TP-Link RE750C Quick Installation Manual page 2

Access Extender Settings
After setup, you can access extender settings via any of the methods below. You
can reselect main network, change extended network settings and more.
Note: If your extender and router use the same network name, Method 1 is recommended.
Method 1: Via the Tether App
1. Connect your smartphone to the extender's or router's network.
2. Launch the Tether app, select your extender, and log in.
3. Manage the extender as needed.
Method 2: Via a Web Browser
1. Connect your computer or smartphone to the extender's network
using a computer, unplug the Ethernet cable if any.
2. Launch a web browser, enter http://www.tplinkrepeater.net in the address bar,
and log in.
3. View or change extender settings as needed.
EasyMesh-Compatible
You can experience strong, stable, and seamless wireless connections
throughout your home with EasyMesh, a whole home mesh standard that
works across different access points for ultimate flexibility.
Seamless Roaming
Connects mobile devices to your routers or extenders that provide the best
coverage. Devices compatible with EasyMesh also share a single Wi-Fi name so you
stay connected in every room.
One-Click Settings
Press the WPS button on the main router and the extender within 2 minutes of
each other, then the EasyMesh network will set up.
Flexible Scalability
Flexibly scale your home networking with different vendors,* different topologies,
different Protocols and different product categories.
*TP-Link EasyMesh-compatible products can network with other devices that use EasyMesh. Failed connections
may be due to firmware conflicts of different vendors. The EasyMesh-Compatible function is still being developed
on some models and will be supported in subsequent software updates.
This product is compatible with standardized EasyMesh technology but has not obtained the Wi-Fi EasyMesh
certification.
For more information, visit
https://www.tp-link.com/easymesh/.
Q1. What should I do if the Tether app cannot find my device during
setup?
Try another method by following the steps below:
1. Connect your smartphone to the extender's network TP-Link_Extender.
< Settings
Wi-Fi
CHOOSE A NETWORK...
TP-Link_Extender
Other...
2. Launch the Tether app, and select your extender.
Tip: If you have connected to the extender's Wi-Fi but still cannot find your device, try turning off
your cellular data.
3. Follow app instructions to complete the setup.
If you are still having problems, contact our technical support.
Q2. What should I do if the Signal LED doesn't turn solid on after
completing setup via the Tether app or web browser?
You may have entered incorrect Wi-Fi password for your host router during the
configuration. Check the password and try again.
Make sure the extender is close to your router, preferably within 16 feet, and away
from large electrical appliances.
If you have enabled wireless MAC filtering, wireless access control, or access
control list (ACL) on your router, disable them first, then follow any method on the
front page to complete the configuration.
Try setting it up via the WPS button.
Reset the extender and go through the configuration again.
If you are still having problems, contact our technical support.
Scan for Setup Video
Wi-Fi
My Devices
Local Device
RExxx
XX-XX-XX-XX-XX-XX
LED Explanation
LED
If you are
.
Power
Signal
2.4 GHz
5 GHz
Access Point Mode (AP Mode)
Stable wireless performance and wired connection with a main router required.
To change your extender to Access Point Mode, do the following:
a. By Web: Login → Find the Mode button on top.
For details, refer to the user guide at https://www.tp-link.com/support.
English
b. By Tether: Login to your extender → Find the Operation Mode
TM Note: Due to Tether app updates, images may differ from your actual user interface.
Operation Mode
Network
Q3. How do I reset the extender?
With the extender powered on, use a pin to press the RESET button for 1 second.
The extender will reboot.
If you need more setup help, please visit
https://www.tp-link.com/support/faq/3074/, or simply scan the QR code.
Safety Information
• Keep the device away from water, fire, humidity or hot environments.
• Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
• Do not use the device where wireless devices are not allowed.
Please read and follow the above safety information when operating the device. We cannot
guarantee that no accidents or damage will occur due to improper use of the device. Please use this
product with care and operate at your own risk.
TP-Link hereby declares that the device is in compliance with the essential requirements and other
relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011 /65/EU and (EU) 2015/863.
The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce
TP-Link hereby declares that the device is in compliance with the essential requirements and other
relevant provisions of the Radio Equipment Regulations 2017.
The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca
Status Indication (For Range Extender Mode)
On/Off The extender is on or off.
Blinking The system is starting up or firmware upgrade is in progress.
The extender is connected to your router's wireless
Solid blue
network and is in a suitable location.
The extender is receiving a weak signal. Try relocating it
Solid red
closer to your router.
Blinking WPS connection is in progress.
Off No wireless connection is established.
The extender is connected or not connected to the 2.4 GHz
On/Off
wireless network of your router.
The extender is connected or not connected to the 5 GHz
On/Off
wireless network of your router.
Mode Logout Reboot
More
RESET
AC750 Wi-Fi Range Extender Model: RE750C
