OWNER' S MANUAL
Hydraulic Box Auger
MODELS 112, 114, & 115
(All D-Series SN Up To D-1940)
PLEASE PROVIDE MODEL
AND SERIAL NO.
WHEN ORDERING PARTS
KILL BROTHERS
24325 St. Rt. 697W
DELPHOS, OHIO 45833
PHONE: 419-695-2060
FAX: 419-695-6875

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 112 and is the answer not in the manual?

Questions and answers

Summary of Contents for Killbros 112

  • Page 1 Part #: 104936 OWNER’ S MANUAL Hydraulic Box Auger MODELS 112, 114, & 115 (All D-Series SN Up To D-1940) PLEASE PROVIDE MODEL AND SERIAL NO. WHEN ORDERING PARTS KILL BROTHERS 24325 St. Rt. 697W DELPHOS, OHIO 45833 PHONE: 419-695-2060...
  • Page 2: Introduction

    INTRODUCTION This manual covers operation, service, This symbol identifies important safety assembly, and parts for your HYDRAULIC BOX messages. When you see it, read the message AUGER. Read study this manual that follows, and be alert to the possibility of completely before attempting to operate this personal injury.
  • Page 3 ! Guards and shields in place ! Hydraulic hoses properly routed/fittings tight NOTE: Due to continuing improvements in the design and manufacture of Killbros products, and normal changes in the marketplace, all specifications contained herein are subject to change without...
  • Page 4: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION........ 2 SECTION II -- SERVICE SAFETY..........5 LUBRICATION........13 AVOID POSSIBLE INJURY....6 BEFORE OPERATING....6 STORAGE / MAINTENANCE..... 13 DURING OPERATION....6 BEFORE TRANSPORTING... 6 TROUBLE SHOOTING...... 13 DURING TRANSPORT....6 FASTENERS........15 SECTION I -- OPERATIONS SECTION III -- INSTALLATION PREPARING HYDRAULIC SUPPLY..9 GENERAL AUGER INSTALLATION..
  • Page 6: Safety

    SAFETY AVOID POSSIBLE INJURY Always use safety precautions. Most accidents are a result of failure to practice safety. Accidents cause lost time and suffering. Do not operate AUGER without reading this manual thoroughly. Follow all safety precautions as outlined in this manual and in gravity box operator’ s manual. All machinery should be operated only by those who are experienced and responsible and have been delegated to do so.
  • Page 7: During Transport

    Make sure that all safety decals and reflectors are clean and in place on the machine. Comply with all state and local laws governing highway safety when moving machinery. Use accessory lighting or warning lights when transporting at night to adequately warm operators of other vehicles. DURING TRANSPORT Use good judgment when transporting implements on highways.
  • Page 8: Section I -- Operations

    SECTION I OPERATIONS...
  • Page 9: Preparing Hydraulic Supply

    Read this “ Operations” section thoroughly. Acquaint IMPORTANT: Know and understand safety rules yourself with the adjustments required to obtain before operating or servicing this machine. Review efficient and trouble-free operations. “ SAFETY” section in this manual if necessary. PREPARING HYDRAULIC SUPPLY Before operating unit, be sure that you refer to tractor’...
  • Page 10: Transporting

    The control valve will extend the otherwise short life of the seals and motor of the auger. Contact your Killbros dealer for more information.
  • Page 11 • Shock-limit the rate of pressure buildup. • Higher than-needed working pressures. • Using smaller than 1/2” hose between tractor and auger hose coupling. NOTE: Many grain augers run too fast. This is usually the result of modern hydraulic systems, which provide high flow (12 to 25 GPM), at the accessory outlets.
  • Page 12: Section Ii -- Service

    SECTION II SERVICE...
  • Page 13: Lubrication

    LUBRICATION Check the following: Oil or grease periodically or as needed: • Winch, swivel cable, and safety chain for wear and looseness • Clean-out door of hopper • Spout clamp rings • Pivots on bottom of auger and sides of hopper •...
  • Page 14 SYMPTOMS REMEDIES B. Auger runs too slow: Pump is worn Repair or replace pump Internal leak in controls or motor Replace seals; repair or replace valves or motor Air in system Bleed system and tighten connections If auger starts slowly and speed increases after Use proper weight hydraulic oil oil heats up;...
  • Page 15: Trouble Shooting

    F. Auger creeps when spout switch is shut off: Oil flow (GPM) is too high Decrease oil flow (not pressure) to hydraulic motor with use of a flow control valve which must not exceed 12 GPM TROUBLE SHOOTING FOR AUGER HYDRAULICS Occasionally when an auger has been connected into If, for example, the auger operates from the other an auxiliary hydraulic system, it may not operate or...
  • Page 16: Section Iii -- Installation

    SECTION III INSTALLATION...
  • Page 17 This instruction manual is for the installation of the mount, should have the smaller length between Hydraulic Box Auger. This unit can be installed on all brakes pointing away from the box (Refer to Killbros boxes. Figure 3-2). Secure using two 1/2 x 1 1/4” capscrews and locknuts.
  • Page 18 between the two washers and tighten so that the Secure using two straps and four 5/16 x 1 1/4” cable will swivel freely, yet is secure (Figure 3-3). capscrews and locknuts and tighten securely. Be sure that top tabs of straps are to the outside Drill another 3/8”...
  • Page 19 FIG. 3-5 CAUTION! BE SURE THAT LOCK ON WINCH IS ACTIVATED WHEN RAISING UNIT. FAILURE TO ENGAGE COULD CAUSE WINCH HANDLE TO SPIN OUT OF CONTROL CAUSING SEVERE BODILY INJURY IMPORTANT! DO NOT RAISE OR LOWER AUGER. HOPPER BRACKET HARDWARE MUST BE TIGHTENED BEFORE OPERATION CAN TAKE PLACE.
  • Page 20 15. Position transport bracket as indicated in Figure 3-7. Mark the bottom hole 4 inches from the end of the box while centering the hole on the angle. Drill a 3/8 inch hole at this location. 16. Attach transport bracket by inserting a 3/8 x 1 1/4”...
  • Page 21 FIG. 3-10 23. Mount hose coupler bracket to front of gravity box. Position where desired and drill a 3/8 inch hole. Secure using 5/16 x 1 1/4” capscrew and locknut. Mount hoses to bracket and secure using sealant. NOTE: Hoses from bracket to hydraulic supply are not provided.
  • Page 22: Winch Assembly

    WINCH ASSEMBLY Continue through hole “ B” and hole “ C” as shown. WARNING! BEFORE OPERATING WINCH, BE SURE THAT WINCH IS SECURELY INSTALLED TO Finally thread back under cable between hole “ A” THE AUGER AND THAT THE CABLES ARE TIED and “...
  • Page 23: Electronic Valve Assembly

    These instructions are for the installation of the approximately 15 inches from bottom of spout to allow for easy access to switch. Electronic Control for the Killbros Hydraulic Box Auger. This accessory will allow for convenient on / NOTE: Depending on the length of the spout, excess off control of the auger.
  • Page 24 5. Run leads to front of gravity box and connect to a AUGER WILL START IMMEDIATELY, ONCE THE 12 Volt D.C. electrical supply. The white wire (+) FLOW IS INITIATED. TO PREVENT INJURY BE must be assembled to the positive supply of the SURE THAT ALL OBJECTS AND PERSONNEL ARE power source.
  • Page 25: Section Iv -- Parts

    SECTION IV PARTS...
  • Page 28: Hydraulic Augers

    Part No. Description 9807 5/16" Locknut 9389-034 5/16" X 2" HCS 91263 3/8" Flanged Nut 100610 Hydraulic Oil Pipe (112) 9403-96747 5/16" X 1" RD.HD.Mach.Screw 100611 Hydraulic Oil Pipe (114) 9394-008 7/16" Fin. Hex Nut 103932 Hydraulic Oil Pipe (115) 9391-034 5/32"...
  • Page 29: Options

    Hydraulic Auger Options Electric Control Kit Part #: 104370 To Auger To Power Supply AUGER-MATE Part #: 101479 Telescopic Spout Kit Part #: 104066 Item Part No. Description Item Part No. Description 9404-019 5/16" Med. Lockwasher 104424 Swivel Coupling 100630 O-Ring 9389-012 5/16"...
  • Page 30 NOTES...
  • Page 31 NOTES...
  • Page 32 KILLBROS 24325 St. Rt. 697W DELPHOS, OHIO 45833 RT/SS/KB/COMP2\D:\OPERATOR_MANUAL\BOX-AUGER\104936.DOC-062899-1...
