooting I’m using another brand of receiver - how do I tell which channel to use Refer to Listen’s Frequency Compatibility Tables (pages 12-13). Adjust Listen’s transmitter to the same frequency as the other major brand. Since Listen products can access 57 channels, they will most likely receive on the same fixed channel or channels of other major brands.
  • Page 107 Compliance Notice This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) These devices may not cause harmful interference, and (2) these devices must accept any interference received, including interference that may cause undesirable operation. Listen’s LT-800 Transmitter (216 MHz only) Listen’s LT-800 transmitter is authorized by rule under the Low Power Radio Service (47 C.F.R.
  • Page 108 Warranty Listen Technologies Corporation (Listen ® ) warrants the LT-800 Stationary Transmitter to be free from defects in workmanship and material under normal use and conditions for the useful lifetime of the product from date of purchase. This warranty is only available to the original end purchaser of the product and cannot be transferred.
  • Page 109 Optional Accessories Antenna Options Telescoping (Top Mount) 72 MHz Helical LA-106 for 72 MHz or (Top Mount) LA-102 for 216 MHz LA-101 for 72 MHz 90 Degree Helical 216 MHz Ground Plane LA-122 Universal (Rear Mount) (Remote Mount, outdoor) Antenna Kit LA-123 for 72 MHz or LA-107 for 216 MHz The single solution for all of your indoor...
  • Page 110 Optional Accessories continued Cable & Connectors Options RG-58 Coaxial Installation of BNC BNC Connector BNC Connector for Cable Connectors for RG-58 RG-8 LA-112 LA-128 LA-114 LA-127 RG-8 Coaxial Cable LA-113 available by the foot Microphone Options LA-268 LA-261 Over-the-Head Over-the-Ear Lapel Noise Cancelling LA-262...
  • Page 112 Listen Technologies Corporation 8535 South 700 West, Suite A Sandy, Utah 84070-2515 U.S.A. Telephone: 1.801.233.8992 Toll Free (North America): 1.800.330.0891 Fax: 1.801.233.8995 E-mail: info@ListenTech.com...
  • Page 113 User’s Manual LR-400 Display Receiver D o n ’ t m i s s a s i n g l e s o u n d . L i s t e n . Listen Technologies Corporation 8535 South 700 West, Suite A Sandy, Utah 84070-2515 USA Telephone: +1.801.233.8992 Toll Free (North America): 1.800.330.0891...
  • Page 114 LR-400 Package Contents Listen Part Number · LR-400 (72MHz or 216MHz) 72 MHz: LR-400-072 · Warranty Card 216 MHz: LR-400-216 · Receiver User Manual Optional Accessories See pages 70-71.
  • Page 115 LR-400 Table of Contents Architectural Specifications ..........26 Specifications .
  • Page 116 LR-400 Specifications Architectural Specifications The FM receiver shall be capable of receiving on 57 wide and narrow band channels with a SNR of 80dB or greater. The receiver shall be capable of seeking channels. The device shall have an adjustable squelch. The device shall have an audio frequency response of 63Hz to 15KHz, ±...
  • Page 117 LR-400 Specifications continued Specification LR-400-072 LR-400-216 16mW maximum, impedance 32 Ohms Set Up Controls Alkaline/NiMH batteries and SQ enable/disable and programmable squelch setting. Volume, channel UP/DOWN, SEEK User Controls (All controls except volume are electronically lockable, and are behind the door) Controls Squelch can be adjusted for sensitivity and signal capture control.
  • Page 118 Quick Reference LR-400 Top of Unit LR-400 Front LED indicators · Steady Red: Normal operation LED - when lit, indicates ON/OFF & VOLUME control dial · Slow Flashing: Battery is low unit has power. · Slow Flashing while charging: Unit is charging 3.5mm Input Jack A Listen earpiece or headset connects here.
  • Page 119 Quick Reference LR-400 Inside Access Door Battery Select SEEK button Switch allows the user to change channels or to lock on a Use UP and DOWN buttons channel. to select a channel. Adjustable Squelch: The default factory preset for squelch is 03.(See page 37 for Squelch programming information) SQ Switch...
  • Page 120 Quick Reference LR-400 Look & Listen™ Display Dots indicate the relative RF signal Indicates the currently strength. When there is a full signal tuned channel the unit will display all 8 dots. Battery level indicator. The indicator flashes, along with the red LED on top of the unit, to alert you when the battery is low and needs to be charged or changed.
  • Page 121 LR-400 Setup Instructions Remove the product Remove outer packaging and plastic cover. Inspect for physical damage. If damage is aparent, please contact Listen Technologies Corporation technical support for assistance. See page 69 for contact information. Open the front access door If locked, use a pocketknife or small screwdriver to unlock the door locks on both sides of the unit.
  • Page 122 continued LR-400 Setup Instructions Set SQ switch The SQ switch is inside the battery compartment next to the Battery Select switch. The unit is shipped with SQ in the ON position. To turn it off, use a small screwdriver or pen to slide the switch to the OFF position (to the right).
  • Page 123 continued LR-400 Setup Instructions Turn the Unit On Receivers are turned on by rotating the volume dial counterclockwise. The red LED on top of the unit should activate and the LCD display should illuminate. If they do not, make sure you have installed the batteries correctly and that you are using fully charged batteries.
  • Page 124 LR-400 Operation Instructions Make Sure the Unit is On Rotate the volume knob counterclockwise with an earphone or headset connected to the unit. Listen receivers use the cable of the earphone or headset as a receiving antenna. Be careful when turning the unit on - if you turn the knob too far you might get too much vol- ume in your earphone! Select a Channel Select the channel to match the transmission channel by pressing the UP and DOWN buttons...
  • Page 125 LR-400 Operation Instructions continued Find an audio transmission using SEEK Another way to find a channel on the LR-400 is to use the SEEK button. When you do this, the Listen receiver looks for the next active channel. Sometimes the unit will mistake interference for a real broadcast signal.
  • Page 126 LR-400 Squelch Squelch The purpose of squelch is to mute the audio output of your receiver when the signal from the transmitter is turned off or is too weak to be received. Without squelch you would hear radio noise in your earphone. The squelch on your receiver can be adjusted so that it will mute the audio on different RF signal strengths.
  • Page 127 Squelch Programming Instructions Squelch Programming To enter Squelch programming mode · Turn the unit off · Press and hold the seek button; while still holding seek turn the ON/OFF dial to turn the unit on. · Release the seek button when the Listen name disappears and a two digit display is seen. To adjust the Squelch level ·...
  • Page 128 LR-400 Charging Batteries The LR-400 and all Listen receivers are unique because they have SmartCharge™ chargers built in. When any of these units are connected to Connect LA-202 an LA-202 wall transformer or dropped into a Listen charging case, NiMH here and plug it batteries will be charged.
  • Page 129 LR-400 Charging Batteries continued During the charge cycle, the red LED on top of the Listen product will flash slowly. When charg- ing is completed, the LED will turn off. It is not necessary to unplug the charger; however, if you unplug the unit from the charger and then plug it back in, it will begin the 13-hour charge cycle over again.
  • Page 130 LR-400 Wall Transformer Operation The LR-400 will operate normally when connected to a wall transformer. Use Listen part number LA-202, available from any Listen dealer. Connect the wall transformer to the jack on the side of the LR-400 marked “PWR/CHG” and plug the wall transformer into a grounded AC outlet. You do not need to have batteries installed in the LR-400 to operate it with a wall transformer.
