FEC PP Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Rev.01
USER GUIDE
PP SERIES
mod. PP-9745W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PP Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FEC PP Series

Summary of Contents for FEC PP Series

  • Page 1 Rev.01 USER GUIDE PP SERIES mod. PP-9745W...
  • Page 2 The information in this manual is subject to change without notice and does not represent any obligation for FEC ITALIA. FEC ITALIA is not responsible for technical errors or other omissions in the manual and declines any liability resulting from its use.
  • Page 3 Regulation laying down implementing measures for Directive (UE) N. 617/2013 2009/125/EC of the European Parliament and of the Council on ecodesign requirements for computers and computer servers Regulation concerning the Registration, Evaluation, Authorization (CE) N. 1907/2006 and Restriction of Chemicals (REACH) FEC ITALIA...

  • Page 4: Table Of Contents

    9. BIOS Introduction ..............33 Enable/Disable ambient light and proximity sensor on the BIOS . 34 Chapter 5 Software Installation ............36 Device code example ..............37 Cash Drawer ................37 COM Ports ................. 37 Chapter 6 ..................40 Hardware ..................40 FEC ITALIA...
  • Page 5 POWER SETTING (COM) ............46 LED Backlight Brightness.............. 47 Cash Drawer ................. 48 Chapter 7 Operating System Recovery ........... 49 Bootable key creation with Aomei Backupper 6.7.0 ..... 50 Starting Operating System Recovery ..........50 Chapter 8 Technical features ............55 FEC ITALIA...

  • Page 6: Chapter 1 General

    Chapter 1 General FEC ITALIA...

  • Page 7: Package Material List

    Use only a damp cloth and avoid any prolonged contact with moisture. 2) Lay the machine on a stable surface before maintenance or use, to avoid accidental falls. 3) The panel's back grilles are ventings. DO NOT COVER. FEC ITALIA...
  • Page 8 The machine fell and was damaged. e. The machine has obvious signs of breakage. 11) DO NOT LEAVE THE MACHINE IN AN UNCONTROLLED ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW -20°C (-4°F) OR HIGHER THAN 60°C (140°F) FEC ITALIA...

  • Page 9: Chapter 2 System Presentation

    System Presentation Chapter 2 System Presentation FEC ITALIA...
  • Page 10 Intel® i5- 12400 processors with low dissipation and reduced consumption. The system ensures high performance in process speed and graphics functionality, maintaining low power consumption and silent operation thanks to the integrated active cooling system. FEC ITALIA...

  • Page 11: I/O Ports

    PP SERIES | PP-9745W – System presentation It has standard 8GB DDR4 RAM, expandable up to 32GB. It has the possibility to mount easily replaceable M.2 PCIe SSD devices. I/O Ports I/O ports are placed in a protected position. A practical cable cover is supplied with the machine, which prevents unwanted access.
  • Page 12 Serials 2x RJ45 Optional Additional PUSB 24V / PUSB 12V / I/O on Request RS232 / USB 2.0 FEC ITALIA...
  • Page 13 PP SERIES | PP-9745W – System presentation FEC ITALIA...

  • Page 14: Chapter 3 Installation And Settings

    PP SERIES | PP-9745W – User Guide Chapter 3 Installation and Settings FEC ITALIA...

  • Page 15: Terminology And Tools

    Contact your agent for more information. Smart DP: is a proprietary port for exclusive use by Display Smart DP. Previous generation displays, called FEC DP, can be used on this port; However, there will be an error in the control panel that cannot be fixed.

  • Page 16: Stand - Double Hinge

    PP SERIES | PP-9745W – User Guide For assembly, you may need these tools: Stand – double hinge Note: This is a general reference assembly guide, the actual display back cover may not match your product. It will not matter to the assembly.
  • Page 17 While holding the base together with one hand. Use your hand to slightly fasten the screws . Then use the screwdriver to tightly fasten STEP 5: Place the stand in the upright position (left image) then use the screwdriver to fasten the two screws (right image). FEC ITALIA...

  • Page 18: Wall Mount Bracket - Optional

    PP SERIES | PP-9745W – User Guide STEP 6: Place the stand cable cover back on the stand. Then assembly is complete . Wall Mount Bracket - optional FEC ITALIA...

  • Page 19: Color

    Installation and Settings Wall Mount Bracket Color Cable Management FEC ITALIA...

  • Page 20: Adjustable Angle

    PP SERIES | PP-9745W – User Guide Adjustable Angle Dimensions FEC ITALIA...

  • Page 21: Add-On Devices

    It will not matter to the assembly. Tools Needed: You will need to prepare a screwdriver in order to assemble the add-on device. Items Included: Panel PC with Part A of the stand attached. FEC ITALIA...
  • Page 22 PP SERIES | PP-9745W – User Guide Part B of the stand Screw x 4pcs in the accessory box. STEP 1: Remove the side cover. STEP 2: Connect the add-on device to the system. STEP 3: Fasten the two screws. Complete.

  • Page 23: Customer Display Installation (Xp-2025)

    Installation and Settings Customer display installation (XP-2025) 1. Remove the connector 2. Fasten 2 screws for customer display Integrated Secondary Display Loosen the screw indicated in the figure and remove the cover • FEC ITALIA...

  • Page 24: Peripheral Installation

    PP SERIES | PP-9745W – User Guide Connect the customer display and secure it to the display. (Make sure the COM6 port power supply is correct before connecting the VFD.) Don't exceed the maximum tilt angle, otherwise, the internal •...

  • Page 25: Remove/Install Cable Cover

    Installation and Settings 2. Attach ID (USB) device and fix it with 1 x M3 screw Remove/Install cable cover 1. Cable cover removal 2. Cable cover installation FEC ITALIA...

  • Page 26: Chapter 4 Driver & Utility Installation And Configuration

    PP SERIES | PP-9745W – User Guide Chapter 4 Driver & Utility installation and configuration FEC ITALIA...

  • Page 27: Chipset

    • 1. Chipset Locate the chipset folder and double-click on [ SetupChipset ] 2. •Click on [ Next ] 3. • Click on [ Accept ] 4. •Click on [ Install ] 5. •Click on [ Yes ] FEC ITALIA...

  • Page 28: Audio

    PP SERIES | PP-9745W – User Guide 6. •Click on [ Restart Now ] 2. Audio 1. •Double-click on [ Setup ] 2. Click on [ Yes ] 3. Click [ Next ] 4. Click [ Yes, I want to restart...

  • Page 29: Graphics

    Installation and Settings 3. Graphics. 1. Double-click on [ installer.exe ] 2. Click on [ Yes ] 3. Click on [ Next ] 4. Click on [ Next ] 5. Click on [ Finish ] FEC ITALIA...

  • Page 30: Intel ® Me

    PP SERIES | PP-9745W – User Guide 4. INTEL ® 1. Double-click on [ 2. Click on [ Next ] Dpinst64 ] 3. Accept terms and 4. Click on [ Next ] conditions, then click on [ Next ] 5. Click on [ Yes ] 6.

  • Page 31: Serial Io

    1. Double-click on [ 2. Click on [ Next ] SetupSerialIO ] 4. Click on [ Next ] 3. Accept terms and conditions, then click on [ Next ] 5. Click on [ Next ] Select Yes, I want to FEC ITALIA...

  • Page 32: Lan

    PP SERIES | PP-9745W – User Guide restart now, then click on [ Finish ] 6. LAN 1. Fai doppio click su [ Setup] 2. Clicca [ Sì ] FEC ITALIA...

  • Page 33: Sensors

    1. Double-click on [ install ] 2. Click on [ Yes ] 8. Cash Drawer Contact the support staff and request the “FEC Guide for SDK Integration with the Cash Drawer”. 9. BIOS Introduction To access the BIOS, press the <DEL> key when the device is rebooting.

  • Page 34: Enable/Disable Ambient Light And Proximity Sensor On The Bios

    PP SERIES | PP-9745W – User Guide Enable/Disable ambient light and proximity sensor on the BIOS To use the BIOS, you can use the touch panel. Step 1: Boot the system Step 2: Press the <DEL> key during boot to enter the BIOS Step 3: On Advanced >...
  • Page 35 Installation and Settings Note: Factory setting is set on “Enabled”. FEC ITALIA...

  • Page 36: Chapter 5 Software Installation

    PP SERIES | PP-9745W – User Guide Chapter 5 Software Installation FEC ITALIA...

  • Page 37: Device Code Example

    Log.d(TAG, "Failed to send broadcast."); public void CashDrawer_2_Open_click(View view) { try { Intent intent = new Intent(" X.intent.action.SET_BOX_OUTPUT2_HIGH"); mContext.sendBroadcast(intent); Thread.sleep(200); Intent intent1 = new Intent(" X.intent.action.SET_BOX_OUTPUT2_LOW"); mContext.sendBroadcast(intent1); } catch (Exception e) { Log.d(TAG, "Failed to send broadcast."); ---------- COM Ports FEC ITALIA...
  • Page 38 PP SERIES | PP-9745W – User Guide COM1 = /dev/ttyUSB0 COM2 = /dev/ttyUSB1 COM3 = /dev/ttyUSB2 COM4 = /dev/ttyUSB3 COM5 (LCM/VFD) = /dev/ttyS1 ---------- int intSerialPortHandle = -1; int intReturnCode = - private int intBaudRate=9600; private String strTestString="testStringtestString"; String strttyUSBPath;...
  • Page 39 SleepMiniSecond(sp, 1000); intDataReceivedLength = sp.getDataReceivedLength(); nRetry++; if (nRetry == 2) break; if ( intDataReceivedLength>= 0) { btyVersion_msg_received = Arrays.copyOf(sp.getBytDataReceived(),intDataReceiv edLength); sp.close(intSerialPortHandle); sp = null; boolean testResult = false; testResult = (intDataReceivedLength > 0 )? true: false; return testResult; ---------- FEC ITALIA...

  • Page 40: Chapter 6

    PP SERIES | PP-9745W – User Guide Chapter 6 Hardware FEC ITALIA...

  • Page 41: Ram Access

    Make sure the product is turned off. Tools Needed: Prepare a screwdriver. STEP 1: Place the Panel PC face down on a flat surface. Using a precision screwdriver, unscrew the screw. STEP 2: Remove back cover FEC ITALIA...
  • Page 42 PP SERIES | PP-9745W – User Guide STEP 3: Lift the panel, which will automatically release the FFC sensor cable. STEP 4: Release the RAM by pressing on the metal hooks. It will rise, then you can disconnect it by pulling it out at a 45-degree angle.

  • Page 43: Add M.2 From The Tray

    Items Included: Thermal pad in the accessory box. M.2 Tray with Screw x 1 M.2 (PCIe Gen III) x 1 (This can be purchased from FEC or otherwise) STEP 1: Get thermal pad from the accessory box. Remove the plastic and place the thermal pad on to the controller.
  • Page 44 PP SERIES | PP-9745W – User Guide STEP 3: Fasten the screw. Complete. Note: Make sure the system is off when inserting the M.2 tray into the socket. FEC ITALIA...
  • Page 45 Installation and Settings FEC ITALIA...

  • Page 46: Power Setting (Com)

    PP SERIES | PP-9745W – User Guide POWER SETTING (COM) You may select the power (5v / 12v) of COM in BIOS Make sure the device voltage matches the power setting before connection FEC ITALIA...

  • Page 47: Led Backlight Brightness

    Installation and Settings LED Backlight Brightness 5 backlight brightness levels (5, 25, 50, 75, 100%) can be • selected through the BIOS. FEC ITALIA...

  • Page 48: Cash Drawer

    PP SERIES | PP-9745W – User Guide Cash Drawer Only on PP Series Please make sure the voltage and cable pin assignment of your • cash drawer matches the cash drawer port on PP-9735W. You may find the jumper setting and pin definition in M/B J1900 •...

  • Page 49: Chapter 7 Operating System Recovery

    Software Setup Chapter 7 Operating System Recovery FEC ITALIA...

  • Page 50: Bootable Key Creation With Aomei Backupper 6.7.0

    PP SERIES | PP-9745W – User Guide Bootable key creation with Aomei Backupper 6.7.0 Create a boot key using the Rufus utility, available at https://rufus.ie/it/, and download the portable version. Launch Rufus with the USB stick to be formatted already inserted, select the Backupper_Std_670_gen22.iso file...
  • Page 51 F7 for the Boot device and select: UEFI: USB name • Once the AOMEI_Backupper graphical interface has started, close the screen with the offer, select the Restore and Image File Selection task. Browse external disk and select the “WTC6E_W10_Pro_21H1_Ita/Eng” file, confirm with Open. FEC ITALIA...
  • Page 52 PP SERIES | PP-9745W – User Guide Check that "Restore entire disk" is checked, click on the Disk 0 box, it turns green, and confirm with Next. Check that Disk0 is highlighted (green), continue with Next, and confirm the overwriting with OK.
  • Page 53 Software Setup On the final screen, check SSD Alignment and start the operation with Start recovery >> FEC ITALIA...
  • Page 54 PP SERIES | PP-9745W – User Guide With the restore operation in progress, click on the cogwheel and check When finished (it will go out), confirm with OK. Once the activity is finished, the PC will turn off. (disconnect external...

  • Page 55: Chapter 8 Technical Features

    Technical Features Chapter 8 Technical features FEC ITALIA...
  • Page 56 PP SERIES | PP-9745W – User Guide General Processor Intel® Core i5-12400 8GB / 32GB (Factory) / 1 RAM Slot Power Supply External 20V / 130W Integrated Storage SSD NVMe from 128 Gb to 1 Tb Speaker 2 x 2 W Integrated...
  • Page 57 EN 55035:2018/A11 IEC 61000-4-2:2008 IEC 61000-4-3:2020 IEC 61000-4-4:2012 IEC 61000-4-5:2014+A1:2017 Warranty 12 months FEC SWAP24 included in the price Compatible Operating Windows IoT, Windows 11, Linux Ubuntu Systems Optional Warranty Optional SWAP 24 or on-site warranty up to 36 months...
  • Page 58 PP SERIES | PP-9745W – User Guide FEC ITALIA...
