USB2-H-600X-M FAMILY Hi-Speed USB to
Multi-Ports RS422 Adapter
USB2-H-6016-M
The USB2-H-600X-M family provide a simple method of adapting legacy serial devices with RS422
interfaces to modern USB ports by incorporating the FTDI Hi-Speed USB bridge chips.
The adaptor which is contained within a metal enclosure is either USB powered or externally powered
(depends on the number of ports). They can supply an output of +5VDC @ up to 80mA on the 5mm
terminal block connectors or 30mA on the Pin 9 of DB9 connectors. Indicator LEDs provide functional
status.The USB2-H-600X-M family have been tested to be compliant with both FCC Part 15 Subpart B
and European EMC Directive.
Table of Contents
E-Mail (Support):
support@connectiveperipherals.com
Neither the whole nor any part of the information contained in, or the product described in this manual, may be adapted or reproduced in any material or
electronic form without the prior written consent of the copyright holder. This product and its documentation are supplied on an as-is basis and no warranty
as to their suitability for any particular purpose is either made or implied. Connective Peripherals Pte Ltd will not accept any claim for damages howsoever
arising as a result of use or failure of this product. Your statutory rights are not affected. This product or any variant of it is not intended for use in any
medical appliance, device or system in which the failure of the product might reasonably be expected to result in personal injury. This document provides
preliminary information that may be subject to change without notice. No freedom to use patents or other intellectual property rights is implied by the
publication of this document. Connective Peripherals Pte Ltd, 1 Tai Seng Avenue, Tower A, #03-05, Singapore 536464. Registered Number: 201617872E
Data Sheet
Document Reference No.: CP_000017
Version 1.3
Issue Date:
Part Number
USB2-H-6008-M
USB2-H-6004-M
Connective Peripherals Pte Ltd
1 Tai Seng Avenue, Tower A, #03-05, Singapore 536464
Tel.: +65 67430980
Copyright © Connective Peripherals Pte Ltd
25-06-2024
USB2-H-6002-M
Web:
www.connectiveperipherals.com/products
USB2-H-6001-M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USB2-H-600-M Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Connective Peripherals USB2-H-600-M Series

Summary of Contents for Connective Peripherals USB2-H-600-M Series

  • Page 1 This product and its documentation are supplied on an as-is basis and no warranty as to their suitability for any particular purpose is either made or implied. Connective Peripherals Pte Ltd will not accept any claim for damages howsoever arising as a result of use or failure of this product.

  • Page 2: Table Of Contents

    5V Power Adapter ..............22 RS422 ..................22 RS422 ..................23 6 Physical Environment Details ........24 Storage Temperature .............. 24 Operating Temperature ............24 7 Physical Dimensions ............. 25 USB2-H-6001-M Dimension ............. 25 USB2-H-6002-M Dimension ............. 27 Copyright © Connective Peripherals Pte Ltd.
  • Page 3 Technical Support ..............34 10 Contact Information ............35 Appendix A List of Figures and Tables ......36 List of Figures ................. 36 List of Tables ................... 36 Appendix B Revision History ........... 38 Copyright © Connective Peripherals Pte Ltd.

  • Page 4: Introduction

    RS422 level shifters plus TXD/RXD LEDs to provide a visual indication of data traffic through the module. The following diagrams show images of the modules in the USB2-H-600X-M family: Figure 1.1 - USB2-H-6001-M Copyright © Connective Peripherals Pte Ltd.
  • Page 5 USB2-H-600X-M_FAMILY Data Sheet Version 1.3 Document Reference No.: CP_000017 Clearance No.: CP#009 Figure 1.2 - USB2-H-6002-M Copyright © Connective Peripherals Pte Ltd.
  • Page 6 USB2-H-600X-M appear as Virtual COM Ports (VCP). This allows existing serial communications software, such as HyperTerminal, to exchange data through the USB2-H-600X-M to a legacy RS422 peripheral device. Copyright © Connective Peripherals Pte Ltd.

  • Page 7: Led Description

    Flashes when data is transmitted from the attached Green Each port has one Activity RS422 device to the USB2-H-600X-M. RXLED Table 1.1 LED Description Block Diagram 1.3.1 Single Port Block Diagram Figure 1.4 - USB2-H-6001-M Block Diagram Copyright © Connective Peripherals Pte Ltd.

  • Page 8: Dual Port Block Diagram

    1.3.2 Dual Port Block Diagram Figure 1.5 - USB2-H-6002-M Block Diagram 1.3.3 Four, Eight and Sixteen Ports Block Diagram Figure 1.6 - USB2-H-6004/6008/6016-M Main Board Block Diagram Figure 1.7 - USB2-H-6008/6016-M Daughter Board Block Diagram Copyright © Connective Peripherals Pte Ltd.

  • Page 9: Block Description

    16-ports, it uses two main boards. Daughter board This is used on the 8 and 16 ports product. A single daughter board is used for 8-port adapters. Two daughter boards are use for 16-port adapters. Copyright © Connective Peripherals Pte Ltd.

  • Page 10: Features

    Note: Windows CE5.0 can only support COM0 to COM9 ports and so this will limit the number of ports which can be used. Note: HyperTerminal is no longer provided with Windows 7/Vista but other terminals are available. Copyright © Connective Peripherals Pte Ltd.

  • Page 11: Performance Figures

    Hi-Speed USB to 16-Port RS422 module USB2-H-6008-M Hi-Speed USB to 8-Port RS422 module USB2-H-6004-M Hi-Speed USB to quad-Port RS422 module USB2-H-6002-M Hi-Speed USB to dual-Port RS422 module USB2-H-6001-M Hi-Speed USB to single-Port RS422 module Table 1.3 - Ordering Information Copyright © Connective Peripherals Pte Ltd.

  • Page 12: Installation

    Some serial devices may require certain handshake signals to be connected. Refer to your device manual for cabling details. When you use the handshake signals, please disable the +5V DC power output using SW3. Copyright © Connective Peripherals Pte Ltd.

  • Page 13: Table 2.2 Switch Setting Configuration Of The 4, 8 And 16 Port Products

    They can provide a 5V output with a maximum current of 80mA (when using USB BUS power), or when using the external power adapter the maximum current can be increased. Copyright © Connective Peripherals Pte Ltd.

  • Page 14: Device Driver Installation

    Version 1.3 Document Reference No.: CP_000017 Clearance No.: CP#009 2.2 Device Driver Installation For driver installation, please refer to the Connective Peripherals USB to Serial Converters Driver Installation Guide (CP_000084) which is available from www.connectiveperipherals.com. Copyright © Connective Peripherals Pte Ltd.

  • Page 15: Connections

    Note: In addition, The CTS- Pin of 4, 8 and 16 Ports can provide +5VDC to an external device with a maximum current draw of 30mA once the 4, 8 and 16 Port products have been enumerated by the system. Pin 9 of the single and dual port models only have the RI function. Copyright © Connective Peripherals Pte Ltd.

  • Page 16: 5Mm Terminal Block

    RTS+ = Request To Send, positive Output polarity Input CTS+ = Clear To Send, positive polarity Input CTS- = Clear To Send, negative polarity PWR output +5V DC output Table 3.3 USB2-H-6001-M Terminal Block interface Copyright © Connective Peripherals Pte Ltd.

  • Page 17: Table 3.4 Usb2-H-6002-M Terminal Block Interface

    TXD+ = Transmit Data, positive Output polarity RXD+ = Receive Data, positive Input polarity RXD- = Receive Data, negative Input polarity PWR output +5V DC output Ground GND = RS422 signal ground Table 3.4 USB2-H-6002-M Terminal Block interface Copyright © Connective Peripherals Pte Ltd.
  • Page 18 Figure 3.2 - USB2-H-6002-M Terminal Block Connector Assignment In addition, one pin of the terminal block connector can provide +5VDC to an external device with a maximum current draw of 80mA once the USB2-6001/6002-M has been enumerated by the system. Copyright © Connective Peripherals Pte Ltd.

  • Page 19: Termination And Bias Resistors Setting

    One end of the link also has two 750- biasing resistors. The below figure shows the example when adding termination Copyright © Connective Peripherals Pte Ltd.
  • Page 20 The size of the biasing resistors is a trade-off. For a greater voltage difference and higher noise immunity on an idle line, use smaller values. For lower power consumption and a greater differential voltage on a driven line, use larger values. Copyright © Connective Peripherals Pte Ltd.

  • Page 21: Table 4.1 Bias And Termination Resistor Numbers Of Each Module

    Termination Resistor Numbers Modules Name Daughter Board Main Board USB2-H- (R27,R31),(R28,R32),(R29,R33),(R30,R34) (R30,R34),(R31,R35),(R32,R36),(R33,R37) 60016-M USB2-H- (R27,R31),(R28,R32),(R29,R33),(R30,R34) (R30,R34),(R31,R35),(R32,R36),(R33,R37) 6008-M USB2-H- (R30,R34),(R31,R35),(R32,R36),(R33,R37) 6004-M USB2-H- (R19,R22),(R20,R23) 6002-M USB2-H- R7,R8 6001-M Table 4.1 Bias and Termination Resistor Numbers of Each Module Copyright © Connective Peripherals Pte Ltd.

  • Page 22: Electrical Details

    RL = 50R CL = 50pF trans voltage swing Receiver input RL = 50R CL = 50pF voltage range For all RS-422 Input ESD HBM ±15 and Output pins Table 5.3 - RS422 Electrical Details Copyright © Connective Peripherals Pte Ltd.

  • Page 23: Table 5.4 Rs422 Electrical Details

    Voltage, dVOD CL = 50pF * ESD Tolerance RS422 Inputs and ESD HBM ±15 Outputs RS-422 Inputs and EN61000-4- ±8 Outputs 2ContactDischarge RS-422 Inputs and EN61000-4- ±15 Outputs 2AirGapDischarge Table 5.4 RS422 Electrical Details Copyright © Connective Peripherals Pte Ltd.

  • Page 24: Physical Environment Details

    65%. Table 6.1 - Storage Temperature 6.2 Operating Temperature Parameter Description Minimum Typical Maximum Units Conditions Operating 5% to 95% RH, Temperature Range non condensing Table 6.2 - Operating Temperature Copyright © Connective Peripherals Pte Ltd.

  • Page 25: Physical Dimensions

    USB2-H-600X-M_FAMILY Data Sheet Version 1.3 Document Reference No.: CP_000017 Clearance No.: CP#009 Physical Dimensions All dimensions are in mm, and the tolerances are +/-0.1mm. USB2-H-6001-M Dimension Figure 7.1 - USB2-H-6001-M Top Cover of Dimension Copyright © Connective Peripherals Pte Ltd.
  • Page 26 USB2-H-600X-M_FAMILY Data Sheet Version 1.3 Document Reference No.: CP_000017 Clearance No.: CP#009 Figure 7.2 - USB2-H-6001-M Bottom Cover of Dimension Copyright © Connective Peripherals Pte Ltd.

  • Page 27: Usb2-H-6002-M Dimension

    USB2-H-600X-M_FAMILY Data Sheet Version 1.3 Document Reference No.: CP_000017 Clearance No.: CP#009 USB2-H-6002-M Dimension Figure 7.3 - USB2-H-6002-M Top Cover of Dimension Figure 7.4 - USB2-H-6002-M Bottom Cover of Dimension Copyright © Connective Peripherals Pte Ltd.

  • Page 28: Usb2-H-6004-M Dimension

    USB2-H-600X-M_FAMILY Data Sheet Version 1.3 Document Reference No.: CP_000017 Clearance No.: CP#009 USB2-H-6004-M Dimension Figure 7.5 - USB2-H-6004-M Top Cover of Dimension Figure 7.6 - USB2-H-6004-M Bottom Cover of Dimension Copyright © Connective Peripherals Pte Ltd.

  • Page 29: Usb2-H-6008-M Dimension

    USB2-H-600X-M_FAMILY Data Sheet Version 1.3 Document Reference No.: CP_000017 Clearance No.: CP#009 USB2-H-6008-M Dimension Figure 7.7 - USB2-H-6008-M Top Cover of Dimension Figure 7.8 - USB2-H-6008-M Bottom Cover of Dimension Copyright © Connective Peripherals Pte Ltd.

  • Page 30: Usb2-H-6016-M Dimension

    USB2-H-600X-M_FAMILY Data Sheet Version 1.3 Document Reference No.: CP_000017 Clearance No.: CP#009 USB2-H-6016-M Dimension Figure 7.9 - USB2-H-6016-M Top Cover of Dimension Figure 7.10 - USB2-H-6016-M Bottom Cover of Dimension Copyright © Connective Peripherals Pte Ltd.

  • Page 31: Environmental Approvals & Declarations

    RoHS, WEEE, REACH, PFOS and DecaBDE. 8.4 Reliability The USB2-H-600X-M family are designed as a robust USB-Serial module for use in many environments. There are no user-serviceable parts. Any failure will require a replacement of the unit. Copyright © Connective Peripherals Pte Ltd.

  • Page 32: Import / Export Information

    Import / Export Information Country of Origin China Harmonized 8471-80-1000 Code Product USB to RS422 Development Module, Single/Dual/Quad/Eight/Sixteen COM Port Description USA ECCN EAR99 No License Required Table 8.1 - Import / Export Information Copyright © Connective Peripherals Pte Ltd.

  • Page 33: Troubleshooting

    RTS- to CTS-. Use a simple terminal program to check that data is transmitted and received. Device Driver Ensure the latest device driver is in use. For instructions on how to remove and re-install the latest driver, refer to the Connective Peripherals USB to Serial Converters Driver Installation Guide (CP_000084) which is available from www.connectiveperipherals.com If other devices with FTDI chips are installed in the system, check with all manufacturers of these devices for the latest device drivers.

  • Page 34: Technical Support

    If the higher COM port assignments are not acceptable for the application, known unused COM port numbers can be uninstalled as shown in the Connective Peripherals USB to Serial Converters Driver Installation Guide (CP_000084) which is available from www.connectiveperipherals.com...

  • Page 35: Contact Information

    Contact Information Global Headquarters Singapore Connective Peripherals Pte Ltd 1 Tai Seng Avenue, Tower A #03-05 Singapore 536464 Tel: +65 67430980 E-Mail (Sales) sales@connectiveperipherals.com E-Mail (Support) support@connectiveperipherals.com Web Site URL http://www.connectiveperipherals.com Web Shop URL http://www.connectiveperipherals.com Copyright © Connective Peripherals Pte Ltd.

  • Page 36: Appendix A List Of Figures And Tables

    Table 3.4 USB2-H-6002-M Terminal Block interface............... 17 Table 4.1 Bias and Termination Resistor Numbers of Each Module ........... 21 Table 5.1 - USB Electrical Details ....................22 Table 5.2 - 5V Power Adapter Electrical Details ................22 Copyright © Connective Peripherals Pte Ltd.
  • Page 37 Table 5.3 - RS422 Electrical Details ....................22 Table 5.4 RS422 Electrical Details ....................23 Table 6.1 - Storage Temperature ....................24 Table 6.2 - Operating Temperature ....................24 Table 8.1 - Import / Export Information ..................32 Copyright © Connective Peripherals Pte Ltd.

  • Page 38: Appendix B Revision History
