- Page 1 Rev.01 USER GUIDE IPC SERIES CELERON J6412...
- Page 2 The information in this manual is subject to change without notice and does not represent any obligation for FEC ITALIA. FEC ITALIA is not responsible for technical errors or other omissions in the manual and declines any liability resulting from its use.
- Page 3 Regulation laying down implementing measures for Directive (UE) N. 617/2013 2009/125/EC of the European Parliament and of the Council on ecodesign requirements for computers and computer servers Regulation concerning the Registration, Evaluation, Authorization (CE) N. 1907/2006 and Restriction of Chemicals (REACH) FEC ITALIA...
-
Page 4: Table Of Contents
Save and exit ................27 Chapter 5 Software Installation ............28 Chapter 7 Operating System Recovery ........... 29 Bootable key creation with Aomei Backupper 6.7.0 ..... 30 Starting Operating System Recovery ..........30 Chapter 8 Technical Features ............35 FEC ITALIA... - Page 5 Operational Start FEC ITALIA...
-
Page 6: Chapter 1 General
Operational Start Chapter 1 General This chapter contains the list of materials in the packing box and some preliminary notes on installing the system. List of materials provided • Before installation • Warranty notes • FEC ITALIA... -
Page 7: Supplied Materials List
Don't place heavy objects on top of the computer base module. If the computer has been stored or kept inactive for a long period, it is recommended not to switch on it immediately, but only after leaving it FEC ITALIA... -
Page 8: Safety
The machine fell and was damaged. e. The machine has obvious signs of breakage. 11) DO NOT LEAVE THE MACHINE IN AN UNCONTROLLED ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW -20°C (-4°F) OR HIGHER THAN 80°C (176°F) FEC ITALIA... -
Page 9: Chapter 2 System Presentation
Presentazione del sistema Chapter 2 System Presentation This chapter introduces basic information about the Celeron Industrial Panel PC (IPC) series. Introduction • Main features • Specifications • FEC ITALIA... -
Page 10: Sturdy, Power And Safety
7/24 in a voltage range of 9V-36V. These characteristics make it ideal for applications in harsh environments typical of modern Industry 4.0. Sturdy, Power and Safety Externally, it features a sturdy aluminum alloy chassis, with IP65 protection on the front. FEC ITALIA... -
Page 11: True Flat Display And Mounting Options
The TFT LCD is equipped with true flat technology, i.e. without steps between the active touch area and the frame. The capacitive touch screen with 10 simultaneous touches is guaranteed for use with work gloves and IP65 certification guarantees total protection against the FEC ITALIA... -
Page 12: I/O Ports
The back panel has four VESA mounting holes (100 x 100 mm), and hooks for panel mounting are included. I/O Ports The Celeron IPC Series I/O Interface includes (order from right): A. DC 9V-36V B. COM1: RS-232/422/485 C. COM2: RS-232/422/485 D. -
Page 13: Dimensions
Installation and Settings Dimensions IPC J012WAC Dimensions (12.1” Display) FEC ITALIA... - Page 14 Installation and Settings FEC ITALIA...
-
Page 15: Chapter 3 Hardware Setup
Installation and Settings Chapter 3 Hardware Setup Contents included: Quick tour of the system • Installing the memory card • • SSD installation Wi-Fi+BT installation • 4G installationù • 5G installation • HDD Installation • FEC ITALIA... -
Page 16: Access To The Motherboard
Installation and Settings For assembly, you may need these tools. Access to the motherboard Unscrew the seven fixing screws and remove the rear cover. FEC ITALIA... -
Page 17: Ssd M.2
Installation and Settings SSD M.2 2.5” SATA WiFi+BT Module FEC ITALIA... -
Page 18: 4G Module
Installation and Settings 4G Module 5G Module FEC ITALIA... - Page 19 Installation and Settings FEC ITALIA...
-
Page 20: Chapter 4 Bios Setup
Installation and Settings Chapter 4 BIOS Setup FEC ITALIA... -
Page 21: Bios Access
Installation and Settings BIOS Access When turning on, press the <DEL> key to enter the BIOS Advanced FEC ITALIA... -
Page 22: Tpm 2.0 Uefi Version
Installation and Settings TPM 2.0 UEFI Version FEC ITALIA... -
Page 23: Com Ports Selection
Installation and Settings COM Ports Selection Select “COM1 Mode” and set the COM1 operating mode to RS232, RS422 or RS485. FEC ITALIA... -
Page 24: Chipset
Installation and Settings Chipset FEC ITALIA... -
Page 25: Turning The Computer On Power
Installation and Settings Turning the computer on power Security FEC ITALIA... -
Page 26: Boot
Installation and Settings Boot FEC ITALIA... -
Page 27: Save And Exit
Installation and Settings Save and exit FEC ITALIA... -
Page 28: Chapter 5 Software Installation
Installation and Settings Chapter 5 Software Installation FEC ITALIA... -
Page 29: Chapter 7 Operating System Recovery
Software Setup Chapter 7 Operating System Recovery FEC ITALIA... -
Page 30: Bootable Key Creation With Aomei Backupper 6.7.0
Create a boot key using the Rufus utility, available at https://rufus.ie/it/, and download the portable version. Launch Rufus with the USB stick to be formatted already inserted, select the Backupper_Std_670_gen22.iso file Confirm operation with Start/Launch. Starting Operating System Recovery FEC ITALIA... - Page 31 F7 for the Boot device and select: UEFI: USB name • Once the AOMEI_Backupper graphical interface has started, close the screen with the offer, select the Restore and Image File Selection task. Browse external disk and select the “WTC6E_W10_Pro_21H1_Ita/Eng” file, confirm with Open. FEC ITALIA...
- Page 32 Software Setup Check that "Restore entire disk" is checked, click on the Disk 0 box, it turns green, and confirm with Next. Check that Disk0 is highlighted (green), continue with Next, and confirm the overwriting with OK. FEC ITALIA...
- Page 33 Software Setup On the final screen, check SSD Alignment and start the operation with Start recovery >> FEC ITALIA...
- Page 34 Once the activity is finished, the PC will turn off. (disconnect external USB drives) End of Procedure When you turn it back on, the system will start with the initial Windows configuration, with the request to select country - language, etc... FEC ITALIA...
-
Page 35: Chapter 8 Technical Features
Technical features Chapter 8 Technical Features FEC ITALIA... - Page 36 (L x P x A) Model IPC-C012WAC IPC-C156WAC Sizes 314 x 60 x 216 mm 400 x 60 x 250 mm (L x P x A) Weight: 3 Kg Weight: 4,5 Kg Cut-out 300 x 203 mm 386 x 236 mm Quality FEC ITALIA...
- Page 37 ACCESSORIES FOR INDUSTRY AND COMMERCE (IAF 19) EMC: EN 55022 Certifications EN 55032:2015+A11:2020 EN 61000-3-2:2019 EN 61000-3-3:2013+A2:2021 EN 55035:2018/A11 IEC 61000-4-2:2008 IEC 61000-4-3:2020 IEC 61000-4-4:2012 IEC 61000-4-5:2014+A1:2017 Compatible Windows 10/11 IoT, Windows 11 PRO, Linux Ubuntu Operative Systems FEC ITALIA...
