Killbros 1135 Manual

Corner auger grain cart
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Grain Handling
CORNER AUGER GRAIN CART
MODEL 1135
Serial Number B36620100 & Up
D72360100 & Up
Part No. 287969

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1135 and is the answer not in the manual?

Questions and answers

Related Manuals for Killbros 1135

Summary of Contents for Killbros 1135

  • Page 1 Grain Handling CORNER AUGER GRAIN CART MODEL 1135 Serial Number B36620100 & Up D72360100 & Up Part No. 287969...
  • Page 2 — Introduction Killbros 1135 Foreword This symbol identifies important safety messages. When you see it, read the message that follows and be alert to the possibility of personal injury. Remember, safety instructions stated in this manual are for your protection. Read them care- fully and follow them closely when working around or using this machine.
  • Page 3 — Introduction Killbros 1135 Product Information When ordering parts or when requesting further information or assistance, always give the following information: • Machine name • Model number • Serial number All products manufactured by Unverferth Mfg. Co., Inc. are warranted to be free from ma- terial and workmanship defects for one full year from the time of consumer delivery.

  • Page 4: Table Of Contents

    — Introduction Killbros 1135 Table of Contents Section I Safety General Hazard Information ..................1-2 Safety Decals ......................1-3 Following Safety Instructions .................. 1-5 Before Servicing or Operating ................1-6 During Operation....................... 1-6 Before Transporting ....................1-7 During Transport ....................... 1-7 Driveline Safety ......................
  • Page 5 — Introduction Killbros 1135 Table of Contents Section II Set Up Set Up Checklist ...................... 2-2 Basic Set Up ......................2-3 SMV Emblem and SIS Decals ................2-4 Auger Rest Retainer Removal ................2-4 Auger Rotational Spout Stop Removal ............2-5 Sideboard and End Caps ..................
  • Page 6 — Introduction Killbros 1135 Table of Contents Section III Operation Operating Checklist ....................3-2 Preparing Tractor ...................... 3-3 Preparing Cart Hardware ......................3-4 Pivot Pins ......................3-4 Hitch ........................3-4 Auger ........................3-4 Auger Driveline Assembly .................. 3-5 Soft Start System ....................3-6 Hydraulic System ....................
  • Page 7 — Introduction Killbros 1135 Table of Contents Section IV Maintenance Lubrication ......................... 4-2 Gearbox Lubrication ....................4-4 Hydraulic System ...................... 4-4 Purge Hydraulic System ..................4-5 Relieving Hydraulic Pressure ................4-6 Auger System ......................4-6 Lower Auger Disassembly.................. 4-7 Lower Auger Replacement With Double Lobe Drive Dog ......4-7 Lower Auger Replacement With Single Lobe Drive Dog ......
  • Page 8 — Introduction Killbros 1135 Table of Contents Section V Parts Decals ........................5-2 Final Assembly .....................5-4 Touch-Up Paint ....................5-5 Sideboards - Serial Number B43450100 & Up ..........5-6 Sideboards - Serial Number B36620100 - B43450099 ........5-8 Rigid Axle - Serial Number D72360100 & Up ..........5-10 Rigid Axle - Serial Number B36620100 - D72360099 ........5-12...
  • Page 9 — Safety Killbros 1135 Section I Safety General Hazard Information ..................1-2 Safety Decals ......................1-3 Following Safety Instructions .................. 1-5 Before Servicing or Operating ................1-6 During Operation....................... 1-6 Before Transporting ....................1-7 During Transport ....................... 1-7 Driveline Safety ......................1-8 Pressurized Oil ......................

  • Page 10: Safety

    — Safety Killbros 1135 General Hazard Information No accident-prevention program can be successful without the wholehearted cooperation of the person who is directly responsible for the operation of the equipment. A large number of accidents can be prevented only by the operator anticipating the result before the accident is caused and doing something about it.

  • Page 11: Safety Decals

    — Safety Killbros 1135 Safety Decals • Replace lost, damaged, painted, oR unReadable decals immediately. if paRts that have decals aRe Replaced, also make suRe to install new DECALS. THESE DECALS INFORM AND REMIND THE OPERATOR WITH OPERATIONAL infoRmation and safety messages.
  • Page 12 — Safety Killbros 1135 Safety Decals (continued) Amber Reflector 9003127 9003125 Fluorescent Strip 9003126 Red Reflector 95046 SIS 20 MPH 9008714 TA510514 SIS 30 KPH 9008720 95046 93459 Always consult your operator’s manual for correct tire VENDOR: CREATIVE SCREEN PRINT...

  • Page 13: Following Safety Instructions

    — Safety Killbros 1135 Following Safety Instructions • Read and understand this operator’s manual before operating. • All machinery should be operated only by trained and authorized personnel. • To prevent machine damage, use only attachments and service parts approved by the manufac- turer.

  • Page 14: Before Servicing Or Operating

    — Safety Killbros 1135 Before Servicing or Operating • Avoid working under an implement; however, if it becomes absolutely unavoidable, make sure the implement is safely blocked. • Ensure that all applicable safety decals are installed and legible. • When working around the implement, be careful not to be cut by sharp edges.

  • Page 15: Before Transporting

    — Safety Killbros 1135 Before Transporting • Secure transport chains to towing vehicle before transporting. DO NOT transport without chains. • Check for proper function of all available transport lights. Make sure that all reflectors are clean and in place on machine. Make sure that the SMV emblem and SIS decal are visible to approaching traffic.

  • Page 16: Driveline Safety

    — Safety Killbros 1135 Driveline Safety • Do not allow children near equipment that is running or engaged. • Do not exceed 1000 rpm PTO speed. • Disengage the PTO, stop the tractor engine, and remove key from ignition before making inspec- tions, or performing maintenance and repairs.

  • Page 17: Pressurized Oil

    — Safety Killbros 1135 Pressurized Oil • Relieve the hydraulic system of all pressure before adjusting or servicing. See hydraulic power unit manual for procedure to relieve pressure. • High-pressure fluids can penetrate the skin and cause serious injury or death. Leaks of high-pressure fluids may not be visible.

  • Page 18: Preparing For Emergencies

    — Safety Killbros 1135 Preparing for Emergencies • Keep a first aid kit and properly rated fire extinguisher nearby. • Keep emergency numbers for fire, rescue, and poison control personnel near the phone. Wearing Protective Equipment • Wear clothing and personal protective equipment appropriate for the job.

  • Page 19: Set Up

    — Set Up Killbros 1135 Section II Set Up Set Up Checklist ...................... 2-2 Basic Set Up ......................2-3 SMV Emblem and SIS Decals ................2-4 Auger Rest Retainer Removal ................2-4 Auger Rotational Spout Stop Removal ............2-5 Sideboard and End Caps .................. 2-6 Tarp Installation ....................

  • Page 20: Set Up Checklist

    — Set Up Killbros 1135 Set Up Checklist After the cart has been completely assembled, use the following checklist and inspect the cart. Check off each item as it is found satisfactory or after proper adjustment is made.  Adjust axle from shipping position to desired operating position. (If applicable) Refer to “Adjustable Axle (Optional)”.

  • Page 21: Basic Set Up

    — Set Up Killbros 1135 Basic Set Up Tractor Electrical & Hydraulic Hook-Up Spout Jack “Transport Position” Jack “Parked Position” Due to shipping requirements and various dealer-installed options, some initial cart set up will be required after it arrives from the factory. Use the following procedures as needed for initial cart set up.

  • Page 22: Smv Emblem And Sis Decals

    — Set Up Killbros 1135 Basic Set Up SMV Emblem & SIS Decals The reflective surface of the SMV must face rearward. This may require removal of film pro- fig. 2-1 tecting the reflective surface or removing and reinstallation of the SMV. (FIG. 2-1)

  • Page 23: Auger Rotational Spout Stop Removal

    — Set Up Killbros 1135 Basic Set Up (continued) Auger Rotational Spout Stop Removal Remove the stop on the rotational spout bracket at the rear of the cart, before operating the fig. 2-5 spout. (FIG. 2-5) • Shipping stop must be removed before op- erating the auger spout.

  • Page 24: Sideboard And End Caps

    — Set Up Killbros 1135 Basic Set Up (continued) Sideboards and End Caps 1. Park the empty cart on a firm, level surface. Block the tires on the machine to keep it from moving. Set the tractor’s parking brake, shut off the engine, and remove the ignition key.
  • Page 25 — Set Up Killbros 1135 Basic Set Up (continued) 5. Lift the left-hand sideboard into position. NOTE: Hinge brackets WILL support the sideboard and tarp if included. NOTE: On some models, shocks are attached fig. 2-10 to the left-hand sideboard, FIG 2-10.
  • Page 26 — Set Up Killbros 1135 Basic Set Up (continued) 7. Install brace tubes. Install The Sideboard ONE PIECE BRACE TUBE: Brace Tube Install sideboard brace tubes on each cross tube weldment. Each weldment will have one left-hand and one right-hand sideboard brace tube.
  • Page 27 — Set Up Killbros 1135 Basic Set Up (continued) 8. If included, remove and discard the shocks and associated brackets from the left-hand sideboard. 9. Lift the large rear sideboard up into position and loosely secure with 3/8” flange screws and flange nuts along the bottom.
  • Page 28 — Set Up Killbros 1135 Basic Set Up (continued) 11. If included, remove and discard the shipping bracket from the small rear panel. 12. Connect the large rear sideboard to the left-hand sideboard using the small rear panel. Loosely secure using 3/8” hardware. See FIG. 2-15.
  • Page 29 — Set Up Killbros 1135 Basic Set Up (continued) 13. Attach smaller end cap on top of rear side- Small boards using 3/8” hardware and one 1/4” self- 1/4” Self- End Cap drilling screw. See FIG. 2-16. Drilling Screw NOTE: The small end cap tab will fit underneath the large end cap.
  • Page 30 — Set Up Killbros 1135 Basic Set Up (continued) 15. Remove and discard the shipping bracket from the front sideboard. 16. Lift large front sideboard into position and loosely secure with 3/8” flange screws and flange nuts along the bottom. See FIG. 2-18.

  • Page 31: Tarp Installation

    — Set Up Killbros 1135 Basic Set Up (continued) Tarp Installation NOTE: For carts SN B41380099 & lower, skip to step 2 on next page. NOTE: Ensure RH and LH doublers are inside the sideboard lip. See FIG. 2-20. 1. For carts SN B41380100 & Up / D72360100 & Up, install six long tarp bows (287400B) across top of the cart, using bracket (283425B), RH doubler (289986B), LH doubler (281936B), 3/8”-16UNC x...
  • Page 32 — Set Up Killbros 1135 Basic Set Up (continued) 2. Install six long tarp bows (287400B) across the top of the cart, using bracket (283425B), 3/8”- 16UNC x 3” capscrew (902703-046), 3/8”-16UNC (91263), 5/16”-18UNC x 3/4” flange screw (91256) and 5/16”-18UNC flange nut (91257). See FIG. 2-21 and 2-22.
  • Page 33 — Set Up Killbros 1135 Basic Set Up (continued) NOTE: Ensure capscrew head (902703-046) is flush with the top of bow weldment (287400B). Capscrew See FIG. 2-23. (902703-046) 3. Tighten all hardware. Tarp Bow (287400B) fig. 2-23 2-15...
  • Page 34 — Set Up Killbros 1135 Basic Set Up (continued) 4. Install four tarp cables across the top Attach Tarp Cables using 3/8”-16UNC 1/2” capscrew Capscrew (TA0-907131-0), 3/8” lock washer (9005688), (TA0-907131-0) 3/8” fender washer (9005696) and bracket & U- nut assembly (281712B). See FIG. 2-24 through Lock 2-27.
  • Page 35 — Set Up Killbros 1135 Basic Set Up (continued) 6. Install end cap extension (283431B) between End Cap Extension the end cap and right-hand sideboard on both (283431B) the front and rear of cart. Retain in place using two 3/8”-16 x 1” carriage bolts (9388-051), two 3/8”-16 flange nuts (91263) and one 1/4”-14 x...
  • Page 36 — Set Up Killbros 1135 Basic Set Up (continued) 8. Attach the crank handle to the tarp roll tube, fig. 2-31 FIG. 2-31. Once secure, roll tarp across the cart to the closed position. Attach to Tube Crank Handle 9. Confirm that the roll tube on the handle is at a fig.
  • Page 37 — Set Up Killbros 1135 Basic Set Up (continued) 11. Add #10-16 x 3/4” self-drilling screws (9005197) fig. 2-33 and U-clamps (9004949) to secure tarp in place on the roll tube side. Check that clips are lo- cated on the straps with an even height across, FIG.

  • Page 38: Warning Lamp Set Up

    — Set Up Killbros 1135 Basic Set Up (continued) Warning Lamp Set Up 1. Pivot warning lamp to widest setting. 2. Adjust warning lamp brackets so that the REFLECTORS are not more than 16” from the outer edge of the tire.

  • Page 39: Driveline Storage

    — Set Up Killbros 1135 Basic Set Up (continued) Driveline Storage Storage brackets are located on the inside right frame rail. Secure the PTO shaft to these brackets for extended transporting or seasonal storage. • Remove and store the complete PTO before towing grain cart. Interference could occur resulting in damage to PTO and cart.

  • Page 40: Wheel/Tire Set Up

    — Set Up Killbros 1135 Basic Set Up (continued) Wheel/Tire Set Up Tire Pressure Tire pressure must be verified before first use and adjusted as necessary. Refer to MAINTENANCE section of this manual for information on tire pressure. Wheel Nuts •...

  • Page 41: Adjustable Axle (Optional)

    — Set Up Killbros 1135 Basic Set Up (continued) Adjustable Axle (Optional) • falling obJects can cause seRious inJuRy oR death. do not woRk undeR the machine at any time while being hoisted. be suRe all lifting devices and suppoRts aRe Rated foR the loads being hoisted. these assembly instRuctions will ReQuiRe safe lifting devices up to 16,000 lbs.
  • Page 42 — Set Up Killbros 1135 Basic Set Up (continued) Adjustable Axle (Optional) (continued) 4. Slide extensions to desired tire gauge spacing. Axle extensions should be extended equally. Refer to chart below and FIG. 2-40. Slide Out Distance Distance Hub Flange...

  • Page 43: For Track Information, Please Refer To Your Track Manual

    — Operation Killbros 1135 Section III Operation Operating Checklist ....................3-2 Preparing Tractor ...................... 3-3 Preparing Cart Hardware ......................3-4 Pivot Pins ......................3-4 Hitch ........................3-4 Auger ........................3-4 Auger Driveline Assembly .................. 3-5 Soft Start System ....................3-6 Hydraulic System ....................

  • Page 44: Operating Checklist

    — Operation Killbros 1135 Operating Checklist  Read and understand all safety precautions before operating cart.  Check axle spacing to be sure axle is adjusted from shipping position to desired operating width. (If applicable)  Set or Calibrate tractor PTO control engagement to MINIMUM setting. Refer to tractor operator’s manual for setting information.

  • Page 45: Preparing Tractor

    — Operation Killbros 1135 Preparing Tractor Before operating cart, read the tractor Operator’s Manual and gain an understanding of its safe methods of operation. Check the tractor brakes and transport lights. Make sure they are in proper working order. Set tractor PTO modulation to MINIMUM. Check that your tractor has the latest PTO engagement software from the OEM.

  • Page 46: Preparing Cart

    — Operation Killbros 1135 Preparing Cart Perform the service checks as outlined below. Repair or replace any damaged or worn parts before operating. Hardware Check for loose bolts and nuts, and tighten as needed. Check again after the first half-day of operation.

  • Page 47: Auger Driveline Assembly

    — Operation Killbros 1135 Preparing Cart (continued) Auger Driveline Assembly NOTE: Ends of driveshaft are symmetrical. Universal Joint Drill Dimple 1. Slide driveshaft down into the universal joint at- Orientation in Line on Driveshaft tached to the gearbox until the end of the shaft extends into the universal joint about 2 3/8”.

  • Page 48: Soft Start System

    — Operation Killbros 1135 Preparing Cart (continued) Soft Start System Check for wear or damage. Hydraulic System Check all hoses and cylinders for signs of leakage. Hoses should not be kinked, twisted or rubbing against sharp edges. Re-route or repair hoses as necessary. Refer to SAFETY section for additional information on safe repair and inspection of hydraulic components.

  • Page 49: Hitching To Tractor Drawbar Connection

    — Operation Killbros 1135 Hitching to Tractor Drawbar Connection This cart is intended to be hitched to a tractor drawbar. Do not attempt to hitch to any other location on the tractor other than the drawbar. The cart is equipped standard with a single tang hitch.

  • Page 50: Jack Usage

    — Operation Killbros 1135 Hitching to Tractor (continued) Jack Usage • unhitching a loaded caRt can cause seRious inJuRy oR death due to the tongue Rising oR falling. always have a loaded caRt attached to a tRactoR. the Jack is intended to suppoRt an empty caRt only.

  • Page 51: Transport Chain Connection

    — Operation Killbros 1135 Hitching to Tractor (continued) Transport Chain Connection • always use tRanspoRt chain when tRanspoRting implements. failuRe to use a tRanspoRt chain could cause peRsonal inJuRy if caRt becomes disengaged. • Replace tRanspoRt chain if any link oR end fitting is bRoken, stRetched, damaged.

  • Page 52: Hydraulic Connections For Hydraulic Drive

    — Operation Killbros 1135 Hitching to Tractor (continued) Clean hydraulic hose couplers before connecting to the tractor. For convenience, it is recom- mended to connect the flow door circuit hoses to tractor implement coupler #1, auger spout circuit hoses to coupler #2, and attach auger fold circuit to coupler #3.

  • Page 53: Electrical Connections

    — Operation Killbros 1135 Hitching to Tractor (continued) Electrical Connections This cart is equipped with a seven-pin SAE con- nector plug which will connect with the receptacle found on most newer tractors. If your tractor does not have this type of receptacle, an SAE J-560 seven-point socket can be purchased from your Unverferth dealer (Part number 92824).

  • Page 54: Towing

    — Operation Killbros 1135 Hitching to Tractor (continued) Towing Ensure that the towing vehicle has adequate weight and braking capacity to tow this implement and all attachments. See your Unverferth dealer for more information. See towing vehicle’s operators manual for towing capacity. Never tow a loaded grain cart over public roads.

  • Page 55: Pto Chain

    — Operation Killbros 1135 Hitching to Tractor (continued) PTO Chain NOTE: PTO chain is intended to prevent the shield from rotating against non-moving parts and there- by preventing shield damage. A properly installed chain will increase the service life of the shield.

  • Page 56: Auger Operation Pto-Driven Auger

    — Operation Killbros 1135 Auger Operation PTO Driven Auger • electRocution will cause seRious inJuRy oR death. elec- tRocution can occuR without diRect contact. keep away FROM ALL ELECTRICAL LINES AND DEVICES. • entanglement with the dRiveline will cause seRious inJuRy oR death.

  • Page 57: Hydraulic Drive (Optional)

    — Operation Killbros 1135 Auger Operation (continued) PTO Driven Auger (continued) fig. 3-16 5. To slow or stop grain flow, close flow door, DO NOT reduce tractor/PTO RPM as a means to control grain flow. Close flow door fully when unloading is complete.
  • Page 58 — Operation Killbros 1135 Hydraulic Drive (Optional) (continued) NOTE: For complete assembly and operation details for the Hydraulic Drive, please refer to the Hydraulic Drive manual (282894). 1. Before loading cart or operating auger, verify that the flow control door is closed.

  • Page 59: Weather Guard Tarp

    — Operation Killbros 1135 Weather Guard Tarp • to pRevent peRsonal inJuRy oR death while seRvicing, do not allow any- one on a closed taRp. taRp system is not designed to suppoRt a peRson. • falling obJects can cause seRious inJuRy oR death. Remove accumulated wateR/snow/ice oR any otheR obJects fRom taRp befoRe opening taRp.
  • Page 60 — Operation Killbros 1135 Weather Guard Tarp (continued) Procedure 1. Using both hands, carefully remove tarp handle from the tube holder. 2. Roll tarp to the desired location, choosing either a fully open or fully closed position. 3. To close the tarp, rotate the roll tube clockwise up under the latch plate.

  • Page 61: For Track Information, Please Refer To Your Track Manual

    — Maintenance Killbros 1135 Section IV Maintenance Lubrication ......................... 4-2 Gearbox Lubrication ....................4-4 Hydraulic System ...................... 4-4 Purge Hydraulic System ..................4-5 Relieving Hydraulic Pressure ................4-6 Auger System ......................4-6 Lower Auger Disassembly.................. 4-7 Lower Auger Replacement With Double Lobe Drive Dog ......4-7 Lower Auger Replacement With Single Lobe Drive Dog ......

  • Page 62: Lubrication

    — Maintenance Killbros 1135 Lubrication To keep your grain cart in top operating condition and to assure its proper performance and reliability for a long period of time, periodic inspection and lubrication is a must. 1 SHOT GREASE WEEKLY SEE CHART...
  • Page 63 — Maintenance Killbros 1135 Lubrication (continued) To keep your grain cart in top operating condition and to assure its proper performance and reliability for a long period of time, periodic inspection and lubrication is a must. Unverferth Mfg. recommends use of NLGI #2 Extreme Pressure grease.

  • Page 64: Gearbox Lubrication

    — Maintenance Killbros 1135 Gearbox Lubrication The fill plug is located on the right-hand front fig. 4-1 side of the housing. To check oil fluid level, place cart on a level surface with the tongue elevated to hitch height and remove the plug. Oil level should be at the bottom thread or approximately 5/8”...

  • Page 65: Purge Hydraulic System

    — Maintenance Killbros 1135 Hydraulic System (continued) Purge Hydraulic System • hydRaulic system must be puRged of aiR befoRe opeRating to pRevent SERIOUS INJURY OR DEATH. • Relieve hydRaulic system of all pRessuRe befoRe adJusting oR seRvicing. SEE THE HYDRAULIC POWER UNIT OPERATOR’S MANUAL FOR PROPER PROCE- DURES.

  • Page 66: Relieving Hydraulic Pressure

    — Maintenance Killbros 1135 Hydraulic System (continued) Relieving Hydraulic Pressure To relieve hydraulic pressure in the system, be sure hydraulic motor is disengaged and/or hydraulic cylinder is not exerting force on the system. Next, consult tractor operators manual for procedure to relieve pressure.

  • Page 67: Lower Auger Disassembly

    — Maintenance Killbros 1135 Auger System (continued) Lower Auger Disassembly 1. Park the empty cart on a firm, level surface. Block the wheels or tracks on the cart to keep Capscrew (9390-056), Flat Washers (9405-076), it from moving. Set the tractor parking brake,...
  • Page 68 — Maintenance Killbros 1135 Auger System (continued) Lower Auger Replacement With Double Lobe Drive Dog (continued) 7. Align auger end with the five pin drive bush- ing and securely engage together, see FIG. 4-5 fig. 4-5 and 4-6. Secure hanger bearing to auger hous- ing tube wall with original three 3/8”-16UNC x...

  • Page 69: Lower Auger Replacement With Single Lobe Drive Dog

    — Maintenance Killbros 1135 Auger System (continued) Lower Auger Replacement With Double Lobe Drive Dog (continued) 10. Perform a final inspection of auger and lower collector box to ensure all debris and tools have been removed. Close the clean-out door completely and lock the position. Connect PTO to tractor.
  • Page 70 — Maintenance Killbros 1135 Auger System (continued) Lower Auger Replacement With Single Lobe Drive Dog (continued) 8. Align auger end with the five pin drive bushing and securely engage together, see FIG. 4-9 and fig. 4-9 4-10. Secure hanger bearing to auger hous- ing tube wall with original three 3/8”-16UNC x...

  • Page 71: Upper Auger Disassembly

    — Maintenance Killbros 1135 Auger System (continued) Upper Auger Disassembly 1. Park the empty cart on a firm, level surface. Block the wheels or tracks on the cart to keep it from moving. Set the tractor parking brake, shut off the engine, and remove the ignition key from the tractor before disconnecting driveline assembly and bearing hardware.

  • Page 72: Upper Auger Assembly

    — Maintenance Killbros 1135 Auger System (continued) Upper Auger Assembly 1. Install upper bearing and spring assembly if previously removed. 2. Insert auger in auger tube. Back out bearing setscrews and insert auger stub shaft through bear- ing. Retain auger with 5/16” x 2” machine screw and nut.

  • Page 73: Auger Flow Door Cylinder Replacement

    — Maintenance Killbros 1135 Auger System (continued) Auger Flow Door Cylinder Replacement • to pRevent peRsonal inJuRy oR death, always ensuRe that theRe aRe people who Remain outside the caRt to assist the peRson woRking in- side, and that all safe woRkplace pRactices aRe followed. theRe aRe RestRicted mobility and limited eXit paths when woRking inside the IMPLEMENT.
  • Page 74 — Maintenance Killbros 1135 Auger System (continued) Auger Flow Door Cylinder Replacement (continued) 2. On the inside of the cart, open the screen ser- fig. 4-15 vice access panel shown in FIG. 4-15. Screen Service Access Panel 3. Remove the cotter pins from the lower cylinder pin then remove the pin.
  • Page 75 — Maintenance Killbros 1135 Auger System (continued) Auger Flow Door Cylinder Replacement (continued) 6. Label the hydraulic hoses to indicate upper and lower. Disconnect them from the cylin- Remove Lower der, along with the lower hydraulic fitting (FIG. Hose & Fitting 4-17).

  • Page 76: Auger Driveline

    — Maintenance Killbros 1135 Auger Driveline Bearings It is important to periodically check set screws in all bearings at either end of the driveline for tightness. Gearbox Fluid level/fill plug is in front of the axle on the right Oil level should be at the bottom of...
  • Page 77 — Maintenance Killbros 1135 Auger Driveline (continued) 4. Remove paint on driveshaft to allow for easier movement. Slide driveshaft forward until the rear spline is out of the universal joint connect- ed to the gearbox. 5. Drop the gearbox end of driveshaft down and slide driveshaft out of the flangette bearing on the hitch end of the driveshaft.
  • Page 78 — Maintenance Killbros 1135 Auger Driveline (continued) U-Joint Quick Disconnect Pin (continued) fig. 4-25 10 Insert quick disconnect pin, compression spring and washer into U-joint pin hole. (FIG. 4-25) 11. Holding the washer in place, peen the edges of the bore seat to retain the washer, spring and pin.
  • Page 79 — Maintenance Killbros 1135 Auger Driveline (continued) Driveline Replacement (continued) 15. Slide new two-piece 1 1/2” dia. shaft collars (9008671) to both sides of new bearing (9003920) closest to the U-Joint, when installing bearings onto new driveshaft (Kit 289771). 16. Assemble new PVC driveshaft cover (291558) behind new bearing (9003920) closest to the U-Joint.
  • Page 80 — Maintenance Killbros 1135 Auger Driveline (continued) Driveline Replacement (continued) 20. Tighten all flangette mounting hardware. Universal Joint NOTE: The driveshaft has a dimple to aid in Drill Dimple Orientation in Line aligning the yokes on both ends of the drive- on Driveshaft line.

  • Page 81: Wheel, Hub And Spindle Disassembly And Assembly

    — Maintenance Killbros 1135 Wheel, Hub and Spindle Disassembly and Assembly • tipping oR movement of the machine can cause seRious inJuRy oR death. be suRe machine is secuRely blocked. • falling obJects can cause seRious inJuRy oR death. do not woRk undeR the machine at any time while being hoisted.
  • Page 82 — Maintenance Killbros 1135 Wheel, Hub and Spindle Disassembly and Assembly (continued) 5. Inspect the spindle and replace if necessary. If spindle does not need to be replaced, skip to Step 6; otherwise continue with Step 5. Remove the bolt and lock nut that retains the spindle to the axle. Using a safe lifting device rated for 200 lbs, replace the old spindle with a new spindle.

  • Page 83: Wheels And Tires

    — Maintenance Killbros 1135 Wheels and Tires Wheel Nut Torque Requirements • impRopeRly toRQued wheel nuts/bolts can cause a loss of implement contRol and machine damage. toRQue wheel nuts/bolts to values in table. check toRQue befoRe use, afteR one houR of unloaded use oR afteR fiRst load, and each load until wheel nuts/bolts maintain toRQue value.

  • Page 84: Tire Pressure

    — Maintenance Killbros 1135 Wheels and Tires (continued) Tire Pressure The following is to be used as a general guide for tire inflation and figures can vary depending on specific brand of tire used. It is important that tires are inspected after unit is loaded.
  • Page 85 — Maintenance Killbros 1135 Wheels and Tires (continued) Tire Pressure (continued) Tire Pressure for Grain Carts Load Index / Ply Max. PSI Tire Make Part Number Tire Size Rating Titan/Goodyear 94286 23.1x26 R-3 99364 23.1x26 R-1 99307 24.5R32 R-1 169A8/B (5-Star) 94289 24.5x32 R-3...

  • Page 86: Tire Warranty

    — Maintenance Killbros 1135 Wheels and Tires (continued) Tire Warranty For questions regarding new tire warranty, please contact your local original equipment tire USED TIRES CARRY NO WARRANTY. dealer. Following are phone numbers and Websites for your convenience: Firestone www.firestoneag.com...
  • Page 87 — Maintenance Killbros 1135 Verify Telescoping PTO Shaft Length - GKN Walterscheid PTO • pRopeRly eXtended and collapsed lengths of the telescoping pto shaft must be veRified befoRe fiRst opeRation with each and eveRy diffeRent tRactoR. if the eXtended length of the pto shaft is not sufficient, it...

  • Page 88: Verify Telescoping Pto Shaft Length

    — Maintenance Killbros 1135 Verify Telescoping PTO Shaft Length - GKN Walterscheid PTO (continued) 3. Calculate maximum recommended extended length: a. Subtract line 1 from line 2. Enter here: b. Divide line (a) by 2. Enter here: c. Add line (b) to line 1. Enter here: d.

  • Page 89: Pto Shaft & Clutch - Benzi Pto

    — Maintenance Killbros 1135 PTO Shaft and Clutch - Benzi PTO Lubrication Lubricate with NLGI grade 2 grease before starting work and every 8 operating hours. Clean and grease PTO drive shaft before each prolonged period of non-use. Molded nipples on the shield near each shield bearing are intended as grease fittings and should be lubricated every 8 hours of operation! Check and grease the guard tubes in winter to prevent freezing.
  • Page 90 — Maintenance Killbros 1135 PTO Shaft and Clutch - Benzi PTO (continued) Shear-Bolt and Friction Clutches (Figs. H1 - H3) 1. Shear bolt clutches: When the set torque value is exceeded, power flow is interrupted due to the bolt shearing.
  • Page 91 — Maintenance Killbros 1135 PTO Shaft and Clutch - Benzi PTO (continued) To Dismantle Guard (Figs. J1 - J3) 1. Pull the guard tube backwards and, using a screwdriver, disengage the three bearing ring tabs by pushing them inward. (FIG. J1) 2.
  • Page 92 — Maintenance Killbros 1135 PTO Shaft and Clutch - Benzi PTO (continued) To Assemble Guard (Figs. K1 - K3) 1. Clean and grease the bearing ring, yoke groove and inner profile tube. (FIG. K1) 2. Fit bearing ring in groove with three bearing ring tabs positioned as shown.
  • Page 93 — Maintenance Killbros 1135 PTO Locking Systems - Benzi PTO Ball-Type Collar Coupling Slide clamp yoke or clutch onto connecting shaft. Pull in the coupler collar to release the balls and simultaneously push PTO driveshaft into the connecting shaft until the coupler collar locks onto the connecting shaft annular grooves.

  • Page 94: Pto Shaft & Clutch - Gkn Walterscheid Pto

    — Maintenance Killbros 1135 PTO Shaft and Clutch - GKN Walterscheid PTO Lubrication (Figs. D1 - D6) Lubricate with quality grease before starting work and every 8 operating hours. Clean and grease PTO driveshaft before each prolonged period of non-use.
  • Page 95 — Maintenance Killbros 1135 PTO Shaft and Clutch - GKN Walterscheid PTO (continued) Coupling the PTO driveshaft (Figs. E1 - E2) Clean and grease the PTO and implement input connection (IIC) AS-Lock 1. Pull locking collar and simultaneously push PTO driveshaft onto PTO shaft until the locking device engages.
  • Page 96 — Maintenance Killbros 1135 PTO Shaft and Clutch - GKN Walterscheid PTO (continued) Chains (Figs. G1 - G3) NOTE: The chain is intended to prevent the shield from rotating against non-moving parts and there- by preventing shield damage. A properly installed chain will increase the service life of the shield.
  • Page 97 — Maintenance Killbros 1135 PTO Shaft and Clutch - GKN Walterscheid PTO (continued) To Dismantle Guard (Figs. J1 - J4) 1. Remove locking screw. 2. Align bearing tabs with cone pockets. 3. Remove half-guard. 4. Remove bearing ring. To Assemble Guard (Figs. K1 - K5) 1.
  • Page 98 — Maintenance Killbros 1135 PTO Shaft and Clutch - GKN Walterscheid PTO (continued) To Assemble Cone (Figs. L1 - L3) 1. Dismantle guard (Figs. J1 - J3). Remove old cone (e.g. cut open with knife). Take off chain. Place neck of new cone in hot water (approx 80°...
  • Page 99 — Maintenance Killbros 1135 PTO Quick Disconnect - GKN Walterscheid PTO (continued) Quick Disconnect Disassembly 1. Compression Spring 2. Ball 3. Lock Collar 4. Back-up ring 5. Snap ring * Back-up ring * (For some clutch types, place additional back up ring first).
  • Page 100 — Maintenance Killbros 1135 PTO Quick Disconnect - GKN Walterscheid PTO (continued) Clutch Disassembly Tighten the four hex nuts (12) uniformly until the clutch pack and hub are loose. Use special tool 9002007 to bend all four retaining lugs back on the edge of the clutch housing. Remove the thrust plate with Belleville springs to get at the friction disks, drive plates and hub for inspection and service.

  • Page 101: Seasonal Storage

    — Maintenance Killbros 1135 Seasonal Storage Your cart is an important investment. Spend a little time to protect it from destructive rust and corrosion, You will be repaid in longer service life and better performance. Do the following before placing the cart in storage: fig.

  • Page 102: Adjusting Cleanout Door

    — Maintenance Killbros 1135 Adjusting Cleanout Door • moving paRts can cRush and cut. keep away fRom moving paRts. • keep hands cleaR of pinch point aReas. • eye pRotection and otheR appRopRiate peRsonal pRotective eQuipment must be woRn while seRvicing the implement.
  • Page 103 — Maintenance Killbros 1135 Adjusting Cleanout Door (continued) 5. Push the gear assembly toward bottom of au- ger to remove excess movement and prevent Push Gear Assembly the door from moving upward when unloading Toward Bottom of Auger the cart. (FIG. 4-35) fig.

  • Page 104: Tarp Troubleshooting Inspection & Maintenance

    — Maintenance Killbros 1135 Tarp Troubleshooting Inspection & Maintenance PROBLEM SOLUTION TARP SAGS IN MIDDLE AREAS BOwS MAY BE BENT OR ADjUSTED TOO MISSING OR LOOSE RIDGE STRAP REPLACE OR RETIGHTEN TENSION MAY BE TOO LOOSE. U-jOINT MAY NEED TO BE ADjUSTED ON SPLINED SHAFT...
  • Page 105 — Maintenance Killbros 1135 Electrical System Diagram — Overall Right-Hand To Right-Side of Side Cart Interior Tail Light RH Sub Assembly #280848B Work Light #9008957 Red Tail/Turn Light #9006282 Rear Wiring Harness #9003050 To Tractor Front Wiring Harness #9007460 Tail Light...
  • Page 106 — Maintenance Killbros 1135 Electrical System Diagram — Plug #92450 GRAIN CART wIRES White -- Ground Green -- Right amber flashing lamp Yellow -- Left amber flashing lamp Brown -- Tail light Black -- Interior & Auger Lights Red -- Brake Lights...
  • Page 107 — Maintenance Killbros 1135 Electrical Diagram — Front Wiring Harness #9007460 4-47...
  • Page 108 — Maintenance Killbros 1135 Electrical Diagram — Rear Wiring Harness #9003050 4-48...
  • Page 109 — Maintenance Killbros 1135 Electrical Diagram — Auger Wiring Harness #9009080 - Serial Number B41380100 & Up #9007461 - Serial Number B41380099 & Lower 4-49...
  • Page 110 — Maintenance Killbros 1135 Electrical Diagram — Proximity Sensor #9007472 Electrical Diagram — Work Light #9008957 Serial Number B41380100 & Up 2 PIN INTEGRATED DEUTSCH CONNECTOR POWER (PIN #1) GROUND (PIN #2) Electrical Diagram — Work Light #9007186 Serial Number B41380099 & Lower...
  • Page 111 — Maintenance Killbros 1135 Electrical Diagram — Red Tail/Turn Light #9006282 Electrical Diagram — Amber Lamp Double Face #9005142 4-51...
  • Page 112 — Maintenance Killbros 1135 Hydraulic System Diagram 4-52...
  • Page 113 — Maintenance Killbros 1135 Complete Torque Chart Capscrews - Grade 5 NOTE: • Grade 5 capscrews can be identified by three radial dashes on the head. • For wheel torque requirements, refer to Wheels and Tires. • Tighten U-bolts evenly and equally to have the same number of threads exposed on each end.
  • Page 114 — Maintenance Killbros 1135 Complete Torque Chart Capscrews - Grade 8 NOTE: • Grade 8 capscrews can be identified by six radial dashes on the head. • For wheel torque requirements, refer to Wheels and Tires. • Tighten U-bolts evenly and equally to have the same number of threads exposed on each end.

  • Page 115: Hydraulic Fittings - Torque And Installation

    — Maintenance Killbros 1135 Hydraulic Fittings – Torque and Installation Tightening O-Ring Fittings 1. Inspect components damage O-Ring fittings contamination. Do not connect any other type of fitting to an O-ring fitting. 2. For adjustable fittings, insure the jam nut and washer are fully backed up.
  • Page 116 — Maintenance Killbros 1135 Hydraulic Fittings – Torque and Installation Tightening JIC Fittings 1. Inspect all components for damage or con- tamination. Do not connect any other type of JIC fittings fitting to a JIC fitting. 2. Lubricate the threads.

  • Page 117: For Track Information, Please Refer To Your Track Manual

    — Parts Killbros 1135 Section V Parts Decals ........................5-2 Final Assembly .....................5-4 Touch-Up Paint ....................5-5 Sideboards - Serial Number B43450100 & Up ..........5-6 Sideboards - Serial Number B36620100 - B43450099 ........5-8 Rigid Axle - Serial Number D72360100 & Up ..........5-10 Rigid Axle - Serial Number B36620100 - D72360099 ........5-12...

  • Page 118: Decals

    — Parts Killbros 1135 Decals Please visit www.unverferth.com/parts/ for the most current parts listing. 97961 94094 95445...
  • Page 119 Decal, FEMA 91605 Decal, KILLBROS Logo 9005266 Decal, Killbros Stripe 9005267 Decal, KILLBROS 9005291 Decal, Stripe 9005293 Decal, KILLBROS (Auger Side) 9005292 Decal, 1135 9007947 Decal, 1135 9007943 Decal, Wheel Products 94754 Decal, CAUTION (Slippery Surface) 95008 Decal, Grease 8 Hours...

  • Page 120: Final Assembly

    — Parts Killbros 1135 Final Assembly Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Bracket, Window Retainer 250461B Ladder Weldment 280600B Ladder Bracket Weldment 280603B Wearshoe - Hitch, CAT 3 281663 Wearshoe - Hitch, CAT 4 281898 Tension Bushing, 2”...

  • Page 121: Touch-Up Paint

    — Parts Killbros 1135 Final Assembly Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Split Tension Bushing, 2” OD x 1 3/4” ID x 2” 9002130 Transport Chain 9003278 O-Ring 9005259 Storage Box...

  • Page 122: Sideboards - Serial Number B43450100 & Up

    — Parts Killbros 1135 Sideboards - Serial Number B43450100 & Up Please visit www.unverferth.com/parts/ for the most current parts listing.
  • Page 123 — Parts Killbros 1135 Sideboards - Serial Number B43450100 & Up Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Angle Tube Brace 220032B Lamp Mount Plate 271574B Tube Brace 59 1/2” Long 287524B Tube Brace 155" Long...

  • Page 124: Sideboards - Serial Number B36620100 - B43450099

    — Parts Killbros 1135 Sideboards - Serial Number B36620100 - B43450099 Please visit www.unverferth.com/parts/ for the most current parts listing.
  • Page 125 — Parts Killbros 1135 Sideboards - Serial Number B36620100 - B43450099 Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Angle Tube Brace 220032B Board Tube Brace 287524B Tube Brace 155" Long 287586B Board Weldment-Front, LH...

  • Page 126: Rigid Axle - Serial Number D72360100 & Up

    — Parts Killbros 1135 Rigid Axle - Serial Number D72360100 & Up Please visit www.unverferth.com/parts/ for the most current parts listing. 5-10...
  • Page 127 — Parts Killbros 1135 Rigid Axle - Serial Number D72360100 & Up Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Includes Items 1, 2A, 3-8 Axle Bundle, 134” Spindle Non-Scale =Black= 2006247B Axle Bundle, 134” Spindle Scale =Black=...

  • Page 128: Rigid Axle - Serial Number B36620100 - D72360099

    — Parts Killbros 1135 Rigid Axle - Serial Number B36620100 - D72360099 Please visit www.unverferth.com/parts/ for the most current parts listing. 5-12...
  • Page 129 — Parts Killbros 1135 Rigid Axle - Serial Number B36620100 - D72360099 Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Includes Items 1, 2A, 3-9 Axle Bundle, 134” Spindle Scale =Black= 287976B Includes Items 1, 2B, 3-9 Axle Bundle, 134”...

  • Page 130: Adjustable Axle

    — Parts Killbros 1135 Adjustable Axle Please visit www.unverferth.com/parts/ for the most current parts listing. Note bending arrow direction. 5-14...
  • Page 131 — Parts Killbros 1135 Adjustable Axle Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Adjustable Axle Bundle, Scale =Black= 280489B Includes Items 1-7, 8A, 9-20 Adjustable Axle Bundle, Non-Scale =Black= 280576B Includes Items 1-7, 8B, 9-20 Pin 1”...

  • Page 132: Track Axle Components With 5 Point Scale System

    — Parts Killbros 1135 Track Axle Components with 5 Point Scale System Please visit www.unverferth.com/parts/ for the most current parts listing. Note bending arrow direction. 5-16...
  • Page 133 — Parts Killbros 1135 Track Axle Components with 5 Point Scale System Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Track Axle Bundle, Scale =Black= 287906B Includes Items 1-5, 6A, 7-10 Includes Items 1-5, 6B, 7-10...

  • Page 134: Hub Components

    — Parts Killbros 1135 Hub Components Please visit www.unverferth.com/parts/ for the most current parts listing. 5-18...
  • Page 135 — Parts Killbros 1135 Hub Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Spindle Scale & Hub Kit =Black= 267280B Includes Items 1, 5, 6, 7B, 8-17 Spindle Non-Scale & Hub Kit =Black=...

  • Page 136: Wheels & Tires

    — Parts Killbros 1135 Wheels & Tires Please visit www.unverferth.com/parts/ for the most current parts listing. • V e r i f y w h e t h e r y o u TIRES have a straight plate For questions regarding new tire...
  • Page 137 — Parts Killbros 1135 Wheels & Tires Please visit www.unverferth.com/parts/ for the most current parts listing. STRAIGHT PLATE WHEELS ITEM DESCRIPTION PART NO. NOTES Wheel & Tire Assembly - Diamond Tread\ 17939WO/9500946 Includes Items 2, 8 & 9 30 x 32 / 900/65R32 R-3...

  • Page 138: Pto Assembly Shearbolt Clutch - Serial Number B41380100 & Up

    — Parts Killbros 1135 PTO Assembly Shearbolt Clutch - Serial Number B41380100 & Up Please visit www.unverferth.com/parts/ for the most current parts listing. 1 3/4-20 Spline Shown 5-22...
  • Page 139 — Parts Killbros 1135 PTO Assembly Shearbolt Clutch - Serial Number B41380100 & Up Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES 1 3/4”-20 Spline PTO Assembly Complete 9008526 Includes Front and Rear Half Assemblies (Benzi America PTO) 1 3/8”-21 Spline (Optional)

  • Page 140: Pto Assembly Shearbolt Clutch - Serial Number B41380099 & Lower

    — Parts Killbros 1135 PTO Assembly Shearbolt Clutch - Serial Number B41380099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. 1 3/4-20 Spline Shown Optional 1 3/8-21 Spline Shown 5-24...
  • Page 141 — Parts Killbros 1135 PTO Assembly Shearbolt Clutch - Serial Number B41380099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES 1 3/4-20 Spline PTO Assembly Complete 9004767 (GKN Walterscheid PTO) 1 3/8-21 Spline (Optional)

  • Page 142: Pto Assembly Friction Clutch - Serial Number B41380100 & Up

    — Parts Killbros 1135 PTO Assembly Friction Clutch - Serial Number B41380100 & Up Please visit www.unverferth.com/parts/ for the most current parts listing. 1 3/4-20 Spline Shown 5-26...
  • Page 143 — Parts Killbros 1135 PTO Assembly Friction Clutch - Serial Number B41380100 & Up Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES 1 3/4”-20 Spline PTO Assembly Complete 9009258 Includes Front and Rear Half Assemblies (Benzi America PTO) 1 3/8”-21 Spline...

  • Page 144: Pto Assembly Friction Clutch - Serial Number B41380099 & Lower

    — Parts Killbros 1135 PTO Assembly Friction Clutch - Serial Number B41380099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. 1 3/4-20 Spline Shown Optional 1 3/8-21 Spline Shown 5-28...
  • Page 145 — Parts Killbros 1135 PTO Assembly Friction Clutch - Serial Number B41380099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES 1 3/4-20 Spline PTO Assembly Complete 9004769 (GKN Walterscheid PTO) 1 3/8-21 Spline (Optional)

  • Page 146: Friction Clutch Assembly - Serial Number B41380100 & Up

    — Parts Killbros 1135 Friction Clutch Assembly - Serial Number B41380100 & Up Please visit www.unverferth.com/parts/ for the most current parts listing. NOTE: Clutch Assembly (9009256) must be used with the Complete PTO Assembly (9009258) or (9009257 - optional). NOTE: The clutch is preset at the factory and should not require adjustment.

  • Page 147: Friction Clutch Assembly - Serial Number B41380099 & Lower

    NOTE: The clutch is preset at the factory and should not require adjustment. See Section 1 for specific clutch information. — Parts Killbros 1135 Friction Clutch Assembly - Serial Number B41380099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing.

  • Page 148: Shear-Bolt Clutch Assembly - Serial Number B41380100 & Up

    — Parts Killbros 1135 Shear-Bolt Clutch - Serial Number B41380100 & Up Please visit www.unverferth.com/parts/ for the most current parts listing. NOTE: Clutch Assembly (9009034) must be used with the Complete PTO Assembly (9008526) or (9009253 - optional). • USE GENUINE OEM REPLACEMENT PART. Incorrect part may cause shear function to oc- cur too soon causing inconvenience or too late resulting in damage to driveline and auger components.
  • Page 149 — Parts Killbros 1135 Shear-Bolt Clutch - Serial Number B41380099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. • USE GENUINE OEM REPLACEMENT PART. Incorrect part may cause shear function to oc- cur too soon causing inconvenience or too late resulting in damage to driveline and auger components.

  • Page 150: 45 Degree Gearbox

    — Parts Killbros 1135 45 Degree Gearbox Please visit www.unverferth.com/parts/ for the most current parts listing. 5-34...
  • Page 151 — Parts Killbros 1135 45 Degree Gearbox Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Gearbox, Complete 9002812 Includes Items 1 thru 17 Shaft, Input 9001131 1.8:1 Gear Shaft, Output 9001132 1.8:1 Gear...

  • Page 152: Upper Auger Components

    — Parts Killbros 1135 Upper Auger Components Please visit www.unverferth.com/parts/ for the most current parts listing. 5-36...
  • Page 153 — Parts Killbros 1135 Upper Auger Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Upper Auger Weldment =Black= 281262 Includes Items 2-8 Soft-Start Kit 278086 Includes Items 3-8 3 Self-Lubricating Bushing 9004877 4 Self-Lubricating Thrust Washer 5.25" Dia.

  • Page 154: Lower Auger Components

    — Parts Killbros 1135 Lower Auger Components Please visit www.unverferth.com/parts/ for the most current parts listing. 5-38...
  • Page 155 — Parts Killbros 1135 Lower Auger Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Includes Flighting & Items 2, 3, Lower Auger Kit 281578-SER 24, 31 Adapter, 4.75” Dia. x 8” 281209B Drive Plate Assembly - 5 Pin 286436 Drive Pin, 0.763”...

  • Page 156: Auger Fold Indicator

    — Parts Killbros 1135 Auger Fold Indicator Please visit www.unverferth.com/parts/ for the most current parts listing. Behind Front Panel ITEM DESCRIPTION PART NO. QTY. NOTES Auger Indicator Weldment with Decal 280575 Includes Item #2 Decal, Auger Indicator 9005335 Decal, Cart Profile...

  • Page 157: Cleanout Door Assembly

    — Parts Killbros 1135 Cleanout Door Assembly Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Door Wheel Weldment 220060B Door Weldment 281015B Roller, Plastic 222118 Plate, Back Door Lift 281059B Plate, Front Door Lift 281060B Shaft &...

  • Page 158: Flow Door Seals

    — Parts Killbros 1135 Flow Door Seals Please visit www.unverferth.com/parts/ for the most current parts listing. 5-42...
  • Page 159 — Parts Killbros 1135 Flow Door Seals Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Capscrew, 1/4”-20UNC x 7/8” G5 9390-004 Capscrew, 3/8”-16UNC x 1 3/4” G5 9390-058 Spring Bracket 281258 Spring 9004375 Flat Washer, 1/4”...

  • Page 160: Drive Components

    — Parts Killbros 1135 " 2 " 1 " 2 " 2 Drive Components Please visit www.unverferth.com/parts/ for the most current parts listing. To Tractor Check/Fill Plug 5-17 5-44...

  • Page 161: Drive Components

    — Parts Killbros 1135 Drive Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Includes Items: 1 - 5, 12, 13, & 9008676 One Driveshaft Replacement Kit 289761 Piece Lock Collar Flangette Bearing, 1 1/2”...

  • Page 162: Driveline U-Joint Assembly

    — Parts Killbros 1135 Driveline U-Joint Assembly Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. QTY. NOTES Complete U-Joint Assembly 95012 Yoke 95010 Grease Zerk, 1/4”-28 UNF 91160 Yoke, 1 3/8-6 Spline 95011 Quick Disconnect Pin Kit 92362 Cross &...
  • Page 163 — Parts Killbros 1135 Notes 5-47...

  • Page 164: Hydraulics

    — Parts Killbros 1135 Hydraulics Please visit www.unverferth.com/parts/ for the most current parts listing. 5-48...
  • Page 165 — Parts Killbros 1135 Hydraulics Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM DESCRIPTION PART NO. NOTES Cylinder, 3” x 22” (3000 PSI) 9004730 Auger Fold Seal Kit 9003772 90° Elbow (9/16-18 JIC Female x 9/16-18 JIC Male)

  • Page 166: Electrical

    — Parts Killbros 1135 Electrical Please visit www.unverferth.com/parts/ for the most current parts listing. 5-50...
  • Page 167 — Parts Killbros 1135 Electrical Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NUMBER DESCRIPTION NOTES 280847 Tail Light Subassembly, Left-Hand 280848 Tail Light Subassembly, Right-Hand 251407B Light Bracket 251406B Light Bracket 251155B Light Bracket Weldment Kit, Left-Hand...
  • Page 168 — Parts Killbros 1135 Directional Spout Components - Serial Number B37230100 & Up Please visit www.unverferth.com/parts/ for the most current parts listing. Seam Location Seam Location Apply adhesive to seal grip to securely fasten seal to spout. 5-52...

  • Page 169: Directional Spout - Serial Number B37230100 & Up

    — Parts Killbros 1135 Directional Spout Components - Serial Number B37230100 & Up Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION QTY. NOTES 268573 Hood Pivot Pin Weldment 272571 Sleeve/Bushing, .75” OD x 2.438” 272620B...

  • Page 170: Directional Spout - Serial Number B37230099 & Lower

    — Parts Killbros 1135 Directional Spout Components - Serial Number B37230099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. Prior To Serial Number b37230100 5-54...
  • Page 171 — Parts Killbros 1135 Directional Spout Components - Serial Number B37230099 & Lower Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION QTY. NOTES 287842B Directional Downspout Kit 94981 Locknut, 1/2-13UNC 9405-088 Flat Washer, 1/2 9004494...

  • Page 172: Weather Guard Tarp Components

    — Parts Killbros 1135 Weather Guard Tarp Components Please visit www.unverferth.com/parts/ for the most current parts listing. 5-56...
  • Page 173 — Parts Killbros 1135 Weather Guard Tarp Components Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 9007458 Tarp 181 x 247 9005581 Tarp Repair Kit TA806225 Hose 1/2" EPDM 9004949 U-Clamp 9003078 Plastic Cap...

  • Page 174: Weather Guard Tarp Mounting Brackets & End Caps

    — Parts Killbros 1135 Weather Guard Tarp Mounting Brackets & End Caps Please visit www.unverferth.com/parts/ for the most current parts listing. End View Of Latch Plates 5-58...
  • Page 175 — Parts Killbros 1135 Weather Guard Tarp Mounting Brackets & End Caps Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 287908B Tarp Kit with Arched End Caps 9005698 Cable Assembly 234" 9009504 End Cap Vent Cover...

  • Page 176: Video System (Optional)

    — Parts Killbros 1135 Video System (Optional) Please visit www.unverferth.com/parts/ for the most current parts listing. 5-60...
  • Page 177 — Parts Killbros 1135 Video System (Optional) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NO. DESCRIPTION NOTES 265770 Video System Kit for Front View Includes Items 1,3,4,5,6,7,8 9004506 Additional Camera for Rear View Includes Items 6 & 7...
  • Page 178 www.unverferth.com MANUALS\\287969///May 2017-0//May 2018-1//May 2019-2//September 2019-3//April 2020-4//July 2021-5//January 2022-6//August 2024-7...

Table of Contents
